Modus StepWatch 5 Quick Start Manual

DO: To charge StepWatch, place it face down on the center of the charger. A light will illuminate when your
StepWatch begins charging.
DON'T: Do not place StepWatch on the edge of the charger. Do not place StepWatch face up on charger.
The StepWatch battery should last more than two weeks when fully charged. A flashing light on the charger
means charging error. If you see this, remove StepWatch, check connections, and place StepWatch back on
charger. Light turns off when fully charged.
When you remove the StepWatch from the charger, the LED lights will indicate the current mode:
2 blue lights: StepWatch is in recording mode
2 purple lights: StepWatch is in idle mode, an app interaction is required to put it back into recording
mode. The Bluetooth radio is on.
All flashing pink: Battery ran out of charge and entered storage mode for more than 24 hours. Device is
not recording. An app interaction is required to put it back into recording mode.
2 white lights: StepWatch is in storage mode and is not recording steps. The Bluetooth radio is off.
This will preserve the battery until the next use. To use StepWatch again, charge StepWatch.
1 green blinking
setup, upload, or charging.
Note: If StepWatch is in recording mode when a low battery forces it into storage mode, it will come back into
recording mode if charged within 24 hours. During the time StepWatch when was in storage mode, data will
show inactivity.
Double tap the back of the StepWatch at any time to display the battery indication lights:
3 green lights for 3 seconds: Battery level is 67%-100%
2 green lights for 3 seconds: Battery level is 34%-66%
1 amber light for 3 seconds: Battery level is 10-33%
1 blinking amber light: Battery level is less than 10%
Instruc(ons for Managing StepWatch 5 Ac(vity Monitor

Charging StepWatch

light: StepWatch is recording, and will blink on each of the first 40 steps detected after

Checking Battery Level

Managing StepWatch 5
Activity Monitor
Page 1 of 3
