ViewSonic Optiquest Q55 Specifications page 2

Optiquest
Q55
Q55
15" (13.8" viewable) COLOR MONITOR WITH
CRT Type
Dot Pitch
Phosphor
Glass Surface
INPUT SIGNAL Video
Sync
Frequency
COMPATIBILITY PC
® *
Mac
CONNECTOR Signal
Power
POWER
Voltage
Consumption
USER CONTROLS Basic
®
OnView
VIDEO INPUT Bandwidth
MISCONVERGENCE
DISPLAY AREA Factory Setting 262mm (H) x 196mm (V) (Dependent upon
Maximum Scan 285mm (H) x 216mm (V) signal timing used)
OPERATING Temperature
CONDITION Humidity
DIMENSIONS Physical
WEIGHT Net
OTHER
REGULATIONS
POWER MANAGEMENT
WARRANTY
381 Brea Canyon Road, Walnut, CA 91789
( 800 ) 843-6784 (909) 869-9216
•
Fax (909) 468-3770 Internet: www.optiquest.com
•
*Free universal Mac cable adapter available. Copyright © 2000 ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are
the property of their respective companies. Specifications subject to change without notice. The EPA only promotes energy efficiency and does not endorse any
particular company or product.
®
Monitor
Monitor
15" (13.8" diagonal viewable area)
90 ˚ deflection
0.24mm Horiz., 0.14mm Vert., 0.28mm Diagonal
RGB medium/short persistance
Tint (TM=57%), anti-static, anti-reflection coating
RGB Analog (0.7Vp-p, 75 ohms)
H/V separate, Composite Sync
F h :30-70kHz, F v :50-160Hz
® ®
IBM XT, AT, 386, 486, Pentium , PS/2 and
compatibles (640 x 480 up to 1,280 x 1,024)
Power Mac ™ (up to 1024 x 768)
15-pin mini D-sub (attached cable)
3-pin plug (IEC320)
AC 90-264VAC (auto switch)
50/60 (auto switch)
70W (typ)
Power on /off, enter, adjust (2 keys)
Contrast, brightness, H/V-position, H/V-size,
OSD position, pincushion, trapazoid, pin-balance,
parallelogram, moiré, tilt, color control, recall,
zoom, corner
110MHz (typ)
0.3mm (max) at center
0.4mm (max) at corner
32 ˚ F to 104 ˚ F (0 ˚ C to 40 ˚ C)
5% to 95% (non-condensing)
365mm (W) x 369mm (H) x 398mm (D)
(14.4" x 14.5" x 15.6")
12.5Kg (27.5 lbs.)
DDC1, DDC2B & GTF
UL, CSA, FCC-B, DHHS, DOC-B, MPR-II, EPA, TCO,
CB, CE, NOM, ISO9241-3
Meets Energy Star ® , VESA DPMS ™
standards
Three year limited warranty on CRT, parts and labor.
48 hour Express Exchange ® service option available
V iewSonic
ViewSonic
Powered by
ViewSonic Corporation's QMS\EMS has been registered to
ISO 9001 & ISO 14001 by the British Standards Institution.
Features & Benefits
1,280 x 1,024 maximum resolution
Displays a maximum resolution of 1,280 x
1,024; 1,024 x 768 at 86Hz flicker-free
refresh rate for easy viewing.
1,280 x 1,024 @ 65Hz
1,024 x 768 @ 86Hz
800 x 600 @ 109Hz
OnView ® controls including ViewMatch
All screen adjustments are made via an
on-screen menu using simple controls.
ViewMatch allows the user to adjust color
temperature and individual color intensity
for screen-to-print matching.
Anti-static, anti-reflection screen
This anti-static, anti-reflection screen coating
refracts unwanted light away from the user
while maintaining the highest quality of the
displayed image.
VESA ® and GTF compliant
Maximizes display performance by
automatically aligning images to reduce
set-up time.
TCO '92
®
®
®
OPQ55-2_02/00_10K_rev1
