- Page 1 INSTRUCTION MANUAL RUNYON DATA SERVICES PATENT PENDING RUNYONDATASERVICES.COM...
- Page 2 CONTENTS Safety Precautions Rhopoint Meter Initial Setup MarSurf PS 10 Meter Initial Setup Cart Setup Enable Remote Control Working With Runyon App/Taking First Reading Terminate Control by Remote Computer RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 3 MarSurf PS 10 and Rhopoint operator’s manuals. 1. Keep the base of the Rhopoint Meter in a safe place when the meter is in use. Store the meter in its base when not in use. Note: If your case is made with custom foam, keep both meters in the cart, and store in the case.
- Page 4 RHOPOINT METER INITIAL SETUP RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 5 RHOPOINT METER Menu SETUP Memory: OFF SELECT SETUP MAKE SURE “Memory” IS: OFF Setup BACK Measurement Menu SELECT GO TO MEASUREMENT MENU RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 6 RHOPOINT METER Measurement BACK Haze: Haze SELECT MAKE SURE “Haze” IS SET TO: Haze Setup BACK Control Menu SELECT GO TO CONTROL MENU RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 7 RHOPOINT METER Control BACK ID: ON SOF/EOF: ON BT Wireless: OFF BT Mode: RC USB Mode: RC SELECT SELECT AND SET AS SHOWN Setup BACK Instrument Setup SELECT ENTER GO TO INSTRUMENT SETUP RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 8 RHOPOINT METER Instrument Setup BACK Power Off: DISABLED USB Charge: 100/500mA Set Date & Time 100/500mA SELECT SET “Power O ” TO: DISABLED SET “USB Charge” TO: 100/500mA SET “Date & Time” CORRECTLY GO “BACK” TO MAIN SCREEN GREAT JOB!
- Page 9 MARSURF PS 10 METER INITIAL SETUP PRESS THE “ON” SWITCH TO POWER ON THE MARSURF PS 10 METER TAP “3 LINES” BUTTON TO ENTER MENU RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 10 MARSURF PS 10 METER SELECT “Parameters” TAP “OK” SELECT “Ra” AND “Rz” ONLY RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 11 MARSURF PS 10 METER SELECT “Export Settings” TAP “OK” SET “Export” TO: Measuring results SET “Export le for measuring results” TO: Replace RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 12 MARSURF PS 10 METER SCROLL DOWN SELECT “Power options” TAP “OK” SET ALL TO: “Never” RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 13 MARSURF PS 10 METER Basic Settings Remote Control TAP “OK” OPTIONAL: YOU MAY SWITCH MILLIMETERS TO INCHES IN “Basic Settings” MAKE SURE “Remote Control” IS CHECKED GREAT JOB! MARSURF PS 10 METER SETUP COMPLETE RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 14 CART SETUP CART CONTENTS LEFT TO RIGHT: RHOPOINT METER, MARSURF PS 10 METER, CART, AND CART HANDLE REMOVE RHOPOINT METER PLACE RHOPOINT METER INTO CART BASE AND SET ASIDE RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 15 CART SETUP MARSURF PS 10 METER INSERT AND POSITION STYLUS REMOVE AND RETAIN SHIPPING CLIP PLACE MARSURF PS 10 PUSH TO LOCK METER INTO CART INTO PLACE RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 16 CART SETUP CONNECT METER CORDS RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 17 CART SETUP SECURE METERS BY INSERTING/TIGHTENING RETAINING RODS Note: Do not overtighten retaining rods They should t snug, but not stressed INSERT HANDLE SECURE WITH WING-NUT RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 18 CART SETUP PRESS THE “ON” SWITCH TO POWER ON THE CART PRESS THE “ON” SWITCH TO POWER ON THE MARSURF PS 10 METER RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 19 CART SETUP ENSURE REMOTE CONTROL IS ACTIVE IF NOT, ENABLE REMOTE CONTROL ON NEXT PAGE BEFORE PROCEEDING TO RUNYON APP RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 20 CART SETUP ENABLE REMOTE CONTROL RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 21 CART SETUP RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 22 RSP DATA SERVICES APP Download and activate Sign-in with the Runyon Data Services App username and password Optional: Set-up “Face ID” for faster login in the future RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 23 Tap on the settings icon in the top right hand corner of the screen Once device is successfully paired, the Select the device needing to be paired grey icon below will appear. Click “Done” to return to the inspections screen RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 24 Note: No elds are required, but listing icon to create new form “Location Name” will be helpful Once all information is lled “CPC Appearance Level” “CPC Exposure Class” out, click “Done” to go back options options to the inspections screen RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 25 Review the reading. Tap “Keep” Tap “Capture Sample” to get to add the reading to the report a reading Here you can review the readings you’ve taken. Tap on a reading to see its location on a map RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 26 “Done” when nished To add a photo, tap “Add Photo”. If you want to take a photo with the camera, tap the camera icon. If you want to use a photo you’ve already taken, tap the gallery icon. RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 27 The report will begin building. This is an example of a report This is an example of a report It can take a few minutes to in PDF form in an Excel spreadsheet complete. When nished, it will open automatically. RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 28 TERMINATE CONTROL BY REMOTE CONTROL MAKE SURE THAT THIS STEP IS COMPLETED PRIOR TO TURNING OFF THE RHOPOINT METER RUNYON DATA SERVICES RUNYONDATASERVICES.COM...
- Page 29 REVISED MARCH 2022 1402 CHASE COURT, CARMEL, IN 46032 855-896-8665 RUNYONDATASERVICES.COM...
