A013-V1.0
Wireless Battery-Powered
Security Camera Kit
User Manual
Amazon Email: Johnny@hiseeu.com
Whatsapp ID: +8613392810296
Website: www.hiseeu.com
Telephone: +1 917 338 1084
(Available Pacific Time 5:00pm-12:00pm)
*Please read this manual thoroughly before using and keep it for future reference.
Advertisement
Summary of Contents for Hiseeu WK-3C70
- Page 1 A013-V1.0 Wireless Battery-Powered Security Camera Kit User Manual Amazon Email: Johnny@hiseeu.com Whatsapp ID: +8613392810296 Website: www.hiseeu.com Telephone: +1 917 338 1084 (Available Pacific Time 5:00pm-12:00pm) *Please read this manual thoroughly before using and keep it for future reference.
- Page 2 Appreciation here. Thanks again for your great support. With the support, not only can we insist on our dream, but also do our best to develop Hiseeu products. We are looking forward to your suggestions, which would help Hiseeu become a world-leading brand in innovating video surveillance products and solutions front.
-
Page 4: Packing List
Packing List Network Video Recorder 2Pcs C80 Battery Cameras 2Pcs Camera Mounts 32G SD Card NVR Power Cable 2Pcs Type-C Cables Wireless Battery-Powered Security Camera Kit Network Cable User Manual Screws Device connection Step1: Connect the base station to the power supply and the router. -
Page 5: Interface Description
Note: The camera and the base station have been paired for you, you just need to wait for the channel 1 and 2 indicators to be always on and the camera pairing is successful. Interface Description IR sensor Indicator light Speaker Microphone HD lens... - Page 6 The explanation of LED indicator: Blue light + color light is always on: The camera is being previewed. Remotely (privacy light). Blue light is on for 1s: The device is turned on or woken up. The blue light flashes continuously: Upgrading. Blue light is always on: Charging.
- Page 7 Register account and login Account registration: Click Register on the login interface, enter your mobile phone, and click Confirm. Verify according to the page prompts (Touch the tennis ball to the red dot and drop the tennis ball onto the racket). Finally, enter the verification code you received and the password you set and you are successful.
- Page 8 Account login: On the login interface, enter the account phone number/email, and the corresponding password, and click the "Confirm" button to log in. Third-party login: App supports third-party login. Click the third-party social software icon, jump to the App to complete the authorization and log information on the page.
-
Page 9: Function And Application
Function and Application Click icon, you will see four options. - Page 10 Alarm Push: Turn on motion detection notification. Settings: Go to setup Base station interface directly. Edit: Edit device name and view your device password. Delete: Delete the device on cellphone. Base Station Setup Interface Base station synchronization alarm: After the camera is turned on, the base station will emit an alarm sound synchronously when the camera triggers motion detection.
- Page 11 Camera is different from that of the mobile phone. Please click the time synchronization, it will automatically sync to your phone time. If camera’s time still is incorrect, you can select correct time zone by yourself.
- Page 12 Setup password: You can change the device password here Set signal path: If your current device communication signal is not good, you can try to use another signal channel Cloud service: Click it you can purchase cloud service, each device only can be purchased separately. a.
- Page 13 b. You can select monthly renewal, when the validity period of cloud storage expires, the fee will be deducted automatically, or click more package to purchased according to the time period. News: you can look at the alarm message and you can select date, time range and motion type, such as all types, motion detection, humanoid detection etc.
- Page 14 Share: share the device to your friend or family. a. Click icon, select share permission and QR code validity. b. Click finish in the upper right corner to generate a QR code, share the QR code to other people.
- Page 15 Playback: Watch camera record, but you need to insert the SD card or purchase cloud service firstly. Please note, just cloud service supports fast forward option, SD card does not support.
- Page 16 Real Time Video Recording Function 1. Picture quality switching, switch the SD/HD manually. 2. It can display images from four cameras at the same time, or you can choose to display only one camera image 3. Turn on/off sound collection. 4.
-
Page 17: Digital Zoom Function
a. Open Detect alarm icon, When the camera detects an object moving, it will immediately send an alarm message. b. Alarm: when you find someone invading, please click the alarm button, and the camera will sound the alarm for 14 seconds to scare away the intrude Digital Zoom Function With the digital zoom magnification image clarity will... - Page 18 Camera Setup Function Smart detection alarm: You need to turn it on to receive alarm notifications. Motion detection sensitivity: if you receive too many wrong alarm messages, please set the sensitivity of motion detection to low.
- Page 19 Smart detection Period: There are four options to choose detection period, such as all day, day model (the detection time is from 8 a.m. to 8 p.m) , night model (the detection time is from 8 p.m to 8 a.m) or you can also customize detection time.
- Page 20 Picture settings: Three modes: This image currently only supports infrared mode, not full color, so the images are all black and white in low light conditions...
- Page 21 Storage settings You can view the usage time of cloud storage, the status of SD card and storage capacity in the storage settings interface. If you have inserted the sd card, but not recording, please check if the SD card status is normal.And you also can download video on this interface.
- Page 22 Device share You can share device permissions with your family according to your needs, each device can share up to 10.
-
Page 23: Frequently Asked Questions
Frequently Asked Questions Q1: One of the cameras doesn't show an image what should I A: 1. You can try pairing it with the base station after resetting camera. After successful pairing, you can refresh the base station on the app. 2. - Page 24 Q: How to use SD card to record video? A: please insert the SD card before powering on; Please check whether the SD card status is normal in the App, if it is abnormal, you can try to format the SD card. (We have installed a 32G memory card in the base station for you ) Note: If the above issues are still not resolved, you can con- tact us.
