- Page 1 AIJGO-34/COMP PERSONAL GROUNDING TESTER WITH PLATFORM, DOUBLE DUAL FOOT ELECTRODE, RFID READER, LCD DISPLAY, OPERATING SOFTWARE AND ENTRANCE GATE WITH TURNSTILE INSTRUCTION MANUAL www.dlb.hu sales@destsa.hu +36 27 502 555...
-
Page 2: Table Of Contents
TABLE OF CONTENTS About the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Technical informations . -
Page 3: About The Product
ӹ Test result indication on LCD display, with LED light and sound The AIJGO-34/COMP is a tester for checking personal grounding before entering an ESD protected area (EPA). It may be a good choice if you want to identify persons entering the site. -
Page 4: Technical Informations
CE declaration We declare that the AIJGO-34/COMP product complies with the requirements of IEC 61340-5-1, ANSI/ESD S20.20 and Directive 2001/95/EC (General product safety). Warning The device can deliver an effective output power of up to 20 µA or less at a maximum voltage of 100 V for 2-4 seconds at 0,5 second cycles. - Page 5 Barrier for AIJGO-22/COMP or AIJGO-34/COMP tester AIJGO-OLED Optional gate opening touch button outwards PieManager management software for AIJGO-34 and AIJGO-34/COMP (if AIJGO-34/MSW buying more than one tester, it is sufficient and recommended to buy one if they will be networked together)
-
Page 6: Parts Of The Tester
PARTS OF THE TESTER Steel touch button with 9 RGB LEDs Combined 4 mm banana plug and 10 mm snap socket for connecting wrist strap/groundable ESD smock LCD display Speaker location RFID reader Connector to the common grounding point Cable for connecting foot electrodes of the gate... - Page 7 AIJGO-OLED - Optional gate opening touch button outwards...
-
Page 8: Turnstile Control System Wiring Guide
TURNSTILE CONTROL SYSTEM Wiring guide Arm dropping (Input) Crossing confirmation (Output, Normally Open) Crossing confirmation (Input) Output direction start (Input) Input direction start (Input) LED ( - ) Turnstile control system LED direction 1 (Output) LED direction 2 (Output) LED Common (Output) Output latch control (Output 24V 1A) Input latch control... -
Page 9: Packaging Dimensions And Weights Of The Product
Weight of the package AIJGO-34/COMP - 1 . package 112 x 48 x 45 cm 73 kg AIJGO-34/COMP - 2 . package with barrier 100 x 105 x 14 cm 56 kg AIJGO-34/COMP - 2 . package without 100 x 105 x 14 cm... -
Page 10: Assembly Instructions
RFID reader (built-in) Multifunctional unit that can handle cards that comply with most known RFID standards: LF reader (low frequency), 125/134 kHz types: eMarine (EM4100, 4102, 4200), HID ProxCard II, Indala, Indala, Kantech, ISO 18000, ISO 11784/85 HDX, ISO 11784/85 FDX(-B), TI RFID (Tiris, e.g. RI-TRP-R4FF, RI-TRP-W4FF), Casi Rusco, HITAG 1/S, HITAG 2 HF reader (high frequency), 13,56 MHz types: ISO-14443A type of encoders: Mifare Classic (1k/4k), Mifare Ultralight, Mifare DESFire,... - Page 11 Place the gate on the platform (with the cables of the foot electrodes routed through the bottom of the gate) Fix the gate to the platform using the screw nuts and washers supplied Connect the wires of the foot electrodes to be used to the wires of the gate.
- Page 12 Ask a qualified electrician to connect the gate to the EPH network of the building. For information on connecting the fire alarm wiring, see below. Emergency open wiring guide The connectors must be short-circuited and not energised, as this will cause the panel to fail.
- Page 13 Turn on the circuit breaker Put the front cover of the gate back in place and lock it with a key AIf you have also purchased a barrier, unscrew the 6 D-head M8 x 20 screws from the platform and secure the barrier to the platform with them Remove the protecion foil from the foot electrode plates...
