Page 1 2023 Technical Service Manual Snow Plows & Spreaders...
Page 2 Additional Support Information Meyer is here to help! Please access the below resources for additional support. Meyer Website Support Documents EZ Troubleshooter Access the Meyer Parts Information, Interactive tool helps website for Technical Documents diagnose snow plow 24/7 support & Owner’s Manuals problems quickly Meyer Dealer &...
Page 3 Table of Contents Operation Matrix 1-12 E-47 & E-57 13-27 E-60 28-39 E-58 40-45 E-68 46-53 V-70 & V-70H 54-76 V-71 77-96 E-70 97-103 E-72 & E-73 104-109 V-73 110-115 SB-73 116-121 Snow Plow Lights 122-155 Harness Pinout 156-161 S.O.S Conversion Kits 162-170 Recommended Ignition Source 171-182...
Page 4 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | E E - - 4 4 7 7 , , E E - - 5 5 7 7 , , E E - - 6 6 0 0 E-57 ANGLE ANGLE...
Page 5 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | E E - - 5 5 8 8 , , E E - - 6 6 1 1 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | E E - - 5 5 8 8 , , E E - - 6 6 1 1 E-58 ANGLE...
Page 6 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | E E - - 7 7 0 0 E-70 ANGLE ANGLE E-70 RAISE...
Page 7 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | E E - - 7 7 2 2 E-72 ANGLE ANGLE E-72 RAISE...
Page 8 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | E E - - 6 6 8 8 , , E E - - 8 8 8 8 E-68 ANGLE ANGLE...
Page 9 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | V V - - 6 6 6 6 V-66 RIGHT RIGHT LEFT LEFT...
Page 10 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | V V - - 6 6 8 8 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | V V - - 6 6 8 8 V-68 RIGHT RIGHT...
Page 11 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | V V - - 7 7 0 0 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | V V - - 7 7 0 0 V-70 RIGHT RIGHT...
Page 12 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | V V - - 7 7 1 1 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | V V - - 7 7 1 1 V-71 V-71 RIGHT...
Page 13 V73 Hydraulic Unit V73 Hydraulic Unit V73 Hydraulic Unit V73 Hydraulic Unit...
Page 14 SB73 Hydraulic Unit SB73 Hydraulic Unit SB73 Hydraulic Unit SB73 Hydraulic Unit...
Page 15 O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | P P o o w w e e r r A A n n g g l l e e O O p p e e r r a a t t i i o o n n C C h h a a r r t t | | P P o o w w e e r r A A n n g g l l e e ANGLE ANGLE...
Page 16 PARTS BREAKDOWN PARTS BREAKDOWN E-46, E-47 & E-47H E-46, E-47 & E-47H E-57 & E-57H E-57 & E-57H ELECTRO-LIFT ELECTRO-LIFT ® ® STANDARD- STANDARD- LONG STROKE- LONG STROKE- STANDARD- STANDARD- LONG STROKE- LONG STROKE- UP THROUGH UP THROUGH HM-9 & HM-10 HM-9 &...
Page 17 ELECTRO LIFT ® Exploded View Caution: Torque to Caution: 100-125 in.-lbs. Torque to 10 in.-lbs. Caution: Torque to 100-125 in.-lbs. Caution: Torque to Notch on 45-55 in.-lbs. underside Sealant (A2) (D1) Caution: Torque to 100-125 in.-lbs. Backup O Ring O Ring Backup O Ring Backup...
Page 18 IGNITION IGNITION SWITCH SWITCH SWITCH SWITCH RAISE & RAISE & LOWER LOWER BLACK BLACK FUSE FUSE WHITE WHITE BATTERY BATTERY BLACK BLACK SOLENOID SOLENOID SWITCH SWITCH MOTOR MOTOR RAISE RAISE FIGURE 1-1A FIGURE 1-1A...
Page 19 PRESSURE PRESSURE RELIEF RELIEF E-46 & E-46H E-46 & E-46H 1650 + 50 P.S.I. 1650 + 50 P.S.I. CHECK VALVE CHECK VALVE LIFT LIFT CYLINDER CYLINDER "A" "A" SOLENOID SOLENOID - OPERATING - OPERATING FILTER FILTER - RETURN - RETURN - INTAKE or DRAIN - INTAKE or DRAIN TANK...
Page 20 IGNITION IGNITION SWITCH SWITCH SWITCH SWITCH RAISE & RAISE & LOWER LOWER BLACK BLACK FUSE FUSE WHITE WHITE BATTERY BATTERY BLACK BLACK SOLENOID SOLENOID SWITCH SWITCH MOTOR MOTOR LOWER/FLOAT LOWER/FLOAT FIGURE 1-2A FIGURE 1-2A...
Page 21: Cylinder Lift
PRESSURE RELIEF E-46 & E-46H PRESSURE 1650 + 50 P.S.I. RELIEF E-46 & E-46H 1650 + 50 CHECK VALVE P.S.I. CHECK VALVE LIFT CYLINDER "A" LIFT SOLENOID CYLINDER "A" SOLENOID ENERGIZED - OPERATING - RETURN FILTER ENERGIZED - OPERATING - INTAKE or DRAIN - RETURN FILTER...
Page 22 SLIK - STIK ELECTRO -TOUCH SLIK - STIK ELECTRO -TOUCH SINGLE LEVER CONTROLLER SINGLE LEVER CONTROLLER CONTROLLER TO "A" SOLENOID GROUND CONTROLLER (BLACK WIRE) (ORANGE WIRE) POWER TO SWITCH TO "C" SOLENOID TO "A" SOLENOID GROUND (BLACK WIRE) (GREEN WIRE) (ORANGE WIRE) (BLUE WIRE) POWER TO SWITCH...
Page 23 "B" "C" PRESSURE SOLENOID SOLENOID RELIEF E-47 1650 + 50 P.S.I. "B" "C" PRESSURE E-57 ENERGIZED SOLENOID SOLENOID 2000 + 0 P.S.I. RELIEF E-47 1650 + 50 P.S.I. CHECK VALVE CHECK E-57 ENERGIZED VALVE 2000 + 0 P.S.I. FILTER CHECK VALVE CHECK POWER ANGLING VALVE...
Page 24 SLIK - STIK SLIK - STIK ELECTRO -TOUCH ELECTRO -TOUCH SINGLE LEVER CONTROLLER SINGLE LEVER CONTROLLER CONTROLLER CONTROLLER TO "A" SOLENOID GROUND TO "A" SOLENOID GROUND (BLACK WIRE) (ORANGE WIRE) (BLACK WIRE) (ORANGE WIRE) POWER TO SWITCH TO "C" SOLENOID POWER TO SWITCH TO "C"...
Page 25 "C" "B" PRESSURE SOLENOID SOLENOID RELIEF E-47 "C" "B" 1650 + 50 P.S.I. PRESSURE E-57 SOLENOID SOLENOID RELIEF 2000 + 0 P.S.I. E-47 1650 + 50 P.S.I. CHECK VALVE CHECK E-57 2000 + 0 P.S.I. VALVE FILTER CHECK VALVE CHECK POWER ANGLING VALVE CYLINDERS...
Page 26 SLIK - STIK ELECTRO -TOUCH SLIK - STIK ELECTRO -TOUCH SINGLE LEVER CONTROLLER SINGLE LEVER CONTROLLER CONTROLLER CONTROLLER TO "A" SOLENOID GROUND (BLACK WIRE) TO (ORANGE WIRE) TO "A" SOLENOID GROUND "C" SOLENOID POWER TO SWITCH (BLACK WIRE) TO (ORANGE WIRE) (BLUE WIRE) (GREEN WIRE) "C"...
Page 27 "C" "B" PRESSURE SOLENOID SOLENOID RELIEF E-47 1650 + 50 P.S.I. ENERGIZED "C" "B" E-57 PRESSURE ENERGIZED SOLENOID 2000 + 0 P.S.I. SOLENOID RELIEF E-47 CHECK VALVE CHECK 1650 + 50 P.S.I. ENERGIZED E-57 VALVE ENERGIZED 2000 + 0 P.S.I. FILTER CHECK VALVE CHECK...
Page 28 SLIK - STIK ELECTRO -TOUCH SINGLE LEVER CONTROLLER SLIK - STIK ELECTRO -TOUCH CONTROLLER SINGLE LEVER CONTROLLER TO "A" SOLENOID GROUND (BLACK WIRE) TO (ORANGE WIRE) "C" SOLENOID POWER TO SWITCH CONTROLLER (GREEN WIRE) (BLUE WIRE) TO "A" SOLENOID GROUND TO "B"...
Page 29 "B" "C" PRESSURE SOLENOID SOLENOID RELIEF E-47 1650 + 50 P.S.I. E-57 ENERGIZED ENERGIZED "B" "C" 2000 + 0 P.S.I. PRESSURE SOLENOID SOLENOID RELIEF CHECK VALVE CHECK E-47 1650 + 50 P.S.I. VALVE E-57 FILTER ENERGIZED ENERGIZED 2000 + 0 P.S.I. POWER ANGLING CHECK VALVE CHECK...
