SAFETRON 600 Series Installation Manual

SAFETRON 600 Series Installation Manual

Hide thumbs Also See for 600 Series:

Advertisement

Quick Links

EN
20231030
Installation manual
SAFETRON SL630

Advertisement

loading
Need help?

Need help?

Do you have a question about the 600 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SAFETRON 600 Series

  • Page 1 20231030 Installation manual SAFETRON SL630...
  • Page 2: Installation

    Fire door rating with reference to test report number: PGA11645A_rev1. The test was performed with a single steel door. • When used in fire proof doors solenoid locks in the 600 series must be used in conjunction with a certified door. •...
  • Page 3 PROPERTIES AND TECHNICAL DATA SAFETRON locks in the 600 series are electromechanically controlled solenoid locks in modular design, in power to open or power to lock versions, adjustable for right-/left-hung doors and with or without split function. For more information on areas of use and accessories see www.safetron.com.
  • Page 4: Cable Dimensioning

    CABLE DIMENSIONING Cable of type data/tele/signal with areas between 0.1-0.2 must not be used as power supply for the lock. Safetron does not provide a warranty for installations that do not follow the recommendations. See table below. Recommended minimum cable area between power source (transformer, not passage system) and...
  • Page 5 The handle is activated usually by the access control systems via cables pink / blue. SL630 Double function latch: Power to open Handle: Power to lock (Attention! unlocked without power) SL630 Secure Double function latch: Power to open Handle: Power to open (Attention! locked without power) Installation manual SAFETRON SL630...
  • Page 6 Locked. SET THE LOCK IN UNLOCKED SETTING To set the lock in the unlocked state where both sides are mechanically open, set the functional selector to the position Unlocked. Installation manual SAFETRON SL630...
  • Page 7 Handle activation of the SL630 (pink / blue) is connected through SAFETRON REC. 2. The integrated microswitch from emergency exit device 794 is connected to SAFETRON REC 3. Upon mechanical opening through the emergency exit device the lock is put in an powerless state and thus mechanically open from both sides of the door allowing for re-entry to occur.
  • Page 8 DIMENSIONS Installation manual SAFETRON SL630...
  • Page 9 STRIKE PLATE POSITION DRILLING SCHEME (Lock case depth 75 mm) (Lock case depth 75 mm) Installation manual SAFETRON SL630...
  • Page 10 INSTALLATION R16,5 10 | Installation manual SAFETRON SL630...
  • Page 11 MAINTENANCE MAINTENANCE SAFETRON SOLENOID LOCK • Maintenance should be performed by a trained professional   • Ensure that mounted knobs, handles and cylinders are working satisfactory • Lubricate and make adjustments as necessary • In normal use lubricate the lock housing mechanical parts once a year.
  • Page 12 SAFETRON AB Tel: +46 54 19 02 45 Säterivägen 18 info@safetron.com P.O. Box 2096 www.safetron.com 65002 Karlstad Sweden...

This manual is also suitable for:

Sl630Sl620Sl621
