WWW.CYCROWN.COM
SUPPORT@CYCROWN.COM
CycFree
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CycFree and is the answer not in the manual?

Questions and answers

Jim Lewis
June 13, 2025

How can I adjust the seat

User image 684c90694127f
Jim
June 9, 2025

How do I get a battery charger for my cycrown cycfree?

Summary of Contents for CYCROWN CycFree

  • Page 1 WWW.CYCROWN.COM SUPPORT@CYCROWN.COM CycFree USER MANUAL...
  • Page 2: Table Of Contents

    Contents What’s Included in the Box Installation How to Charge the Battery Drive Modes Display and Buttons For Your Safety Battery Maintenance Storage Scrap Disposal Specification Warranty Contact Us...
  • Page 3 PRODUCT OVERVIEW Gear Lever LCD Display Brake Lever Stem Saddle Handle Bar Hydraulic Suspension Front Fork Bicycle Carrier Front light Taillight Front Mudguard Charging Port On/Off Switch Battery Motor Pedal Disc Brake Slow Release 1x Bike Frame 3x Hex Key 1x Front Wheel 2x Pedal 1x QR Skewer...
  • Page 4: Installation

    Installation Before Installation ● Please read this manual thoroughly and follow its instructions. ● Make sure all parts are intact. ● Do not install the battery or start the computer until the bike is fully installed. ● If you have any questions or can't find the information you need in the manual, please contact us via email.
  • Page 5 Step 2 Handlebar Angle Adjustment To adjust the handlebar angle, Open the quick Make sure the handlebar is perpendicular to the release connecting the handlebar and stem. front wheel. Step 3 Front Wheel Installation Insert the front axle into the wheel hub from one side and After taking out the front wheel, remove the front fork from install the bushings, spacers, safety hooks, spacers, and nuts the fork mount...
  • Page 6 Warnings: ● The disc brake is located on the left side in the direction of riding. ● Make sure the front wheel hub is fully engaged into the front fork drop-outs. ● Ensure that the circumference of the front wheel is completely caught in the drop-outs of the front fork, and tighten the nuts on both sides.
  • Page 7 Step 5 Pedal Installation Press the pedals firmly by hand first. Tighten the Identify the correct side by finding ‘R’ and ‘L’ right pedal clockwise and the left pedal marks on the pedals. counterclockwise. Fully tighten the pedals with a pedal wrench or Push the pedal inward to fold the pedals up or down.
  • Page 8 Step 6 Seat Installation Close the seatpost clamp and make sure Open the QR seatpost clamp and Loosen the seat clamp and adjust the seatpost is held in place. Don’t adjust adjust the seat height by pulling up the seat too high (keep the safety line the seat to an appropriate angle.
  • Page 9: How To Charge The Battery

    Disconnect all cables when charging is complete. Charge your e-bike before the first ride. It takes about 7 hours to fully charge the battery. For your convenience, the battery can also be charged when removed from the CYCROWN CycFree e-bike.
  • Page 10 Battery Safety ● Please fully charge the battery before first use. It takes 7 hours. ● Periodically visually inspect the battery connector and charging cable. ● Always keep the charging environment clean and dry. ● Do not charge the e-bike if there is liquid on the charging port. ●...
  • Page 11: Drive Modes

    Drive Modes Shift Lever Brake Lever On/of Switch Throttle Handlebar Electirc bike display Twist Throttle Drive Modes Twist Throttle Pedal Assist Turn on the LCD smart display and you can switch the speed by twisting the throttle with speed mode from 1 to 5. Display OFF Gear Twist Throttle...
  • Page 12: Display And Buttons

    Display and Buttons Computer display Speedometer Working Current Imperial system: MPH Battery Level PAS Level Total Travel Distance Front Light Front Light & Horn Button ● Press to turn on/off the front light ● Press or hold to activate the horn Horn M Button Increase Button...
  • Page 13 Functions 1. On the display ● Speed, PAS level, Battery level, Fault indicator, Total travel distance, Trip distance, Front light sign, Trip time. 2. Control and Settings ● Power on/off control, Front light on/off control, 6 KM/H walk assist mode control, Wheel diameter setting, Top speed setting, Auto sleep time setting, backlight bright- ness setting, Voltage level setting.
  • Page 14 Functions 3.1 Front Light 3.2 Battery Level 3.3 Multi-Function Section 3.4 PAS Level 3.5 MAX: Trip max. Speed AVG: Average Speed The Meter will Calculate the Real Speed According to the Wheel Diameter and Signal Data 6 KM/H Walk Real-Time Battery Controller Brake...
  • Page 15 Setting P00: Factory reset: When the parameter is adjusted to 10 and then switch to the next menu, All the information will be fully displayed on the screen, Indicating that the data has been restored to the default parameters. P01: Backlight brightness: Level 1 means the darkest and level 3 means the brightest.
  • Page 16 P14: 1-20A Controller current limit value setting, 12A by default, Range: 1A-20A. P15: Controller under-voltage setting. P16: Zeroing: Press and hold the increase button for 5 seconds to reset ODO. P17: Auto-cruise selection, 0 is no auto-cruise, 1 is auto-cruise; The trigger time for auto-cruise is set by the controller..
  • Page 17 Specific Operation Instructions: 1. Change PAS level or speed limit. ● (Assuming it is in PAS drive mode) 1.1 Short press ,PAS level + 1. 1.2 Short press ,PAS level - 1. 2. Switch speed unit. ● Long press ,Switch speed unit. 3.
  • Page 18: For Your Safety

    For Your Safety For safe riding, Please read the following information carefully. Before riding, Be sure to check that your brakes are working properly. Before Your First Ride Check whether the quick-release screws and seat are firm, And whether the brakes ●...
  • Page 19: Battery Maintenance

    ● Be aware of your surroundings and avoid obstacles and unsafe surfaces. ● Ride in the open and flat. Try to avoid slopes or places with many pedestrians. ● Do not ride at high speeds, On uneven terrains, In bad weather or in other unsafe conditions.
  • Page 20: Storage

    The substances inside the battery pose a chemical risk to the environment. The end-of-life disposal recommendation for any CYCROWN product is to dispose of the entire device at an e-waste recycling center or through an e-waste recycling center, Project or facility.
  • Page 21: Specification

    Specification Item Meaning Model Name CycFree Net Weight 82.5 LB / 37.4 KG Product Dimensions 68.1*24.4*53.1 IN / 1730×620×1350 MM Package Dimensions 57*11*29.5 IN / 1450*280*750 MM Max. Incline 11° (Rider Weighs 220.4 LBS / 100 KG) Max. Capacity 330 LBS / 150 KG Max.
  • Page 22: Warranty

    Immersion, High temperature, And earthquake. 7. Loss of wearing parts, Such as packaging materials and various technical materials. 8. Other failures or damages not caused by product design, Technology, Manufacturing, Quality, Or other issues. 9. Not purchased from the CYCROWN online store.
  • Page 23: Contact Us

    Contact Us If you have issues with riding, Maintenance and safety, Or faults/failures with the CYCROWN CycFree electric bike, Please contact us. E-mail Service: support@cycrown.com www.cycrown.com...