Page 30 WHITE WHITE SWITCH WHITE WHITE WHITE WHITE IGNITION IGNITION RAISE SWITCH SWITCH SWITCH & SWITCH LOWER WHITE WHITE SWITCH ANGLE SWITCH ANGLE IGNITION IGNITION RAISE RAISE SWITCH SWITCH & SWITCH & LOWER LOWER BLACK BLACK BLACK BLACK FUSE FUSE SWITCH ANGLE SWITCH ANGLE RAISE WHITE...
Page 31 PARTS & INSTALLATION INSTRUCTIONS PARTS & INSTALLATION INSTRUCTIONS E-60 & E-60H QUIK LIFT® E-60 & E-60H QUIK LIFT® STANDARD- LONG STROKE- STANDARD- LONG STROKE- STANDARD- LONG STROKE- STANDARD- LONG STROKE- UP THROUGH UP THROUGH MDII MDII UP THROUGH UP THROUGH MDII MDII HM-9 &...
Page 32 QUIK-LIFT E-60 and E-60H ® Exploded View NOTE: E-60 - ITEM #2 1-1/4" RAM ASSEMBLY 15706 IS STILL AVAILABLE. NOTE: E-60 - ITEM #2 RAM ASSEMBLY HAS CHANGED and IS NOW 1-3/4" ITEM PART NO. DESCRIPTION LIFT RAM ASSEMBLY IS PART NO.15335 15690 PISTON 15691...
Page 33 When the Up arrow is activated, electric power is sent to both the RAISE E-60 and E-60H When the Up arrow is activated, electric power is sent to both the RAISE E-60 and E-60H MOTOR & “B” Solenoid via wiring harness. MOTOR &...
Page 34 P .A. VALVE BLOCK E-60 AND E-60H P .A. VALVE BLOCK E-60 AND E-60H RAISE FLOW "B" SOLENOID RAISE FLOW CHART ENERGIZED "B" SOLENOID CHART ENERGIZED PRESSURE LIFT PILOT RELIEF VALVE CYLINDER CHECK 2500 P.S.I. VALVE PRESSURE LIFT PILOT RELIEF VALVE CYLINDER CHECK 2500 P.S.I.
Page 35 LOWER / FLOAT E-60 and E-60H When the DOWN arrow is activated, electric power is sent LOWER / FLOAT E-60 and E-60H When the DOWN arrow is activated, electric power is sent only to the “A” Solenoid via wiring harness. Electrical power only to the “A”...
Page 36 P .A. VALVE BLOCK P .A. VALVE BLOCK E-60 AND E-60H E-60 AND E-60H LOWER / FLOAT LOWER / FLOAT FLOW CHART FLOW CHART PRESSURE LIFT PILOT RELIEF VALVE CYLINDER CHECK 2500 P.S.I. PRESSURE VALVE LIFT PILOT RELIEF VALVE CYLINDER CHECK 2500 P.S.I.
Page 37 When the Left arrow is activated, electric power is sent only ANGLE LEFT E-60 and E-60H When the Left arrow is activated, electric power is sent only ANGLE LEFT E-60 and E-60H to the MOTOR Solenoid via wiring harness. to the MOTOR Solenoid via wiring harness. When the Electro-Touch®...
Page 38 P .A. VALVE BLOCK E-60 AND E-60H P .A. VALVE BLOCK E-60 AND E-60H ANGLE LEFT FLOW CHART ANGLE LEFT FLOW CHART PRESSURE LIFT PILOT RELIEF VALVE CYLINDER CHECK 2500 P.S.I. VALVE PRESSURE LIFT PILOT RELIEF VALVE CYLINDER CHECK 2500 P.S.I. VALVE CROSS-OVER RELIEF VALVE...
Page 39 When the Right arrow is activated, electric power is sent ANGLE RIGHT E-60 and E-60H When the Right arrow is activated, electric power is sent ANGLE RIGHT E-60 and E-60H to the MOTOR & “C” Solenoid via wiring harness. to the MOTOR & “C” Solenoid via wiring harness. When the Electro-Touch®...
Page 40 P .A. VALVE BLOCK E-60 AND E-60H P .A. VALVE BLOCK ANGLE RIGHT E-60 AND E-60H "C" SOLENOID ENERGIZED FLOW CHART ANGLE RIGHT "C" SOLENOID ENERGIZED FLOW CHART PRESSURE LIFT PILOT RELIEF VALVE CYLINDER CHECK 2500 P.S.I. VALVE PRESSURE LIFT PILOT RELIEF VALVE CYLINDER...
Page 41 Form No. 1-877 R2 PARTS & INSTALLATION INSTRUCTIONS 15995 E-58H Unit Only Hydraulic Carton PARTS LIST Part No. QTY Description 15995 E-58H Hydraulic Unit 15630 • E-58H Cover 15631 • Cover Strap 08128 • Adapter Kit 15912 •• Connector Adapter 22652 ••...
Page 42: Parts List Parts List
Form No. 1-868 R2 Form No. 1-868 R2 PARTS & INSTALLATION INSTRUCTIONS PARTS & INSTALLATION INSTRUCTIONS 15967 P .A. Block Kit E-47/E-57/E-58/E-60/E-61/E-78 15967 P .A. Block Kit E-47/E-57/E-58/E-60/E-61/E-78 PARTS LIST PARTS LIST Part No. Part No. Description Description 1 5 9 6 7 1 5 9 6 7 P.A.
Page 43 Form No. 1-819 R7 PARTS & INSTALLATION INSTRUCTIONS E-58H ELECTRO-LIFT UNITS ® PARTS LIST ITEM E-58H E-58H New QTY DESCRIPTION ITEM E-58H QTY DESCRIPTION 15967 15967 • Valve Assy. (12V) 15869 Pump & Motor Assy. (12 volt) --------- --------- • Coupler, Female Half (OPTIONAL) 15727 •...
Page 44 EXPLODED VIEW EXPLODED VIEW E-58H New Block E-58H New Block Hose Hose P.S. Ram P.S. Ram "B" "B" Red Wire Red Wire (Left Angle) (Left Angle) (Raise) (Raise) "C" "C" Green Wire Green Wire "A" "A" (Right Angle) (Right Angle) Black Wire Black Wire (Lower/Float)
Page 45: Valve Assembly
E-58H Raise, Motor and “B” Solenoid E-58H Raise, Motor and “B” Solenoid RAISE POWER ANGLING CYLINDERS RAISE PUMP CHECK VALVE POWER ANGLING CYLINDERS ENERGIZED PUMP FILTER PUMP PRESSURE PORT CHECK VALVE ENERGIZED ENERGIZED PUMP PRESSURE RELIEF VALVE FILTER NON ADJUSTABLE PRESSURE PORT OPENS at 2000 + 50 P.S.I.
Page 46 E-58H Lower, “A” Solenoid E-58H Lower, “A” Solenoid LOWER POWER ANGLING CYLINDERS PUMP CHECK VALVE LOWER ENERGIZED PUMP POWER ANGLING CYLINDERS FILTER PRESSURE PORT ENERGIZED PUMP CHECK VALVE PRESSURE RELIEF VALVE ENERGIZED PUMP NON ADJUSTABLE OPENS at 2000 + 50 P.S.I. FILTER PRESSURE PORT ENERGIZED...
Page 47 E-58H Angle Left, Motor only E-58H Angle Left, Motor only ANGLE LEFT POWER ANGLING CYLINDERS PUMP ANGLE LEFT CHECK VALVE ENERGIZED POWER ANGLING PUMP CYLINDERS FILTER PRESSURE PORT PUMP ENERGIZED CHECK VALVE PRESSURE RELIEF VALVE ENERGIZED PUMP NON ADJUSTABLE FILTER OPENS at 2000 + 50 P.S.I.
Page 48 E-58H Angle Right, Motor and “C” Solenoid E-58H Angle Right, Motor and “C” Solenoid ANGLE RIGHT POWER ANGLING CYLINDERS PUMP ANGLE RIGHT CHECK VALVE ENERGIZED POWER ANGLING PUMP CYLINDERS FILTER PRESSURE PORT PUMP ENERGIZED CHECK VALVE ENERGIZED PUMP PRESSURE RELIEF VALVE NON ADJUSTABLE FILTER OPENS at 2000 + 50 P.S.I.
Page 49: Parts Breakdown
PARTS BREAKDOWN ITEM PART NO. QTY DESCRIPTION ITEM PART NO. DESCRIPTION 15941 • Valve Assy. w/Coup. (12V) 15869 Pump & Motor Assy. (12 volt) 22445 • Coupler, Female Half 15727 • Motor - 12 Volt (2 Terminal) 22442 • Coupler, Male Half 15889 •...
Page 50: Exploded View
Caution: Torque to 100-125 in.-lbs. Caution: Torque to 100-125 in.-lbs. Caution: Torque to 45-55 in.-lbs. GROOVES Sealant FACE DOWN (A2) (D1) Caution: Torque to 100-125 in.-lbs. ADJUSTABLE Caution: Torque to 75-85 in. lbs. E-68 Exploded View (94) FIGURE 3-1 Cross-Over Relief Valve. NON ADJUSTABLE...
