ViewSonic A90 Specifications page 2

19" (18.0" VIEWABLE) GRAPHICS SERIES MONITOR WITH
CRT
Type
Phosphor
Glass Surface
INPUT SIGNAL
Video
Sync
Frequency
COMPATIBILITY PC
*
Mac ®
CONNECTOR Signal
Power
POWER Voltage
Consumption
USER CONTROLS Basic
OnView ®
VIDEO INPUT Bandwidth
MISCONVERGENCE
DISPLAY AREA
Factory Setting
Maximum Scan
OPERATING Temperature
CONDITION
Humidity
DIMENSIONS Physical
WEIGHT Net
OTHER
REGULATIONS
POWER MANAGEMENT
WARRANTY
381 Brea Canyon Road, Walnut, CA 91789 • Phone (800) 888-8583 • (909) 869-7976
Fax (909) 869-7958 • Internet: www.ViewSonic.com
†
*Free universal Mac ® cable adapter available. Compared to conventional CRT monitors, results may vary.
Copyright © 1999, ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are the property of their respective companies.
Specifications subject to change without notice. The EPA only promotes energy efficiency and does not endorse any particular company or product.
Microsoft, Windows, Windows NT and the Windows logo are the registered trademarks of Microsoft Corporation in the United States and other countries.
VSA90-1;6/99-50-rev1
V i e w S o n i c A 9 0
A
S ERIES
19" (18.0" diagonal viewable area)
0.23mm horizontal / 0.27mm diagonal dot pitch,
90˚deflection
RGB medium persistence
Tint (TM=46%) ARAG ® screen treatment
RGB analog (Impedance 0.714Vp-p, 75 ohms)
H/V Separate (TTL) composite, sync-on-green
F h :30-86kHz, F v :50-180Hz
IBM ® PC and PC compatible
(from VGA up to 1,600 x 1,280 non-interlaced)
Power Mac (up to 1600 x 1200)
™
15-pin mini D-sub (attached cable)
3-pin plug (IEC320)
AC 88–132V/180-264VAC 50/60 Hz (auto switch)
135W (typ)
Power on/off, Key–1, Key–2, down, up
Contrast, brightness, H/V-position, H/V-size, pincushion,
degauss, pin-balance, trapezoid, ViewMatch
parallelogram, tilt, ViewMeter ® , language select,
OSD position, moiré, Data recall
179MHz (typ)
0.3mm (max) at center
0.4mm (max) at corner
360mm(H) x 270mm(V) (typ)
365mm(H) x 275mm(V)
32˚F to 104˚F (0˚C to 40˚C)
5% to 95% (no condensation)
452mm (W) x 450mm (H) x 465mm (D)
(17.8" x 17.7" x 18.3")
21Kg (46.2 lbs.)
DDC1 & DDC2B
UL, CSA, FCC-B, DHHS, MPR-II, Energy Star
DOC-B, CE
Meets Energy Star ® , VESA ® DPMS ™ standards
Three year limited warranty on CRT, parts and labor
48 hour Express Exchange ® Service option available
• OnView
ViewMatch
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows the
user to adjust color temperature and individual
color intensity for screen-to-print matching.
• SuperClear
This SuperClear screen technology delivers "power
color" images that are up to 25%
conventional CRT monitors and up to 10%
improved color fidelity. This provides vivid, realistic
color and optimized clarity.
• ARAG ®
This specially formulated anti-reflection, anti-glare
screen treatment uses a multi-layer process to
refract unwanted light away from the user while
maintaining the highest quality of the displayed
image.
• MPR-II and Energy Star
This monitor surpasses these strict standards for
reduced emissions, power consumption and
efficiency..
•
Fully supports the Windows
® color,
standard for easy, trouble-free configuration
and setup.
• PC and Mac
• Three year limited warranty
® ,
® controls including
®
™ screen
†
brighter than
†
screen treatment
®
compliant
auto-installation
®
® compatible
