- Page 1 Host RJ-11 IP Gateway User Guide Version 1.02 - February 2007 Copyright © 1993-2007 AirLink Communications, Inc. All rights reserved.
-
Page 2: Table Of Contents
Default settings 6 Configuring the Raven-E 7 Configuring the Intial IP Address for the Host RJ-11 IP Gateway without a Raven-E 9 Configuring the IP Address and Interface Port of the Host RJ-11 IP Gateway Host RJ-11 IP Gateway Defaults 12 Configuring the Host RJ-11 IP Gateway 12 Hardware . - Page 3 Warranty Terms and Conditions 45 Standard Software Warranty One Year Standard Equipment Warranty Remedy WARRANTY DISCLAIMER LIMITATION OF LIABILITY General Conditions AirLink Technical Support 48 AirLink Support Web Site 48 AirLink Documentation and Guides Contacting Technical Support Host RJ-11 IP Gateway User Guide, version...
-
Page 4: Introduction
The RJ-11 IP Gateway provides the bridge between a device requiring an RJ-11 interface and the Raven-E, with its Ether- net interface. The Host RJ-11 IP Gateway can provide Ethernet-based Internet connectivity to a Legacy Host system with only RJ-11 ports. -
Page 5: Host Rj-11 Ip Gateway Features
The phone port is a phone line designed to function just like standard wall-jack analog phone line. It is designed primarily to connect dial-up devices, with internal modems, to the RJ-11 IP Gateway, which then routes data from the devices over the network. The RJ-11 IP Gateway and... -
Page 6: Installation
Host RJ-11 IP Gateway CD or you can download Wireless Ace from the AirLink website: /www.airlink.com/support/modems/utilities/. A default installation of this utility is assumed later in these directions. If you will not be connecting the Host RJ-11 IP Gateway to a Raven-E, you will not need Wire- less Ace. •... -
Page 7: Cellular Account Required
Installation If you will be connecting the Host RJ-11 IP Gateway to a Raven-E, you will need a cross-over Ethernet cable to configure your Raven-E unless your computer’s Ethernet port is auto-sensing. The Host RJ-11 IP Gateway has an auto-sensing Ethernet port, you can use either a cross-over cable or a straight-through Ethernet cable to connect the Host RJ-11 IP Gateway to the Raven-E or your computer. -
Page 8: Configuring The Raven-E
Configure the Raven-E for Public Mode. Set the *HOSTPRIVMODE to 0. In this mode, the modem assigns the Host RJ-11 IP Gateway the IP address it has received from your cellular pro- vider. This is the default setting for the modem. -
Page 9: Private Mode
Host RJ-11 IP Gateway User Guide, version If the modem and the Host RJ-11 IP Gateway are going to be on a LAN with other computers and devices you may want to use Private Mode. On a LAN, a DHCP server other than the modem may give the Host RJ-11 IP Gateway an IP address to which the modem would not know to send its messages. -
Page 10: Configuring The Intial Ip Address For The Host Rj-11 Ip Gateway Without A Raven-E
Host RJ-11 IP Gateway User Guide, version Wireless Ace: Status If you are using a Raven-E with the Host RJ-11 IP Gateway, you do not need to use this utility, skip this section. If you are able to use the default IP address of the Host RJ-11 IP Gateway, you,... - Page 11 Type in an IP address. It’s recomended that you use 192.168.1.3. Press Enter to save the address. If the Host RJ-11 IP Gateway is not displayed in step 2, you will need to manually add the device. optional Click on Add Unlisted Port Server.
- Page 12 Note the current settings (so you can return to them when you finish). FIGURE 9. Change the IP address to match the temporary IP address you configured for the Host RJ-11 IP Gateway. The last number needs to be different. If you configured 192.168.1.3 for the Host RJ-11 IP Gateway, you should use 192.168.1.2 for your computer.
-
Page 13: Configuring The Ip Address And Interface Port Of The Host Rj-11 Ip Gateway
IP Address: 192.168.1.3. Configuring the Host RJ-11 IP Gateway Connect the Host RJ-11 IP Gateway to power and connect the Ethernet cable from your computer to the Host RJ-11 IP Gateway. Type “http://192.168.1.3:9080” (see the example in the screenshot below) in the Address or Location bar and press the enter key. - Page 14 Select Network Settings from the menu on the left. FIGURE 12. DHCP Mode In DHCP Mode, the Host RJ-11 IP Gateway will receive its IP address from the modem. The IPv4 Address and the IPv4 Netmask should be listed as 0.0.0.0. Host RJ-11 IP Gateway User Guide, version...
- Page 15 Static IP Mode If the Host RJ-11 IP Gateway is going to be on a LAN, you many wish to set a static IP address. Use this mode only if you have configured Private Mode for the modem. The default for the Host RJ-11 IP Gateway is a static IP address of 192.168.1.3.
