Page 2
Table of Contents Safety Information-Single Fixed Sofas Safety Information-Gas Fire Pit Table Pre-assembly(continued)-Single Fixed Sofas Pre-assembly-Gas Fire Pit Table Assembly-Single Fixed Sofas 18-19 Package Contents-Gas Fire Pit Table Pre-assembly (continued)-3 Seater Sofa 20-21 Assembly-Gas Fire Pit Table 8-10 Assembly-3 Seater Sofa 22-23 Operating-Gas Fire Pit Table 11-13...
Page 3
WARNING: FOR YOUR SAFETY: If the information in this manual is not followed exactly. a re or explosion may result causing property damage, personal injury or loss of life. WHAT TO DO IF YOU SMELL GAS: Do not try lighting any appliance. Do not touch any electrical switch;...
Page 4
WARNING: Solid fuels shall not be burned in this appliance. The installation must conform with local codes or, in the absence of local codes, ANSIZ223.1/NFPA54, NFPA58 NaturalGas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2. This appliace must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
PL ANNING ASSEMBLY Carefully remove all pieces from the carton and make sure that you have all parts (refer to the hardware and package contents list). If you are missing parts, please contact 1-877-606-2818for further assistance. YOUR OWNER'S MANUAL Keep and store this Owner's Manual for future reference. It contains important instructions and procedures for safety and maintenance.
Page 7
PART DESCRIPTION QUANTITY LegA Leg B LegC Leg D Back Panel Side Panel With Window Side Panel Door Fire Glass Table Top With Burner Door Knob Tank Support Cross Bar...
Page 8
Step 1: Attach Door Knob (L) to Door Panel () using one (1)M6 X 12mm Bolt(AA). Step 2: Attach the leg (ABCD)to the table top by using eight M6*12 Bolts. Attach Back panel (E) to Leg (B)and (C)with four M6*12 Bolts (AA). Phillips head screwdriver (not included).
Page 9
Step 4: Attached the Side Panel With Window (F) to Leg(C) and (D) by using four M6*12mm bolt. Do not tighten the bolts at this step. Step 5: Pull out the control panel and attach it to side panel with window (F) with two M6* 12mm bolts(AA) and M6 Nut(CC).Please use Phillips head screwdriver(not included).
Page 10
Step 7: Insert the door(H) to the leg(A),and attach it with one(1) M6x20mm Hex Head Bolts(DD). Step 8: Place the propane tank (not included) onto the propane tank support (M). Secure the tank by tighting the screw of the propane tank support(M). Connect the hose and regulator to the propane tank.
Page 11
Never use this appliance for other than the intended use. DO NOT use this WARNING: appliance to prepare food. Initial Lighting: When lit for the first time, the appliance emits a slight odor. This is a normal temporary condition caused by the“burn-in”of internal paints and lubricants used in the manufacturing process and does not occur again.
LEAK TESTING OPERATION WARNING: A leak test must be performed annually or if a part of the gas system is replaced. WARNING: Never use an open flame to check for gas leaks. Be certain no sparks or open flames are in the area while you check for leaks.
Page 13
LIGHTING CAUTION : Keep the outdoor gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. CAUTION : Do NOT obstruct the flow of combustion and ventilation air. CAUTION : Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire.
Page 14
Storage between uses: □ Turn the control knob to “OFF” position. □ Disconnect LP source. □ Store heater upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow, dust and debris). □ If desired, cover heater to protect exterior surfaces and to help prevent build up in air passages. NOTE: Wait until heater is cool before covering.
Page 15
PROBLEM PROBLEM CAUSE SOLUTION The flame and heat are The propane lighting Ensure lighting procedure is followed carefully. The valve low when the valve is procedure was not followed must be in the off position when the tank valve is turned on. turned to high.
Do not completely tighten screws until all screws are started.Tighten each bolt rmly and properly. • • Some parts may contain sharp edges. Wear protective gloves as necessary. • Children under the age of 16 should not be engaged in the assembly, removal or disassembly of the product. Children under the age of 10 should be supervised by a competent adult while using this furniture.
