COMPACT FRIDGE
User's Manual
ES313066AAK
Congratula ons for choosing this product.
Before using this product for the first
please read the manual carefully
and use the equipment only as described in the manual to avoid hazards and personal injury.
Please retain this manual for future reference.
Applicable model: BCD-106W
CAUTION
Read all precau ons and instr
ns in this manual before using this equipment.
If you have any ques
ns about this product, please consult your supplier in

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCD-106W and is the answer not in the manual?

Questions and answers

Related Manuals for ZNTS BCD-106W

Summary of Contents for ZNTS BCD-106W

  • Page 1 Please retain this manual for future reference. Applicable model: BCD-106W CAUTION Read all precau ons and instr ns in this manual before using this equipment.

  • Page 2: Table Of Contents

    Contents ..........................22 PRECAUTIONS ......................24 HOW TO INSTALL THE LIGHT ..................25 INSTRUCTION OF APPROPRIATE USAGE ............................26 FEATURES ..........................26 FOR YOUR SAFETY ..........................28 INSTALLATION ............................... 30 PARTS ........................31 BASIC PREPARATION ..........................32 HOW TO USE ......................

  • Page 3: Precautions

    PRECAUTIONS The environmentally friendly R600a is used as the refrigerant. R600a has no damaging influence on the ozone layer (ODP), a negligible greenhouse effect (GWP) and is available worldwide. Because of its efficient energy R600a is highly suitable as a coolant for this Special must be taken into due to the coolant's high flammability.
  • Page 4 Children aged from 3 to 8 years allowed to load and unload refrigerating appliances. THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY  The unit is designed only for use with R600a gas as the designated refrigerant.  The refrigerant loop is sealed. Only a qualified technician should attempt to service! ...

  • Page 5: How To Install The Light

    supplies at the rear of the appliance If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its services agent. FAILURE TO ABIDE BY THIS WARNING COULD RESULT IN AN EXPLOSION, DEATH, INJURY AND PROPERTY DAMAGE.

  • Page 6: Instruction Of Appropriate Usage

    INSTRUCTION OF APPROPRIATE USAGE To avoid of food, please respect the following - Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance - Clean regularly surfaces that can come in contact with food and accessible drainage systems - Clean water tanks if they have not been used for 48 h;...

  • Page 7: Features

    4. FEATURES  Energy saving design, low consumption of power  Suitable for long period storing of frozen foodstuffs and freezing fresh foodstuffs  Low noise 5. FOR YOUR SAFETY  Your safety is the most important thing we concerned! Please read this manual carefully and fully understand before operating your appliance.
  • Page 8 This unit uses a flammable refrigerant. If refrigerant leaks and comes in contact with fire or heating part, it will create harmful gas and there is risk of fire. warning Read the USER MANUAL carefully before operation. Further information is available in the USER MANUAL, SERVICE MANUAL, and the like.

  • Page 9: Installation

    6. INSTALLATION The refrigerator should not be placed directly in the sunshine or in the vicinity of heat sources such as stove or steam heaters. Do not put the refrigerator in the places where it is subjected to humidity and water drops.
  • Page 10 There will be some odor of plastics when the refrigerator is opened. This is normal. Please don’t worry about it. You can clean the inner parts of the inside cabinets with warm water and neutral soap or detergent in order to eliminate or lessen the odor.

  • Page 11: Parts

    7. PARTS 1. FREEZER(ICE CREAM) 6. COMPRESSOR BOX 2. THERMOSTAT KNOB 7. MAGNETIC GASKET 3. LAMP SWITCH(10W) 8. RACK-EGG 4. REFRIGERATOR(VEGETABLE) 9. DOOR RAIL 5. REFRIGERATOR SHELF...

  • Page 12: Basic Preparation

    8. BASIC PREPARATION Before Using  All parts are well packed in the factory. Please remove the insertions and adhesive tapes for packaging when the packing box is opened. The cabinet shelf can be easily taken off and adjusted up or down according to your needs.

  • Page 13: How To Use

     Seal food in containers with lids, in plastic wrap or in plastic bags to prevent from drying and mingling of odor. 9. HOW TO USE Temperature Control  Point 0 is power off point when the thermostat is set at this, the compressor stops working, the refrigerator is not performed, and the light in the compartment is off.
  • Page 14 To make ice cubes Fill water into the ice tray to the Slide the ice tray into the freezer about 80% capacity. compartment. When you want to make ice cubes Hold both ends of the ice tray, rapidly, you should set the remove the ice cubes from the thermostat control at 7.
  • Page 15 Defrosting Empty freezer. Set the temperature control to “0”. Remove the frost with the soft If the frost is too thick, please use cloth. the defroster. Note: Do not use sharp tools.

  • Page 16: Leveling The Appl Iance

    10. LEVELING THE APPLIANCE When the refrigerator leans to the left, turn the left front foot clockwise. When the refrigerator leans to the right, turn the right front foot counter- clockwise.

  • Page 17: How To Clean The Unit

    11. HOW TO CLEAN THE UNIT  Exterior Wipe with a damp sudsy cloth, then dry.  Interior Wash either compartment with a baking soda solution (two tablespoon of baking soda to about one liter of warm water). Rinse and dry. ...

  • Page 18: Trouble Shooting

    12. TROUBLE SHOOTING SYMPTOMS CHECKS -The plug is not properly connected. -The power fuse is turned off. When the Refrigerator/Freezer it not -The temperature control is set too low. operating or the food is not sufficient frozen. -The appliance is exposed to direct sun light or installed near a heater.

  • Page 19: Warning

    13. WARNING  Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.  Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.  Do not damage the refrigerant circuit. ...