Page 51 E-68 Mount, Motor Only E-68 Mount, Motor Only MOUNT PUMP MOUNT CHECK VALVE PUMP POWER ANGLING FILTER CYLINDERS PUMP PRESSURE PORT CHECK VALVE PUMP PRESSURE RELIEF VALVE NON ADJUSTABLE POWER ANGLING FILTER CYLINDERS OPENS at 2000 + 50 P.S.I. PRESSURE PORT "B"...
Page 52 E-68 Dismount, Motor and “E” Solenoid E-68 Dismount, Motor and “E” Solenoid DISMOUNT DISMOUNT PURPLE "ENERGIZED" (TAN WIRE GROUND) PURPLE "ENERGIZED" (TAN WIRE GROUND) PUMP PUMP CHECK VALVE CHECK VALVE POWER ANGLING POWER ANGLING PUMP CYLINDERS PUMP CYLINDERS FILTER PRESSURE PORT FILTER PRESSURE PORT PRESSURE RELIEF VALVE...
Page 53 E-68 Raise, Motor and “B” Solenoid E-68 Raise, Motor and “B” Solenoid RAISE RAISE RED "ENERGIZED" (TAN WIRE GROUND) RED "ENERGIZED" (TAN WIRE GROUND) PUMP PUMP CHECK VALVE CHECK VALVE PUMP PUMP RED WIRE POWER ANGLING RED WIRE FILTER POWER ANGLING CYLINDERS "ENERGIZED"...
Page 54 E-68 Lower, “A” Solenoid E-68 Lower, “A” Solenoid LOWER/FLOAT BLACK "ENERGIZED" (TAN WIRE GROUND) LOWER/FLOAT PUMP BLACK "ENERGIZED" (TAN WIRE GROUND) CHECK VALVE PUMP POWER ANGLING PUMP FILTER CYLINDERS CHECK VALVE PRESSURE PORT PUMP POWER ANGLING PRESSURE RELIEF FILTER CYLINDERS VALVE- NON ADJUSTABLE PRESSURE PORT 2000 P.S.I.
Page 55 E-68 Angle Left, Motor and “D” Solenoid E-68 Angle Left, Motor and “D” Solenoid LEFT ANGLE YELLOW "ENERGIZED" (TAN WIRE GROUND) PUMP LEFT ANGLE YELLOW "ENERGIZED" (TAN WIRE GROUND) CHECK VALVE PUMP POWER ANGLING FILTER PUMP CYLINDERS PRESSURE PORT CHECK VALVE PUMP PRESSURE RELIEF VALVE POWER ANGLING...
Page 56: Right Angle
E-68 Angle Right, Motor and “C” Solenoid E-68 Angle Right, Motor and “C” Solenoid RIGHT ANGLE GREEN "ENERGIZED" (TAN WIRE GROUND) RIGHT ANGLE PUMP GREEN "ENERGIZED" (TAN WIRE GROUND) CHECK VALVE GREEN WIRE "ENERGIZED" PUMP PUMP FILTER POWER ANGLING PRESSURE PORT CHECK VALVE GREEN WIRE CYLINDERS...
Page 57 PARTS & INSTALLATION INSTRUCTIONS V-70 ELECTRO-LIFT UNIT ® Parts List ITEM V-70 12V V-70 24V QTY DESCRIPTION 15092 15091 Lift Assembly (Unit Only) 15096 15154 • Motor - (2 Terminal) 15097 15097 • Pump Assembly 15083 15083 • Allen Head Screw 1/4-20 x 3" 15101 15101 •...
Page 58 V-70 Exploded View FIGURE 3-1 COIL COLOR CODE S1 - Red wire S2 - Black wire S3 - Green wire S5 - Yellow wire S6 - Blue w/White stripe S7 - Purple wire Ground Wire each Coil Black w/white stripe RAISE - Motor Solenoid + S1 + S2 LOWER - S1 + S2 + S3 LEFT ANGLE -...
Page 59 Form No. 1-1235 PARTS & INSTALLATION INSTRUCTIONS V-70H ELECTRO-LIFT UNIT ® ITEM PART DESCRIPTION 16031 Lift Assembly (Unit Only) 15096 • Motor - (2 Terminal) 15097 • Pump Assembly 15083 • Allen Head Screw 1/4-20 x 3” 15101 • Pump Filter Assy. 15235 •...
Page 60 V- 70H PARTS BREAKDOWN RAISE = Motor Solenoid + S1 + S2 COIL COLOR CODE LOWER = S1 + S2 + S3 S1 - Red Wire LEFT ANGLE = Motor Solenoid Only S2 - Black Wire LEFT EXTEND = Motor Solenoid + S5 S3 - Green Wire LEFT RETRACT = Motor Solenoid + S7 S5 - Yellow Wire...
Page 61: General Information
GENERAL INFORMATION GENERAL INFORMATION Before the Meyer Electro-Lift unit is disassembled for repairs, make certain that all the maintenance Before the Meyer Electro-Lift ® unit is disassembled for repairs, make certain that all the maintenance ® procedures have been checked; refer to Owner's Manual. When the unit is to be overhauled, Seal Kit Part procedures have been checked;...
Page 62 V-70 Raise: Motor, “S1” and “S2” V-70 Raise: Motor, “S1” and “S2” RAISE RAISE PILOT CHECK PILOT 2900 P.S.I. VALVE CHECK RELIEF 2900 P.S.I. RESERVOIR VALVE VALVE RELIEF RESERVOIR VALVE LEFT WING LEFT WING RESERVOIR RESERVOIR PILOT PILOT CHECK CHECK VALVE VALVE RIGHT WING...
Page 63 V-70 Lower: “S1”, “S2” and “S3” V-70 Lower: “S1”, “S2” and “S3” LOWER LOWER PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT WING RESERVOIR PILOT LEFT WING CHECK RESERVOIR VALVE PILOT CHECK VALVE RIGHT WING...
Page 64 V-70 Angle Left: Motor Only V-70 Angle Left: Motor Only ANGLE LEFT ANGLE LEFT PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT WING RESERVOIR PILOT CHECK LEFT WING VALVE RESERVOIR PILOT CHECK RIGHT WING VALVE...
Page 65 V-70 Angle Right: Motor and “S3” V-70 Angle Right: Motor and “S3” ANGLE RIGHT ANGLE RIGHT PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT WING RESERVOIR PILOT CHECK VALVE LEFT WING RESERVOIR PILOT CHECK...
Page 66 V-70 Left Extend: Motor and “S5” V-70 Left Extend: Motor and “S5” LEFT ENERGIZED EXTEND LEFT ENERGIZED EXTEND PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT WING RESERVOIR PILOT CHECK LEFT WING VALVE RESERVOIR PILOT...
Page 67 V-70 Left Retract: Motor and “S7” V-70 Left Retract: Motor and “S7” LEFT ENERGIZED RETRACT PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT ENERGIZED RETRACT LEFT WING RESERVOIR PILOT CHECK PILOT 2900 P.S.I. VALVE CHECK RELIEF VALVE RESERVOIR VALVE RIGHT WING LEFT WING RESERVOIR...
Page 68: Lift Cylinder
V-70 Right Extend: Motor, “S3” and “S6” V-70 Right Extend: Motor, “S3” and “S6” RIGHT EXTEND RIGHT PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR EXTEND VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR LEFT WING VALVE RESERVOIR PILOT CHECK VALVE ENERGIZED LEFT WING RESERVOIR...
Page 69 V-70 Right Retract: Motor, “S3” and “S7” V-70 Right Retract: Motor, “S3” and “S7” RIGHT ENERGIZED RETRACT RIGHT ENERGIZED PILOT CHECK 2900 P.S.I. VALVE RETRACT RELIEF RESERVOIR VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT WING RESERVOIR PILOT CHECK VALVE LEFT WING...
Page 70 V-70 Scoop: Motor, “S2”, “S3”, “S5”, “S6” and “S7” V-70 Scoop: Motor, “S2”, “S3”, “S5”, “S6” and “S7” ENERGIZED ENERGIZED SCOOP ENERGIZED SCOOP ENERGIZED PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT WING RESERVOIR PILOT...
Page 71 V-70 VEE: Motor, “S2”, “S3” and “S7” V-70 VEE: Motor, “S2”, “S3” and “S7” ENERGIZED ENERGIZED PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE PILOT CHECK 2900 P.S.I. VALVE RELIEF RESERVOIR VALVE LEFT WING RESERVOIR PILOT LEFT WING CHECK RESERVOIR VALVE PILOT CHECK...
Page 72: Testing Tips
DIAGNOSTIC FLOW CHART FOR V-70 Unit These charts are intended to be used as an aid in diagnosing problems on the V-68 unit. They are not a substitute for factory training and experience. Be certain to read the General Information and Testing Tips sections before attempting any troubleshooting. IMPORTANT: Maintenance and repairs must be performed with the moldboard on the ground.
Page 73: Operation Chart
Operation Chart | V-70 Operation Chart | V-70 RIGHT RIGHT LEFT LEFT ANGLE ANGLE RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR MOTOR...
Page 74 Operation Chart | V-70 RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR S1 Solenoid Failure Red and Black w/White Stripe No Raise or Lower...