- Page 16 Host RJ-11 IP Gateway: Serial Settings None For most configurations, the default settings are best. Change these parame- Note: ters only if you know the device you will be connecting to the Host RJ-11 IP Gate- way requires special settings. Host RJ-11 IP Gateway: Reset/Reboot...
-
Page 17: Hardware
Caution: nected into the Public Switched Telephone Network (PSTN). This device is designed to emulate the PSTN for other devices. The Host RJ-11 IP Gateway may sustain damage not covered by warranty if it is connected to the Public Switched Telephone Network. - Page 18 The Host RJ-11 IP Gateway is starting up. The Host RJ-11 IP Gateway is obtaining an IP address from the modem. The Host RJ-11 IP Gateway has an IP address and is operat- ing normally. No power to the Host RJ-11 IP Gateway.
- Page 19 ETHERNET - Indicates the status of the Ethernet connection (RJ-45 port). TABLE 4. LED Condition Solid Green Green/Yellow Blinking • PHONE - Indicates the status of the phone port (RJ-11). TABLE 5. LED Condition Solid Green Blinking Green Blinking Red...
-
Page 20: Configuration Settings And Commands
Configuration Settings and CHAPTER 4 Commands The Host RJ-11 IP Gateway can be configured to handle a variety of devices which need to connect to an RJ-11 port. Web-based Interface The Host RJ-11 IP Gateway employs a web-based user interface. To access the web interface, you will need to know the IP Address given to your Raven-E by the cellular carrier (or the modem domain name if you have configured IP Manager settings for the modem). -
Page 21: Service Configuration
Most of the Service Configuration menu options deal with the RJ-11 port. Welcome The Welcome screen is the first page displayed when you connect to the Host RJ-11 IP Gateway. Current settings and status are shown in a table. FIGURE 3. -
Page 22: Serial Settings
Ethernet Address: MAC Address of the Host RJ-11 IP Gateway. • IP Address: The current IP Address of the Host RJ-11 IP Gateway and how the IP address was assigned (in the example, a Raven-E in Public Mode used DHCP to give the Host RJ-11 IP Gateway the IP addressed assigned by the cellular network). -
Page 23: Port Services
Port Services By default, the RJ-11 port is configured to accept incoming TCP connections from TCP/telnet cli- ents with outgoing service based on phone numbers dialed by the attached device (Modem Ser- vice). -
Page 24: Phone Number Translation
The Default Translation entry is used if the dialed phone number is not found in the list. (The dial backup number is not used in the Host RJ-11 IP Gateway.) The phone number table has a number of features to ease initial configuration. When an attached device dials a number that is not in the table, the device server creates a dummy entry in the table. -
Page 25: Network Translation
TCP hosts. This functionality is called network translation and behaves much like a TCP “pipe” between two systems. The Host RJ-11 IP Gateway also uses Network Translation to allow connections to the web-base interface on a port other than the http protocol defined port of 80 which is frequently blocked by cellular carriers. -
Page 26: Protocol Settings
IP address contains the network number, and which portion contains the host number. The default netmask depends on the “class” of the IP address that you are using. Host RJ-11 IP Gateway User Guide, version... - Page 27 In one type of configuration, the Host RJ-11 IP Gateway has been designed to work in conjunction with an AirLink Raven-E. The IP address for the Host RJ-11 IP Gateway and the IP address for the Raven-E need to be on the same network. If you need to set a specific IP address for the Raven-E and the Host RJ-11 IP Gateway, you will need to use Private Mode for the Raven-E.
-
Page 28: Dns Settings
“foo” in the ping command and the domain name “company.com” in the DNS Domain Name above, the ping command will do a DNS lookup on the name “foo.com- pany.com”. Host RJ-11 IP Gateway User Guide, version... -
Page 29: Ip Routing
Time is used in the system and other logs. Having the correct time can help to troubleshoot prob- lems or simply to track occurrences of particular events. The current time is expressed in UTC (Coordinated Universal Time). Host RJ-11 IP Gateway User Guide, version Host RJ-11 IP Gateway: IP Routing... -
Page 30: Security Settings
UDP port 123. If your device server is behind a firewall you may need to allow accesses to this port through the firewall. Adding or changing the NTP server will trigger the Host RJ-11 IP Gateway to get the time again. - Page 31 Configuration Settings and Commands FIGURE 13. • System Password: The Host RJ-11 IP Gateway’s administrative functions can be protected by a system password. By default, no system password is configured. Once a password is set, your web browser will prompt you for the system password whenever you try to access sensitive configuration pages.
