To register your HART
product, please visit:
https://HARTtools.com/register
Use this battery pack for HART
only. Refer to the Operator's Manual provided with product.
Always mention the model number above when communi-
cating with us regarding this battery pack.
SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
Failure to follow all instructions listed below, may result
in electric shock, fire and/or serious personal injury.
 Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in operating
condition. Be aware of possible hazards when not
using your battery tool or when changing accessories.
Following this rule will reduce the risk of electric shock,
fire, or serious personal injury.
 Do not place battery tools or their batteries near fire
or heat. This will reduce the risk of explosion and possibly
injury.
 Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped
or received a sharp blow. A damaged battery is subject
to explosion. Properly dispose of a dropped or damaged
battery immediately.
 Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush with water
immediately.
 Charge only with HART
of other chargers may result in personal injury, fire,
or damage.
 Do not charge in an area of extreme heat or cold. It
will work best at normal room temperature. To reduce
the risk of serious personal injury, do not store outside or
in vehicles.
 Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in contact
with your skin, wash immediately with soap and water.
If liquid gets into your eyes, flush them with clean water
for at least 10 minutes, then seek immediate medical
attention. Following this rule will reduce the risk of serious
personal injury.
 When battery pack is not in use, keep it away from
other metal objects like: paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause sparks, burns, or a
fire.
BPH001/BPH002/BPH004 20V
1.5Ah/2.0Ah/1.3Ah
Li-ion Battery Pack
20 V cordless products
20V battery chargers. Use
 Always remove battery pack from your tool when you
are assembling parts, making adjustments, cleaning,
or when not in use. Removing battery pack will prevent
accidental starting that could cause serious personal
injury.
 Always remove battery pack before storing the device.
 When battery becomes fully charged, unplug the
charger from the power supply and remove the battery
pack from the charger.
 Always wear eye protection with side shields marked
to comply with ANSI Z87.1. Failure to do so could result
in objects being thrown into your eyes and other possible
serious injuries.
 Keep battery pack dry, clean, and free from oil and
grease. Always use a clean cloth when cleaning. Never
use brake fluids, gasoline, petroleum-based products, or
any solvents to clean battery pack.
 Do not use a battery pack that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable
behavior resulting in fire, explosion or risk of injury.
 Do not modify or attempt to repair a battery pack that
has been damaged.
 Do not expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or temperature
above 265°F (130°C) may cause explosion.
 Have servicing performed by a qualified repair person
using only identical replacement parts. This will ensure
that the safety of the product is maintained.
 Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specified in the instructions. Charging improperly
or at temperatures outside of the specified range may
damage the battery and increase the risk of fire.
 Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If you
loan someone this tool, loan them these instructions also.
OPERATION
LITHIUM-ION BATTERY PACKS
Lithium-ion batteries deliver fade free power for their entire
run time. Lithium-ion tools will not gradually lose power
due to decreasing battery charge. Instead, power from the
battery pack will drop from full to zero once the full charge
has been drained from the battery. Once this happens,
recharging of the battery is required. It is not necessary to
drain the battery pack completely before recharging.
BATTERY PROTECTION FEATURES
Lithium-ion battery packs are designed with features that
protect the lithium-ion cells and maximize battery life.
If the tool stops during use, release the trigger to reset and
resume operation. If the tool still does not work, the battery
needs to be recharged.
1 - English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPH001 and is the answer not in the manual?

Questions and answers

Gary Whitney
February 11, 2025

I just wanna say I really like your product, the first impact I bought lasted me 2 years. And I built 2 houses with that impact. But it finally stopped working about 6 months ago. Without hesitation I purchased another one. > Used it Twice and the battery got low and I never was able to get it to charge the battery one time all it does is blink. I've had it for six months now it's just won't charge. What can I do about this issue.

User image 67abd234bd478
1 comments:
Mr. Anderson
February 12, 2025

If your HART BPH001 impact driver won't charge and only blinks after six months of use, follow these steps:

1. Ensure you are using a HART 20V lithium-ion charger, as using other chargers can cause issues.
2. Check if the battery pack is too warm. If so, wait for it to cool down before charging. The charger will automatically begin charging once the battery reaches the correct temperature.
3. Inspect the battery pack for any visible damage. If it has been exposed to fluids or shows signs of corrosion, do not attempt to use it.
4. If the problem persists, refer to the charger's operator manual for further troubleshooting.
5. If none of these steps resolve the issue, contact HART customer support for assistance.

This answer is automatically generated