Page 75 Operation Chart | V-70 Operation Chart | V-70 RIGHT RIGHT LEFT LEFT ANGLE ANGLE RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR MOTOR S2 Solenoid Failure...
Page 76 Operation Chart | V-70 Operation Chart | V-70 RIGHT RIGHT LEFT LEFT ANGLE ANGLE RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR MOTOR S3 Solenoid Failure...
Page 77 Operation Chart | V-70 Operation Chart | V-70 RIGHT RIGHT LEFT LEFT ANGLE ANGLE RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR MOTOR S5 Solenoid Failure...
Page 78 Operation Chart | V-70 Operation Chart | V-70 RIGHT RIGHT LEFT LEFT ANGLE ANGLE RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR MOTOR S6 Solenoid Failure...
Page 79 Operation Chart | V-70 Operation Chart | V-70 RIGHT RIGHT LEFT LEFT ANGLE ANGLE RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-70 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR MOTOR S7 Solenoid Failure...
Page 80 PARTS & INSTALLATION INSTRUCTIONS V-71 ELECTRO-LIFT UNIT ® PARTS LIST ITEM V-71 QTY DESCRIPTION 15132 Lift Assembly (Unit Only) 12V • Motor - 12 Volt (2 Terminal) 15070 15097 • Pump Assembly 15083 • Allen Head Screw 1/4-20 x 3" 15101 •...
Page 81 V-71 V-71 Exploded View Exploded View Hydraulic Solenoid Color Code: FIGURE 3-1 Hydraulic Solenoid Color Code: OPERATION - SOLENOID COMBINATION FIGURE 3-1 RAISE - Motor Solenoid + S6 OPERATION - SOLENOID COMBINATION LOWER - S1 RAISE - Motor Solenoid + S6 LEFT ANGLE - Motor Solenoid + S3 + S5 + S8 LOWER - S1 LEFT EXTEND - Motor Solenoid + S2 + S7...
Page 82 V-71 Raise: Motor and “S6” V-71 Raise: Motor and “S6” RAISE RAISE 2900 P.S.I. 2900 P.S.I. RELIEF RELIEF VALVE VALVE PILOT PILOT 2900 P.S.I. CHECK 2900 P.S.I. CHECK RELIEF VALVE RELIEF VALVE VALVE VALVE LIFT CYLINDER LIFT CYLINDER 300 0 0 0 P P.S .S.I.
Page 83 V-71 Lower: “S1” Only V-71 Lower: “S1” Only LOWER LOWER 2900 P.S.I. RELIEF 2900 P.S.I. VALVE RELIEF VALVE PILOT 2900 P.S.I. PILOT CHECK 2900 P.S.I. CHECK RELIEF VALVE RELIEF VALVE VALVE VALVE LIFT CYLINDER LIFT CYLINDER 300 0 0 0 P P.S .S.I.
Page 84 V-71 Angle Left: Motor, “S3”, “S5” and “S8” V-71 Angle Left: Motor, “S3”, “S5” and “S8” ANGLE ANGLE LEFT ENERGIZED LEFT 2900 P.S.I. ENERGIZED RELIEF 2900 P.S.I. VALVE RELIEF VALVE PILOT 2900 P.S.I. CHECK PILOT RELIEF 2900 P.S.I. VALVE CHECK RELIEF VALVE VALVE...
Page 85 V-71 Angle Right: Motor “S2”, “S4” and “S7” V-71 Angle Right: Motor “S2”, “S4” and “S7” ANGLE ANGLE ENERGIZED RIGHT ENERGIZED RIGHT 2900 P.S.I. RELIEF 2900 P.S.I. ENERGIZED VALVE RELIEF ENERGIZED VALVE PILOT 2900 P.S.I. CHECK PILOT RELIEF VALVE 2900 P.S.I. CHECK VALVE RELIEF...
Page 86 V-71 Left Extend: Motor, “S2” and “S7” V-71 Left Extend: Motor, “S2” and “S7” LEFT ENERGIZED EXTEND 2900 P.S.I. LEFT RELIEF ENERGIZED VALVE ENERGIZED PILOT EXTEND 2900 P.S.I. CHECK RELIEF 2900 P.S.I. VALVE VALVE RELIEF ENERGIZED VALVE LIFT CYLINDER PILOT 2900 P.S.I.
Page 87 V-71 Left Retract: Motor and “S3” V-71 Left Retract: Motor and “S3” LEFT ENERGIZED RETRAC 2900 P.S.I. LEFT RELIEF VALVE ENERGIZED PILOT RETRAC 2900 P.S.I. CHECK 2900 P.S.I. RELIEF VALVE VALVE RELIEF VALVE LIFT CYLINDER PILOT 2900 P.S.I. CHECK RELIEF VALVE VALVE 20 3000 00 P...
Page 88 FIGURE 1-7 FIGURE 1-7...
Page 89 V-71 Right Retract: Motor and “S4” V-71 Right Retract: Motor and “S4” RIGHT RIGHT RETRAC T RETRAC T 2900 P.S.I. RELIEF 2900 P.S.I. VALVE RELIEF VALVE PILOT 2900 P.S.I. CHECK PILOT 2900 P.S.I. RELIEF CHECK VALVE RELIEF VALVE VALVE VALVE LIFT CYLINDER LIFT CYLINDER 3000...
Page 90 V-71 Scoop: Motor, “S2”, “S5”, “S7”and “S8” V-71 Scoop: Motor, “S2”, “S5”, “S7”and “S8” SCOOP SCOOP ENERGIZED ENERGIZED 2900 P.S.I. 2900 P.S.I. RELIEF ENERGIZED RELIEF VALVE ENERGIZED VALVE PILOT PILOT 2900 P.S.I. CHECK 2900 P.S.I. CHECK RELIEF VALVE RELIEF VALVE VALVE VALVE LIFT CYLINDER...
Page 91 V-71 VEE: Motor, “S3” and “S4” V-71 VEE: Motor, “S3” and “S4” ENERGIZED ENERGIZED 2900 P.S.I. 2900 P.S.I. RELIEF RELIEF VALVE VALVE PILOT 2900 P.S.I. PILOT CHECK 2900 P.S.I. RELIEF CHECK VALVE VALVE RELIEF VALVE VALVE LIFT CYLINDER LIFT CYLINDER 20 3000 00 P P.
Page 92 DIAGNOSTIC FLOW CHART FOR DIAGNOSTIC FLOW CHART FOR V-71 Unit V-71 Unit These charts are intended to be used as an aid in diagnosing problems on the V-68 unit. They are not a substitute for factory training These charts are intended to be used as an aid in diagnosing problems on the V-68 unit. They are not a substitute for factory training and experience.
Page 93: Operation Chart
Operation Chart | V-71 Operation Chart | V-71 V-71 RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-71 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-71 RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-71 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR...
Page 94 Operation Chart | V-71 Operation Chart | V-71 V-71 RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-71 V-71 RIGHT RIGHT LEFT LEFT ANGLE ANGLE RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP V-71 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR...
Page 95 Operation Chart | V-71 Operation Chart | V-71 V-71 V-71 RIGHT RIGHT RIGHT RIGHT LEFT LEFT LEFT LEFT ANGLE ANGLE ANGLE ANGLE V-71 V-71 RAISE RAISE LOWER LOWER RETRACT RETRACT EXTEN EXTEN RETRACT RETRACT EXTEN EXTEN RIGHT RIGHT LEFT LEFT SCOOP SCOOP MOTOR...
Page 96 Operation Chart | V-71 Operation Chart | V-71 V-71 V-71 RIGHT RIGHT RIGHT RIGHT LEFT LEFT LEFT LEFT ANGLE ANGLE ANGLE ANGLE V-71 V-71 RAISE RAISE LOWER LOWER RETRACT RETRACT EXTEND EXTEND RETRACT RETRACT EXTEND EXTEND RIGHT RIGHT LEFT LEFT SCOOP SCOOP MOTOR...
Page 97 Operation Chart | V-71 Operation Chart | V-71 V-71 V-71 RIGHT RIGHT RIGHT RIGHT LEFT LEFT LEFT LEFT ANGLE ANGLE ANGLE ANGLE V-71 V-71 RAISE RAISE LOWER LOWER RETRACT RETRACT EXTEND EXTEND RETRACT RETRACT EXTEND EXTEND RIGHT RIGHT LEFT LEFT SCOOP SCOOP MOTOR...
Page 98 Operation Chart | V-71 Operation Chart | V-71 V-71 RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-71 V-71 RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-71 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR...
Page 99 Operation Chart | V-71 V-71 RIGHT RIGHT LEFT LEFT ANGLE ANGLE V-71 RAISE LOWER RETRACT EXTEND RETRACT EXTEND RIGHT LEFT SCOOP MOTOR MOTOR...
Page 100 PARTS BREAKDOWN PARTS BREAKDOWN PARTS LIST ITEM E-70 12V E-70 24V QTY DESCRIPTION ITEM E-70 12V E-70 24V QTY DESCRIPTION 15068 15151 • Valve Block Assy.(12V) 15826 16001 Lift Assembly (Unit Only) 15085 15136 •• "A" Solenoid Assembly 15061 15061 •...