-
Page 32: Online Update
“call out” to get updates if all the incoming connections are disabled. FIGURE 15. Host RJ-11 IP Gateway User Guide, version Host RJ-11 IP Gateway: Online Update -top half of the page P Host RJ-11 IP Gateway: Online Update - middle of the page... -
Page 33: Status And Logs
The status and log pages display system and operation information. Troubleshooting Significant events will be displayed for review. For a more complete report of events, see the sys- tem log. Host RJ-11 IP Gateway User Guide, version Host RJ-11 IP Gateway: Online Update - bottom of the page... -
Page 34: System Log
You can save the System Log to a file to review separately. You can also clear the log, but there is no confirmation on clearing the stored log file. FIGURE 18. Port Status The current status of the RJ-11 port is displayed. Host RJ-11 IP Gateway User Guide, version Host RJ-11 IP Gateway: Troubleshooting Host RJ-11 IP Gateway: System Log... -
Page 35: Os And Network Information
The DCD, RTS, CTS, DTR, DSR, and RI columns indicate the status of the modem signals for the RJ-11 (phone) port. If the modem signal is present (either asserted if it is an outgoing signal, or detected if it is an incoming signal) its name will appear in the corresponding column. -
Page 36: Log Files And Settings
By default, the Host RJ-11 IP Gateway stores informational and warning messages in the system log. You can also configure the Host RJ-11 IP Gateway to save trace data in this system log buffer. Host RJ-11 IP Gateway: Log Settings FIGURE 20. -
Page 37: Commands
You can usually find the SMTP settings in the email client you use. Not all email hosts will allow relaying through their host. Commands The Host RJ-11 IP Gateway has some built in commands available. Ping You can use the Ping command to test a network connection. -
Page 38: Reset/Reboot
IP address effectively tests the first function. Reset/Reboot The Reset/Reboot page lets you reset the phone (RJ-11) port or the entire Host RJ-11 IP Gateway. FIGURE 23. You can reset the phone port by selecting the port and pressing the Reset Port(s) button. This will kill whatever service was on the port and reset it back to the current configuration settings. -
Page 39: Specifications
Public Switched Telephone Network (PSTN). This device is designed to emulate the PSTN for other devices. The Host RJ-11 IP Gateway may sustain damage not covered by warranty if it is connected to the Public Switched Telephone Network. -
Page 40: Optional Mounting Bracket
Specifications Optional Mounting Bracket The mounting bracket is designed to “snap” on to the back of the Host RJ-11 IP Gateway for easy installation. Mounting Bracket, part number 100-170-1010 FIGURE 1. Host RJ-11 IP Gateway User Guide, version... -
Page 41: At Commands
AT Commands APPENDIX B In addition to the web-based interface, you can use some typed AT Commands with the Host RJ-11 IP Gateway. To enter AT commands, you need to be connected to the device via telnet or by using the RJ-11 port as you would a standard analog modem. - Page 42 &V1 Status &W Write current configuration to flash &W1 &Xnnn Change baud rate. &X Any other & command is ignored Host RJ-11 IP Gateway User Guide, version Response OK(0) Varies OK(0) OK(0) OK(0) OK(0) OK(0) Equivalent to ATZ without dropping the con- nection.
-
Page 43: Response Codes
ERROR CONNECT 1200 NO DIALTONE BUSY NO ANSWER CONNECT 2400 CONNECT 4800 CONNECT 9600 CONNECT 14400 Host RJ-11 IP Gateway User Guide, version Response OK(0) OK(0) OK(0) Contents Automatic Answer(# of RING's) Number of RING's Received Command Line Termination Character... -
Page 44: Modem Signal Behavior
AT Commands Modem Signal Behavior The RJ-11 IP Gateway is not a modem (DCE), but is a terminal (DTE) device. It is designed to be connected to another DTE device via RJ-11 cable.The RI (Ring Indicator) signal does not have a corresponding outgoing signal so it is not supported. -
Page 45: Port Settings
Port Settings Most of the serial port settings (like baud rate) are controlled by the configured port settings on the device server. Modem emulation does not support changing these from AT commands. Host RJ-11 IP Gateway User Guide, version Example Notes... -
Page 46: Warranty Terms And Conditions
510-781-9760 to obtain an RMA number. Products deemed by AirLink to be DOA (dead on arrival) may be returned to Air- Link for repair, at AirLink's expense, using the standard RMA procedures. Host RJ-11 IP Gateway User Guide, version... -
Page 47: Warranty Disclaimer
OF ANY EXCLUSIVE REMEDY AND THE EXPIRATION OF THESE WARRANTY TERMS. General Conditions AirLink shall have the right to assign any or all components of these Warranty Terms without the prior written consent of the other party. AirLink shall not be liable to Customer for any alleged... - Page 48 Any modifi- cations of these Warranty Terms must be in writing and signed by a duly authorized officer of both parties hereto. Host RJ-11 IP Gateway User Guide, version...
-
Page 49: Airlink Technical Support
AirLink Technical Support APPENDIX D If you encounter problems with operation of your Host RJ-11 IP Gateway or Raven-E (as applica- ble), AirLink’s support staff can help. AirLink Support Web Site The AirLink web site is updated frequently with Setup Wizards, Utilities, How-To Guides, and other documentation: http://www.airlink.com/support.
