Bauhn ABTWPDQ-0224-M User Manual

Have you got everything?
A
B
E

Operation

Setting Up

• Extend the tripod legs so that the tripod can stand on
a flat surface.
• Screw the microphone mount onto the tripod as
illustrated, ensuring it is securely screwed in.
• Screw the condenser microphone onto the microphone
mount until it is securely locked in.
• Cover the microphone with the supplied foam cap to
avoid wind noise and distortion.

Connect to Computer

• Plug in the supplied USB cable to the USB port on the
bottom of the microphone as illustrated, and the other end
to a USB port on your PC/laptop.
• Once connected, your PC/latop will automatically
recognize the device and install the driver.
For Windows:
• Go to Device Manager > Audio inputs and outputs > The
"Bauhn Microphone" should appear.
For MacOS:
• Open system preference and select Sound.
• Select "Bauhn Microphone" for both the input and output
tab options.
• Note: A USB hub (not included) is required if your MacOS
system does not have a USB port.

Voice Recorder

• You will need to install the relevant software for
this function to work.
For Windows:
• Download and install the Windows Voice Recorder (if not already installed)
on the Microsoft store.
For MacOS:
• Download and install the Voice Memo app (if not already installed) on the
apple store.
• Ensure you are not on mute.
No volume
• Adjust the volume knob.
Computer • Ensure the USB cable is securely connected on both the
cannot
detect
• Open the control panel. Select "Add a device" tab and
microphone
Nearly done! Just a bit more on the other side of this page...
C
D
F
G
A. MUTE: Press the button to mute the
microphone (The button will light up red).
A
Press again to unmute (button light will be off).
B. ECHO KNOB: Adjust the knob to
B
increase/decrease the echo of the
microphone.
C. VOLUME KNOB: Adjust the knob to
C
increase/decrease volume level.
D. HEADPHONE JACK: Connect to your
D
headphones for monitoring audio playback.
Note: The volume knob is for adjusting
the microphone and will not adjust the
headphones volume.
microphone and your laptop/PC.
manually search & install the microphone.
User Guide
Model: ABTWPDQ-0224-M
Condenser Microphone
A. Condenser Microphone
B. Foam Cap
C. Tripod
D. Microphone Mount
E. USB Cable
F. User Guide
G. Warranty Certificate

Product Overview

Troubleshooting