-
Page 14: Setting The Operating Direction Of The Tester
SETTING THE OPERATING DIRECTION OF THE TESTER A tester with turnstile can be used in two directions. When passing through, the tester can be on the left or on the right side. The most commonly used solution is to position the tester right-handed and allow the turnstile to rotate freely backwards. I. - Page 15 3 . Enableing free backwards rotation of 4 . Enableing entering in case of a successful the turnstile by suitable connection on the test with appropriate connection control panel of the gate On the gate control panel, connect the fifth Counting from the left side of the gate control quick connector (counting from the left), the panel, leave the eighth quick connector...
- Page 16 II. Settings in the case of a tester positioned to the left of the movement direction and the turnstile rotates freely backwards 1 . RFID reader location When facing the tester, the RFID reader should be positioned to the left in this case. If it is not, unscrew the two screws that hold the reader and move the reader to the left side.
- Page 17 3 . Enableing free backwards rotation of 4 . Enableing entering in case of a successful the turnstile by suitable connection on the test with appropriate connection control panel of the gate On the gate control panel, connect the fourth Counting from the left side of the gate control quick connector (counting from the left), the panel, leave the ninth quick connector marked...
- Page 18 III. Settings in the case of a tester positioned to the right of the movement direction and it is needed to use gate open touch button to move backwards 1 . RFID reader position When facing the tester, the RFID reader should be positioned to the right in this case.
- Page 19 3 . Blocking the free backwards rotation of 4 . Enableing entering in case of a successful the turnstile and enableing the possibility test with appropriate connection to go through the gate after using the touch On the gate control panel, connect the fifth button quick connector (counting from the left), the Counting from the left side of the gate control...
- Page 20 IV. Settings in the case of a tester positioned to the left of the movement direction and it is needed to use gate open touch button to move backwards 1 . RFID reader position When facing the tester, the RFID reader should be positioned to the left in this case.
- Page 21 3 . Blocking the free backwards rotation of 4 . Enableing entering in case of a successful the turnstile and enableing the possibility test with appropriate connection to go through the gate after using the touch On the gate control panel, connect the fourth button quick connector (counting from the left), the Counting from the left side of the gate control...
-
Page 22: Operation Instructions
OPERATION INSTRUCTIONS Step with both feet on the middle of the foot electrode plates When testing a wrist strap/groundable ESD smock system, connect the wrist strap/ groundable ESD smock to the tester socket Place the RFID card you want to use on the RFID reader Touch both halves of the steel touch button at the same time and keep your hand on it while... -
Page 23: Calibration / Verification Guide
An upper resistance limit of 35 MΩ can be set for the measurement of a footwear system, see the PieManager management software description CALIBRATION / VERIFICATION GUIDE Foot electrode calibration / verification Place a measuring electrode on the foot electrode you want to measure and connect it to a resistance decade Place a hand electrode on the right side of the tester’s touch button and connect it to the... - Page 24 Wrist strap/groundable ESD smock connection calibration / verification Connect the wrist strap/groundable ESD smock connection to a resistance decade Place a hand electrode on the right side of the tester’s touch button and connect it to the resistance decade To calibrate / verificate, adjust the knobs on the resistance decade Read your RFID card at the RFID reader of the tester...
- Page 25 Table to evaluate the results Accepted maximum Accepted maximum Calibration / verification Lower limit Expected Upper limit deviation downwards deviation upwards parameters value value value from expected value from expected value Footwear system test - 20% 80 KΩ 100 KΩ 120 KΩ...
- Page 26 D és Tsa. Bt. 2600 Vác, Dr. Csányi László Krt. 83. Hungary Tel. / Fax: +36 27 502 555 +36 27 200 835 E-mail: sales@destsa.hu Web: www.destsa.hu www.dlb.hu...