Page 101 E-70 Exploded View FIGURE 3-1 E-70 Exploded View FIGURE 3-1...
Page 102 E-70 Raise, Motor and “B” Solenoid E-70 Raise, Motor and “B” Solenoid RAISE RAISE PUMP CHECK VALVE PUMP POWER ENERGIZED CHECK VALVE PUMP ANGLING POWER CYLINDERS ENERGIZED PUMP ANGLING CYLINDERS ENERGIZED ENERGIZED PRESSURE RELIEF VALVE PRESSURE RELIEF VALVE ADJUSTABLE ADJUSTABLE OPENS at 2000 + 50 P.S.I.
Page 103 70 Lower, “A” Solenoid 70 Lower, “A” Solenoid LOWER LOWER PUMP CHECK VALVE ENERGIZED PUMP PUMP CHECK VALVE ENERGIZED PUMP ENERGIZED ENERGIZED PRESSURE RELIEF VALVE ADJUSTABLE OPENS at 2000 + 50 PRESSURE RELIEF VALVE P.S.I. ADJUSTABLE OPENS at 2000 + 50 DUAL P.S.I.
Page 104 E-70 Angle Left, Motor only E-70 Angle Left, Motor only ANGLE LEFT ANGLE LEFT POWER ANGLING POWER ANGLING CYLINDERS CYLINDERS PUMP PUMP CHECK VALVE CHECK VALVE ENERGIZED ENERGIZED PUMP PUMP ENERGIZED ENERGIZED PRESSURE RELIEF VALVE PRESSURE RELIEF VALVE ADJUSTABLE ADJUSTABLE OPENS at 2000 + 50 P.S.I.
Page 105 E-70 Angle Right, Motor and “C” Solenoid E-70 Angle Right, Motor and “C” Solenoid ANGLE RIGHT ANGLE RIGHT POWER ANGLING POWER ANGLING CYLINDERS CYLINDERS PUMP PUMP CHECK VALVE CHECK VALVE ENERGIZED PUMP ENERGIZED PUMP ENERGIZED ENERGIZED PRESSURE RELIEF VALVE PRESSURE RELIEF VALVE NON ADJUSTABLE NON ADJUSTABLE OPENS at 2000 + 50 P.S.I.
Page 106 DIAGNOSTIC FLOW CHART FOR E-70 Unit These charts are intended to be used as an aid in diagnosing problems on the E-70 unit. They are not a substitute for factory training and experience. Be certain to read the General Information and Testing Tips sections before attempting any troubleshooting. IMPORTANT: Maintenance and repairs must be performed with the moldboard on the ground.
Page 107 E72 Hydraulic Unit E72 Hydraulic Unit ITEM PART DESCRIPTION ITEM PART DESCRIPTION 16006 E72 Lift Assembly (Unit Only) 15121 • Adjustable Relief Valve 15070 • Motor (2 Terminal) 15082 • Seal Kit (All Seals) 15097 • Pump Assembly 15150 • Coil (12V) 15083 •...
Page 108 E72 & E73 Hydraulic Unit E72 & E73 Hydraulic Unit...
Page 109 E72 & E73 Hydraulic Unit E72 & E73 Hydraulic Unit E72 & E73 Hydraulic Unit E72 & E73 Hydraulic Unit...
Page 110 V73 Hydraulic Unit V73 Hydraulic Unit V73 Hydraulic Unit V73 Hydraulic Unit ITEM ITEM DESCRIPTION DESCRIPTION ITEM ITEM DESCRIPTION DESCRIPTION 16027 16027 V73 Lift Assembly (Unit Only) V73 Lift Assembly (Unit Only) 15230 15230 • V73 Suction Tube 3/8" • V73 Suction Tube 3/8" 15211 15211 •...
Page 111 Form No. 1-1141 PARTS & INSTALLATION INSTRUCTIONS E-73 ELECTRO-LIFT UNIT ® PARTS LIST ITEM E-73 12V QTY DESCRIPTION 16028 Lift Assembly (Unit Only) 15212SP • Motor (2 Terminal) 15211 • Pump Assembly • Allen Head Screw 1/4-20 x 3" 1 1 5 5 0 0 8 8 3 3 15101 •...
Page 112 E-73 PARTS BREAKDOWN E-73 PARTS BREAKDOWN Hydraulic Solenoid Color Code: Hydraulic Solenoid Color Code: OPERATION - SOLENOID COMBINATION OPERATION - SOLENOID COMBINATION RAISE - Motor Solenoid + B RAISE - Motor Solenoid + B LOWER - A LOWER - A LEFT ANGLE - Motor Solenoid Only LEFT ANGLE - Motor Solenoid Only RIGHT ANGLE - Motor Solenoid + C...
Page 113 V73 Hydraulic Unit V73 Hydraulic Unit ITEM DESCRIPTION ITEM DESCRIPTION 16027 V73 Lift Assembly (Unit Only) 15230 • V73 Suction Tube 3/8" 15211 • Pump Assembly 15231 • V73 Return Tube 3/8" 15083 • Allen Head Screw 1/4-20 x 3" 15101 •...
Page 114 V73 Hydraulic Unit V73 Hydraulic Unit...
Page 115 V73 Hydraulic Unit V73 Hydraulic Unit V73 Hydraulic Unit V73 Hydraulic Unit...
Page 116 V73 Hydraulic Unit V73 Hydraulic Unit...
Page 117 V73 Hydraulic Unit V73 Hydraulic Unit...
Page 118 V73 Hydraulic Unit V73 Hydraulic Unit...
Page 119 SB73 Hydraulic Unit SB73 Hydraulic Unit Item Part Qty Description Item Part Qty Description 16030 1 LIFT ASSEMBLY (UNIT ONLY) 15101 1 • FILTER,SCREEN M-SERIES SUCT. • 15175 1 BASE ASSY,M3593,MOD,3W/4W 15067 1 • PLUG,RESV,BREATHER,3/8 NPT • 15211 1 P ASSY,QM MDLR,DC,BRGS BLD RSV 15066 1 •...
Page 120 SB73 Hydraulic Unit SB73 Hydraulic Unit...
Page 121 SB73 Hydraulic Unit SB73 Hydraulic Unit SB73 Hydraulic Unit SB73 Hydraulic Unit...
Page 122 SB73 Hydraulic Unit SB73 Hydraulic Unit...
Page 123 SB73 Hydraulic Unit SB73 Hydraulic Unit...
Page 124 SB73 Hydraulic Unit SB73 Hydraulic Unit...
Page 125: Parts List
F F o o r r m m 1 1 - - 1 1 2 2 1 1 3 3 MEYER LED SNOW PLOW LIGHTS 12 Volt Kit PARTS LIST ITEM PART NO. QTY. DESCRIPTION 23067 LED Snow Plow Light Carton 23066 •...
Page 126 NOTICE: MEYER PRODUCTS ASSUMES NO RESPONSIBILITY FOR INSTALLATIONS NOT MADE IN ACCORDANCE WITH THESE INSTRUCTIONS. INSTALLATION INSTRUCTIONS Mount the lights (1&2) using supplied hardware. Refer to Figure 1. Note: The wire harness exiting from the light housing should be secured against the metal frame of the plow supports. Fasten the harness so that it will be located near the grill of the vehicle. Figure 1 Verify that installation is correct by turning on the vehicle headlamps, and switching from high to low beam on the vehicle set, then switch over to the plow lamp headlamp set, and check for high and low beam. At any one time, only the plow or vehicle lights should be on, never both sets at once. Verify DRL headlamp function by turning off the vehicle headlamps switch and turning on the ignition key, starting the engine if necessary. You should have DRL function on only one headlamp set (either plow or vehicle, never both). This is true for most installations. Switch over to the other set, and check for proper function. Your Nite Saber LED light kit is fitted with an internal jumper that illuminates the low and high beam when the high beam is activated. If this feature is not desired, the jumper harness can be removed and only the high beam will illuminate. In addition, the heat grid will not activate in high beam mode.
Page 127 Form 1-1208R INSTALLATION INSTRUCTIONS Plow Light Vehicle Harness Part Number 23060 The 23060 harness can be used for vehicles equiped with central hydraulics or any vehicle Meyer does not provide light modules for. When Installing on a Vehicle with Central Hydraulics •...
Page 128 Form 1-1209 Form 1-1209 INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Park/Turn Control Harness Park/Turn Control Harness Part Number 23061 Part Number 23061 Used for... Used for... • 7 pin to 4 pin trailer harness conversion • 7 pin to 4 pin trailer harness conversion •...
Page 133 Form 1-895 Form 1-895 MeYeR SNoW MeYeR SNoW 12 Volt Kit 12 Volt Kit PLoW LIgHTS PLoW LIgHTS PARTS LIST PARTS LIST ITeM ITeM PART No. PART No. QTY. QTY. DeSCRIPTIoN DeSCRIPTIoN 07550 07550 Snow Plow Light Carton Snow Plow Light Carton 07552 07552 •...
