Quicksilver MAX Sprint Assembly Manual page 105

TAIL GROUP TO AXLE & WINGS
1/4" LOCKNUT
(10510)
WASHER
LOWER BOOM TUBE
(40421)
BOTH ASSEMBLIES USE THE SAME HARDWARE
UPPER BOOM TUBE
(40179)
TAIL BRACE TUBE
(40425)
At this point, both wings are attached to the Trike and the Trike is sitting on all three wheels.
First step is to set the Tail Skid on blocks (chair) and attach the Upper Tail Booms to the
Channels on the Wings. You will need to Rotate the channels to align with the holes in the
Boom Tube. Raise or Lower the tail skid as needed. A 1/4" drift pin (or Phillips Screw Driver)
will aid in this step.
Once connected DO NOT raise or Lower the tail assembly. This will damage Tubing, Channels
and or Bolts. Attach the AFT end of the Lower Boom Tube to the bottom of the Tail Skid (41150) and or Bolts.
Attach the FWD end of Lower Boom Tubes to the Channels on the Main Axle.
Attach the Landing Gear Side Wire to the Tang on the Main Axle.
CAUTION: Be very sure the Upper Boom Tube aligns easily to Channel.
Section 9
Air-Tech, Inc
LANDING GEAR SIDE WIRE
(20616)
AN4-20a
(10170)
CHANNEL (20090)
6