Page 134 NoTICe: MeYeR PRoDUCTS ASSUMeS No ReSPoNSIBILITY d) The 12Vdc power must be connected to a switched FoR INSTALLATIoNS NoT MADe IN ACCoRDANCe WITH ignition circuit. Using the red fused (5 amp.) wire NoTICe: MeYeR PRoDUCTS ASSUMeS No ReSPoNSIBILITY THeSe INSTRUCTIoNS. NoTICe: MeYeR PRoDUCTS ASSUMeS No ReSPoNSIBILITY d) The 12Vdc power must be connected to a switched d) The 12Vdc power must be connected to a switched...
Page 135 a) Disconnect the original vehicle’s headlamps. Taking a) Disconnect the original vehicle’s headlamps. Taking Locate vehicle’s marker light wires and turn signal wires Locate vehicle’s marker light wires and turn signal wires one of the adapter harnesses (22), locate the connector one of the adapter harnesses (22), locate the connector on the right side of the vehicle.
Page 137 Snow Plow Lamps Aiming Instructions Snow Plow Lamps Requirements: Aiming Instructions An unobstructed wall that is preferably painted white with minimum dimensions 10 feet (3m) wide by 5 feet (1.5m) high. The vehicle that is having the lamps installed will need to be parked such that the distance from the front of the snow plow lamps Requirements: to the wall is 25 feet (7.6m). The ground of the wall and driveway in which the vehicle is parked must be flat and even. An unobstructed wall that is preferably painted white with minimum dimensions 10 feet (3m) wide by 5 feet (1.5m) high. The vehicle that is having the lamps installed will need to be parked such that the distance from the front of the snow plow lamps Preparation for Headlamp Aim: to the wall is 25 feet (7.6m). The ground of the wall and driveway in which the vehicle is parked must be flat and even. The vehicle must be positioned 25 feet (7.6m) away from the aiming wall. The center of the vehicle must be aligned with the center of the wall. This can be facilitated by using black tape to mark the wall. The wall will require a vertical line that represents Preparation for Headlamp Aim: the center line of the vehicle and the wall (Line 1), and a horizontal line that represents the center line height of the snow plow lamps (Line 2), (reference item i below). The wall will also require two vertical lines bisecting the horizontal line that provide the The vehicle must be positioned 25 feet (7.6m) away from the aiming wall. The center of the vehicle must be aligned with the distance between the snow plow headlamps (Lines 3 left and 4 right). Locate the high beam (inner) bulb on each snow plow center of the wall. This can be facilitated by using black tape to mark the wall. The wall will require a vertical line that represents lamp and project the location onto the front lens with the aid of a small ½" piece of black tape. Then using a tape measure, the center line of the vehicle and the wall (Line 1), and a horizontal line that represents the center line height of the snow plow accurately measure the distance between the black tape left and right bulb centers. Once the distance has been determined, lamps (Line 2), (reference item i below). The wall will also require two vertical lines bisecting the horizontal line that provide the divide the distance by two. This is the distance between Line #1 to Line #3 and Line #1 to Line #4. Reference Figure 5. distance between the snow plow headlamps (Lines 3 left and 4 right). Locate the high beam (inner) bulb on each snow plow Finally, the wall will require a horizontal line that represents the nominal vertical aim position down (Line 5), (reference item j lamp and project the location onto the front lens with the aid of a small ½" piece of black tape. Then using a tape measure, below). Reference Figure 5.
Page 138 Visual Headlamp Aiming Procedure: Activate the snow plow lamp HIGH beams so that they illuminate toward the wall. Reference Figure 6. Focus the left snow plow lamp hot spot beam directly at the cross hair target that is developed by Line 5 and Line 3. There are four bolts that provide vertical aiming of the headlamp. Adjust the lamps accordingly and tighten the bolts. Repeat the same procedure for the right snow plow lamp. The hot spot beam cross hair target that is developed by Line 5 and Line 4. Confirm that each lamp has maintained the correct aiming location. Secure the mounting bolts to the snow plow frame. This completes the headlamp aiming process. Confirm that the headlamps are switched back to the low beam position before operating vehicle. TABLE 1 - VERTICAL BEAM AIM GUIDELINES (LINE 5) Headlamp (centerline) Nominal Mounting Height...
Page 139 07099 Adapter Harness 07099 Adapter Harness...
Page 140 07100 Adapter Harness 07100 Adapter Harness...
Page 141 07101 Adapter Harness 07101 Adapter Harness...
Page 142 07102 Adapter Harness 07102 Adapter Harness...
Page 143 07103 Adapter Harness 07103 Adapter Harness...
Page 144 07104 Adapter Harness 07104 Adapter Harness...
Page 145 07105 Adapter Harness 07105 Adapter Harness...
Page 146 07106 Adapter Harness 07106 Adapter Harness...
Page 147 07180 Adapter Harness 07180 Adapter Harness...
Page 148 07185 Adapter Harness 07185 Adapter Harness...
Page 149 07190 Adapter Harness 07190 Adapter Harness...
Page 150 07213 Adapter Harness 07213 Adapter Harness...
Page 151 07221 Adapter Harness 07221 Adapter Harness...
Page 152 07403 Adapter Harness...
Page 153 07417 Adapter Harness 07417 Adapter Harness...
Page 154 07777 Adapter Harness 07777 Adapter Harness...
Page 155 07744 Adapter Harness 07744 Adapter Harness...
Page 156 07745 Adapter Harness 07745 Adapter Harness...
Page 157 07747 Adapter Harness 07747 Adapter Harness...
Page 158 07333 Adapter Harness...
Page 159 Form No. 1-1263 Form No. 1-1263 23039/23059 Harness Pin Out 23039/23059 Harness Pin Out 23039 23039 Molex 33482-1601 Molex 33482-1601 Cavity Cavity Color Color Function E-73 Function E-73 Function V-73 Function V-73 Function V-73H Function V-73H Function PB-73 Function PB-73 Orange Orange Low Beam Relay...
Page 160 9 10 11 12 13 14 15 16 9 10 11 12 13 14 15 16 23059 23059 Molex 33472-1601 Molex 33472-1601 Cavity Cavity Color Color Function E-73 Function E-73 Function V-73 Function V-73 Function V-73H Function V-73H Function PB-73 Function PB-73 Orange Orange...
Page 161 23059 23059 Tyco 770099-1 Tyco 770099-1 Cavity Cavity Color Color Function E-73 Function E-73 Function V-73 Function V-73 Function V-73H Function V-73H Function PB-73 Function PB-73 Blue Blue Ignition Ignition Ignition Ignition Ignition Ignition Ignition Ignition White White Motor Solenoid Motor Solenoid Motor Solenoid Motor Solenoid...
Page 162 Universal One Piece Harness Plug Universal One Piece Harness Plug Schematic Schematic 22691 VEHICLES SIDE HARNESS 22691 VEHICLES SIDE HARNESS Cavity Color Function E-58H/E-61 Function E-68 Function V-68 Cavity Color Function E-58H/E-61 Function E-68 Function V-68 "B" Solenoid "B" Solenoid S1 Solenoid "B"...
Page 163 22692 (E-58H & E-61), 22694 (E-68) & 22696 (V-68) VEHICLES SIDE HARNESS 22692 (E-58H & E-61), 22694 (E-68) & 22696 (V-68) Cavity Color Function E-58H/E-61 Function E-68 Function V-68 Blue/White Not Used Mount S6 Solenoid VEHICLES SIDE HARNESS Gray Not Used Dis-mount Not Used Purple...
Page 164 One Piece Harness Plug Schematic 22261/22262/22604/22610 Plug Vehicle Side Right Snow Plow Light Left Snow Plow Light Black Blue White Blue White Coil Black Green Black Green Yellow Yellow Coil Green Coil Black Motor Motor Socket Hydraulic Side Right Snow Plow Light Left Snow Plow Light Black White...
Page 165 Form No. 1-1253 Form No. 1-1253 Instructions Instructions 15370 and 15370A 12V Solenoid Starters 15370 and 15370A 12V Solenoid Starters See diagram below for wiring installation of 15370 and 15370A 12V Soldenoid Starters. See diagram below for wiring installation of 15370 and 15370A 12V Soldenoid Starters. Note: For 15370A models ONLY, the mounting bracket must be grounded in order to Note: For 15370A models ONLY, the mounting bracket must be grounded in order to operate.
Page 166 Form No. 1-1-1259 Form No. 1-1-1259 Installation Instructions Installation Instructions Standard Operating System Conversion Kit 08098 Standard Operating System Conversion Kit 08098 GENERAL INFORMATION GENERAL INFORMATION Always disconnect battery prior to installation. Always disconnect battery prior to installation. SAFETY PRECAUTIONS should be used when Quik Lift is in a RAISED position.
Page 167 Step 1: Remove the plus wiring from the hydraulic unit. Step 1: Remove the plus wiring from the hydraulic unit. Step 2: Clamp on Motor Solenoid (2) using Clamp (1) to the hydraulic unit. Step 2: Clamp on Motor Solenoid (2) using Clamp (1) to the hydraulic unit. Step 3: Attach SOS Motor Cable (5) from the Motor Solenoid (2) to the hydraulic unit motor as shown.
Page 168 Step 4: Connect the three coil adapters (7) (red, green and black) to their respective coils. Step 5: Connect the three coil adapters (7) (red, green and black) to the Harness (4) (brown to white, red to red, black to black and green to green). Connect the heavy black wire to the motor ground as shown (A).
Page 169 Step 7: Carefully route the wires so the hydraulic unit cover can be installed. Step 8: To install the SOS vehicle harness (9) route the 12 pin connector (1)into vehicle’s cab and plug into controller. Route the 16 pin connector (2) to the front of the vehicle and plug into the plow side harness.
Page 170 Form No. 1-1260 Form No. 1-1260 Installation Instructions Installation Instructions Standard Operating System Conversion Kit 08487 Standard Operating System Conversion Kit 08487 GENERAL INFORMATION GENERAL INFORMATION Always disconnect battery prior to installation. Always disconnect battery prior to installation. SAFETY PRECAUTIONS should be used when Quik Lift is in a RAISED position.
Page 171 Step 1: Remove the plus wiring from the hydraulic unit. Step 1: Remove the plus wiring from the hydraulic unit. Step 2: Clamp on Motor Solenoid (2) using Clamp (1) to the hydraulic unit. Step 2: Clamp on Motor Solenoid (2) using Clamp (1) to the hydraulic unit. Step 3: Attach SOS Motor Cable (5) from the Motor Solenoid (2) to the hydraulic unit motor as shown.
Page 172 Step 4: Connect the six coil adapters (7) to their respective coils. Step 4: Connect the six coil adapters (7) to their respective coils. Green Green Black Black Blue Blue Yellow Yellow Purple Purple Step 5: Connect the six coil adapters (7) (red, green, black, blue, purple and yellow) to the Harness (4) (brown to white, red to red, black to black, Step 5: Connect the six coil adapters (7) (red, green, black, blue, purple and yellow) to the Harness (4) (brown to white, red to red, black to black, green to green, blue to blue, purple to purple and yellow to yellow).
Page 173 Step 7: Carefully route the wires so the hydraulic unit cover can be installed. Step 8: To install the SOS vehicle harness (9) route the 12 pin connector (1)into vehicle’s cab and plug into controller. Route the 16 pin connector (2) to the front of the vehicle and plug into the plow side harness.
Page 174 Vehicle Manufacturer Recommendations for Key On Ignition Service...
Page 177 Upfitter Circuit Subject: Provisions Models Chevrolet Silverado GMC Sierra Affected: Model Years: 2014 and Beyond Date: March 20, 2014 Revision August 18, 2014 Date: ADVISORY: Condition/Concern: Upfitters may inquire on the new 2014-2015 LD Full-size trucks and for the 2015 HD series as to where to access commonly used circuit for adding aftermarket equipment.
Page 178 Refer to connector pin–out table for connector and terminal part number information (next page).
Page 179 X X 6 6 1 1 A A J J u u n n c c t t i i o o n n B B l l o o c c k k T T o o p p V V i i e e w w...
Page 180 Connector Part Information Connector Part Information Harness Type: Upfitter Harness Type: Upfitter   OEM Connector: 13924036 OEM Connector: 13924036   Service Connector: Kit P/N 19328970 Includes Connector body and Service Connector: Kit P/N 19328970 Includes Connector body and ...
Page 181 Wire Harness Pass-thru location Upfitter Wire Harness Pass-thru...
Page 184 Body Builders Layout Book Body Builders Layout Book ELECTRICAL WIRING ELECTRICAL WIRING 2015 2015 SUPER DUTY F-SERIES SUPER DUTY F-SERIES ELECTRICAL WIRING ELECTRICAL WIRING MODEL YEAR MODEL YEAR CUSTOMER ACCESS SCHEMATICS CUSTOMER ACCESS SCHEMATICS www.fleet.ford.com/truckbbas www.fleet.ford.com/truckbbas...
Page 186 Form 1-984 Form 1-984 Installation Instructions Installation Instructions Part No. 22154 E-58H Controller Part No. 22154 E-58H Controller Installation & Operation Installation & Operation When installing motor solenoid part number 15370 (per form number 1-841) or If motor solenoid is already installed on the vehicle, When installing motor solenoid part number 15370 (per form number 1-841) or If motor solenoid is already installed on the vehicle, the enclosed diode part number 15059, must be connected to the small terminal of the motor solenoid and to the motor solenoid the enclosed diode part number 15059, must be connected to the small terminal of the motor solenoid and to the motor solenoid...
Page 187: Installation Instructions
Form 1-1060 Installation Instructions Part No. 07691 Pistol Grip to Touch Pad Adapter Installation & Operation When replacing a 22690 or 22690X Pistol Grip Controller with a 22154 Touchpad. The adapter pictured below will plug into the vehicle harness and the Touchpad will plug into the opposite end. If the Pistol Grip Controller activated the plow lights the enclosed rocker switch , bracket and wiring will need to be installed.
Page 188 Form 1-887 R3 Form 1-887 R3 Part No. 22690DC Pistol Grip Controller Part No. 22690DC Pistol Grip Controller Installation & Operation Installation & Operation When installing motor solenoid part number 15370 (per form number 1-841) or If motor solenoid is already installed on the vehicle, the enclosed diode part When installing motor solenoid part number 15370 (per form number 1-841) or If motor solenoid is already installed on the vehicle, the enclosed diode part number 15059, must be connected to the small terminal with white wire of the motor solenoid and to the motor solenoid mounting bracket as shown below.
Page 189 Form 1-886 R3 Part No. 22695DC Pistol Grip DLX Controller Installation & Operation When installing motor solenoid part number 15370 (per form number 1-883) or If motor solenoid is already installed on the vehicle, the enclosed diode part number 15059, must be connected to the small terminal white wire of the motor solenoid and to the motor solenoid mounting bracket as shown below. Note: Motor Solenoid must have a good ground in order to operate properly.
Page 190 Form 1-985 R1 Form 1-985 R1 Part No. 22790X Joy Stick DLX Controller Part No. 22790X Joy Stick DLX Controller Installation & Operation Installation & Operation When installing motor solenoid part number 15370 (per form number 1-883) or If motor solenoid is already installed on the vehicle, the enclosed diode part When installing motor solenoid part number 15370 (per form number 1-883) or If motor solenoid is already installed on the vehicle, the enclosed diode part number 15059, must be connected to the small terminal white wire of the motor solenoid and to the motor solenoid mounting bracket as shown below.
Page 191 Form 22869X Part No. 22869X Pistol Grip DLX Controller Installation & Operation When installing motor solenoid part number 15370 (per form number 1-883) or If motor solenoid is already installed on the vehicle, the enclosed diode part number 15059, must be connected to the small terminal white wire of the motor solenoid and to the motor solenoid mounting bracket as shown below. Note: Motor Solenoid must have a good ground in order to operate properly.
Page 192 Form 1-885 R1 22693 Form 1-885 R1 22693 Part No. 22693 Pistol Grip Controller Part No. 22693 Pistol Grip Controller Installation & Operation Installation & Operation When installing motor solenoid part number 15370 (per form number 1-878 or 1-881) or If motor solenoid is already installed on the vehicle, the When installing motor solenoid part number 15370 (per form number 1-878 or 1-881) or If motor solenoid is already installed on the vehicle, the enclosed diode part number 15059, must be connected to the small terminal with white wire of the motor solenoid and to the motor solenoid enclosed diode part number 15059, must be connected to the small terminal with white wire of the motor solenoid and to the motor solenoid...
Page 193 1-1126 1-1126 Part No. 23010 Wireless Snow Plow Controller Kit Part No. 23010 Wireless Snow Plow Controller Kit Installation & Operation Installation & Operation INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS When installing motor solenoid part number 15370 (per form number 1-883) or If motor solenoid is already installed on the vehicle, the enclosed When installing motor solenoid part number 15370 (per form number 1-883) or If motor solenoid is already installed on the vehicle, the enclosed diode part number 15059, must be connected to the small terminal white wire of the motor solenoid and to the motor solenoid mounting bracket as diode part number 15059, must be connected to the small terminal white wire of the motor solenoid and to the motor solenoid mounting bracket as...
Page 194: Operating Specifications
IS175 IS175 Part No. 23010 Wireless Snow Plow Controller Kit Part No. 23010 Wireless Snow Plow Controller Kit To satisfy FCC RF Exposure requirements for mobile and base station transmission devices, a separation To satisfy FCC RF Exposure requirements for mobile and base station transmission devices, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during distance of 20 cm or more should be maintained between the antenna of this device and persons during operation.
Page 195 Form 1-1130 Part No. 23022 Controller Installation & Operation Plow Light Switch SNOW PLOW CONTROLLER OPERATION The snow plow should only be in operation when the vehicle ignition switch and the control switch are in the “ON” position. Care should be taken to insure that the control switch is kept dry and free from moisture during normal operation. Control swith must be turned off when truck is turned off.
Page 196 Form 1-1157 Part No. 23047 Pistol Grip Straight Blade New Standard Operating System Controller Installation & Operation HFP (ALM/ARM) On/Off Raise Imprinted on backside of Controller Systems Monitor LED Read-Out Float Light Flashes Check Coil (wire Color) Angle Left Monitor Continuous Light----Motor Solenoid 1 Light Flash----Red Lower...
Page 197 Form 1-1155 Part No. 23037 Pistol Grip Deluxe Operating System Controller Installation & Operation Monitor Float HFP (ALM/ARM) On/Off Left Right Retract Retract Right Extend Left Extend Raise Imprinted on backside of Controller Scoop Systems Monitor Angle Left LED Read-Out Light Flashes Check Coil (wire Color) Continuous Light----Motor Solenoid Angle Right...
Page 198 - - 5 5 Part No. 23074 Pistol Grip Deluxe V-70 Horizontal Part No. 23074 Pistol Grip Deluxe V-70 Horizontal Operating System Controller Operating System Controller Installation & Operation Installation & Operation SNOW PLOW CONTROLLER OPERATION SNOW PLOW CONTROLLER OPERATION The snow plow should only be in operation when the vehicle ignition switch and the control switch are in the “ON”...
Page 199 SNOW PLOW CONTROLLER OPERATION Hands-Free Plowing or ALM/ARM: Meyer re-branded the ALM/ARM feature on its 23074 controllers to be Hands-Free Plowing (HFP)™. When activated, the Hands-Free Plowing (HFP) mode uses the vehicle’s shift lever to control the up/down movement of the moldboard. Pressing the HFP button on the controller will toggle you through: On/Off, Back-Drag Mode (default mode when active), and Forward Plowing Mode.
Page 200: Electrical Installation
ELECTRICAL INSTALLATION SPEED CONTROLLER 36244 with VIBRATOR (OPTIONAL) PARTS LIST Item Part No. Qty. Description 38009 • Parts included in Misc.Carton 36244 • Speed Control Assembly •• Speed Control •• Mounting Bracket •• Machine Screw, Rd Hd 8-32 x 1” ••...
Page 201 PARTS & INSTALLATION INSTRUCTIONS 36244 Spreader Speed Control Choose a location for the speed control that is convenient for the driver, noting whether mounting bracket will be attached to the top or bottom of speed control. Attach mounting bracket to vehicle. Make certain speed control is grounded by attaching ground wire to a good vehicle ground.
Page 202 PARTS & INSTALLATION INSTRUCTIONS 34403 Spreader Speed Control Choose a location for the speed control that is convenient for the driver, noting whether mounting bracket will be attached to the top or bottom of speed control. Attach mounting bracket to vehicle. See diagram below Brown Speed White...
Page 203 34417 PARTS & INSTALLATION INSTRUCTIONS 34417 Speed Controller Choose a location for the Speed Control that is convenient for the driver. Make certain speed control is grounded by attaching ground wire to a good vehicle ground. Attach the eyelet end of the 96" red wire to the positive terminal of the battery and route the plug end to the location of the speed control.
Page 204 Form 1-990 R1 Form 1-990 R1 Part No. 22808 Speed Controller Part No. 22808 Speed Controller Installation & Operation Installation & Operation INSTALLATION INSTRUCTIONS (2 wire harness) INSTALLATION INSTRUCTIONS (2 wire harness) A. Choose a convenient location to mount A. Choose a convenient location to mount controller (1).
Page 205 INSTALLATION INSTRUCTIONS (4 wire harness) A. Choose a convenient location to mount controller (1). Mount mounting bracket (2) inside vehicle cab using three #10 x 1/2” pan phillips head screws provided. B. Connect Black wire (10) from pigtail (7) to ground. Black Wire must be grounded before connecting any other wires.
Page 206 IS145/1 IS145/1 34405 34405 PARTS & INSTALLATION INSTRUCTIONS PARTS & INSTALLATION INSTRUCTIONS 34405 Speed Controller 34405 Speed Controller The Meyer 34405 Speed Controller is an electronic module powered off the switched ignition circuit +12Vdc and The Meyer 34405 Speed Controller is an electronic module powered off the switched ignition circuit +12Vdc and supplying the heavy motor current from the +12Vdc battery curcuit.
Page 207 34405 CONTROLLER OPERATION 34405 CONTROLLER OPERATION The controller will provide the spreader motor with multiple speed options per the following: The controller will provide the spreader motor with multiple speed options per the following: I/O (On/Off) I/O (On/Off) Depress the button once to enable the spreader motor operation. Depress the button once to enable the spreader motor operation.
Page 208 Meyer Wireless Controller Meyer Wireless Controller The wireless controller is a compact unit with two parts. One part is the Base Unit The wireless controller is a compact unit with two parts. One part is the Base Unit (Receiver) and the other part is the Keyfob (Transmitter). The Keyfob is used to send a (Receiver) and the other part is the Keyfob (Transmitter).
Page 209 “Learn” Button “Learn” Button Programming LED “red” Programming LED “red” (“black” press button) (“black” press button) Antenna (coiled) Antenna (coiled) Male Connector Male Connector Fig. 2: Base Unit layout (Figure shown without Base Unit Cover) Fig. 2: Base Unit layout (Figure shown without Base Unit Cover) Programming the Keyfob and the Base Unit: Programming the Keyfob and the Base Unit: The next step to the wireless controller installation is to create a 1 in 16 million address...
Page 210: Off Road Use Only
Battery Replacement The Keyfob uses a standard CR2032 lithium button cell battery. In normal use it will provide 1 to 2 years of operation. To replace the Keyfob battery, gently press and slide the battery cover off. Remove the battery by sliding it out from underneath the retainer. Observe the battery polarity when replacing (“+”...
Page 211 Standard & Standard Plus Controller Operation OVERVIEW The standard spreader control system offers independent output control for the auger rate and spinner rate. The standard plus spreader control system offers independent output control for the auger rate, spinner rate, and pre-wet flow. OPERATION The vehicle ignition must be turned on in order for the controller to operate.
Page 212 M M e e y y e e r r 6 6 6 6 1 1 9 9 0 0 S S p p r r e e a a d d e e r r C C o o n n t t r r o o l l l l e e r r T T h h e e w w i i r r e e l l e e s s s s g g a a s s o o l l i i n n e e e e n n g g i i n n e e c c o o n n t t r r o o l l l l e e r r i i s s i i n n t t e e n n d d e e d d t t o o c c o o n n t t r r o o l l t t h h e e s s t t a a r r t t / / s s t t o o p p , , t t h h r r o o t t t t l l e e i i n n c c r r e e a a s s e e / / d d e e c c r r e e a a s s e e a a n n d d e e l l e e c c t t r r i i c c c c l l u u t t c c h h o o n n / / o o f f f f f f u u n n c c t t i i o o n n s s O O p p e e r r a a t t i i o o n n...
Page 213 S S y y n n c c h h r r o o n n i i z z i i n n g g T T r r a a n n s s m m i i t t t t e e r r a a n n d d R R e e c c e e i i v v e e r r E E a a c c h h t t r r a a n n s s m m i i t t t t e e r r a a n n d d r r e e c c e e i i v v e e r r p p a a i i r r a a r r e e s s y y n n c c h h r r o o n n i i z z e e d d a a t t t t h h e e f f a a c c t t o o r r y y .
Page 214 AMP DRAW AMP DRAW Hydraulic Model Operating Amps (not in by‐pass) Operating Amps (In by‐pass) Hydraulic Model Operating Amps (not in by‐pass) Operating Amps (In by‐pass) E‐47 125‐140 Amps 200‐230 Amps E‐47 125‐140 Amps 200‐230 Amps E‐57, E‐58, E‐60, E‐68 105‐120 Amps 170‐200 Amps E‐57, E‐58, E‐60, E‐68 105‐120 Amps 170‐200 Amps E‐70, E‐72 115‐130 Amps 185‐215 Amps E‐70, E‐72 115‐130 Amps 185‐215 Amps V‐70, V‐72 135‐145 Amps 215‐240 Amps V‐70, V‐72 135‐145 Amps 215‐240 Amps Spreader Model Spinner Operating Amp Range Spinner Start up Amp Range Vibrator Amp Range Spreader Model Spinner Operating Amp Range Spinner Start up Amp Range Vibrator Amp Range BL 240/400 8‐17 amps 22‐28 amps...
Page 215 Throughout the years, Meyer has remained committed to improving our customers’ performance with dependable solutions and superior service. Meyer is a trusted brand of the Aebi Schmidt Group. Look to Meyer for a full line of commercial snowplows and spreaders.
Page 216 Meyer Products, Inc. 6186731, 6,793,154 B2, 6722590, 6715703, 6978952, 6932287, 8505838, 18513 Euclid Avenue 8827002, 5842649, CA 2,435,106 C, 6364598, 9,127,425, 9,127,425, Cleveland, Ohio 44112 9,371,621, 6,722,590, 6,715,703, 6,932,287, 6,978,252, 9,371,621, 9,085,862, 9,096,979. www.meyerproducts.com Rev. 7/23 ©Aebi Schmidt Group, 2023...

This manual is also suitable for:

Meyer e-57 Meyer e-60 Meyer e-58 Meyer e-68 Meyer v-70 Meyer v-70h ... Show all
