- Page 1 Epos User Manual English English Version V 1.0 May 1, 2023 Epos 300 User Manual www.kelvinlight.com...
-
Page 2: Table Of Contents
2.0 Introduction (Features, Properties) 3.0 Precautions 4.0 Overview 5.0 Setting up Epos 300 5.1 Attaching the Tilt Lock Handle 5.2 Mounting the Epos 300 to a Light Stand 5.3 Powering the Epos 300 6.0 User interface 6.1 User interface overview 6.2 Main menu 6.3 Settings... -
Page 3: Introduction (Features, Properties)
2.5 Function One of the benefits that advocate the Epos 300 is the separation of the light head and the light control unit. The light may be controlled remotely from the Bluetooth, Kelvin Narrator App for iOS/Android, DMX, Lumen Radio/Wireless DMX (built-in) or from the separate control unit, which is operable free standing or suspended from a vertical support. - Page 4 4. In case the cables and wires are damaged, it must be replaced with the same kind of cables and wires; 5. In case the light source is damaged, it can only be serviced by an authorized Kelvin service centre or authorized Kelvin service personnel;...
-
Page 5: Overview
FCC Compliance Statement WARNING Changes or modifications not expressly approved by Kelvin or an authorized service partner will void the warranty. NOTICE 1 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 6 Epos 300 User Manual www.kelvinlight.com...
-
Page 7: Setting Up Epos 300
5.1 Use of Protective Cap To get started using the Epos 300, please remove protection cap. Always remove the cap before turning the light on and always mount the cap back after use when you are packing the light away to ensure your light stays Epos 300 User Manual www.kelvinlight.com... -
Page 8: Attaching The Tilt Lock Handle
5.3 Attaching the Tilt Lock Handle The tilt lock handle can be attached to either side of the Epos 300. To attach the handle, follow these steps: 1. Place the Epos 300 and yoke face down on a flat surface. -
Page 9: Mounting The Epos 300 To A Light Stand
5.3 Mounting the Epos 300 to a Light Stand / Bracket Loosen the mounting lock and place the receiver over the light stand’s 5/8-inch pin (Baby Pin). Tighten the handle until secured with the mounting screw on the Baby Pin Receiver. -
Page 10: Powering The Epos 300
2. Connect the AC cable to the power supply and a power outlet. Battery Power 1. Connect the 4-pin XLR cable to the power supply and the Epos 300 controller. 2. Slide a battery into the power supply’s battery plate until it locks into place. -
Page 11: User Interface
5.6 Turn ON and OFF After achieving power, push the power button on the side of the controller to turn the light ON and OFF. 6.0 User interface Epos 300 Epos 300 User Manual www.kelvinlight.com... -
Page 12: User Interface Overview
3. Right Dial: Tint, Toggle parameter, Menu line 4. Mode Menu (on touch screen) Select modes by selecting from the menu on the top left corner of the screen to choose: CCT, HSI, Gel, RGB, XY, Effects. Epos 300 User Manual www.kelvinlight.com... -
Page 13: Main Menu
Left knob long press, toggles stable between stable and maximum light output. (See Modes and Intensity section for more information.) Touch interface: Menu button, return to the previous light mode. Mode buttons, enter the respective mode. Settings button, enter the Epos settings. Epos 300 User Manual www.kelvinlight.com... -
Page 14: Settings
In master mode the controller generates DMX messages and sends them to connected slaves (wired and/or wirelessly) o Choosing which profile to receive or send ▪ The DMX protocol/profiles are described in a separate document Epos 300 User Manual www.kelvinlight.com... -
Page 15: Intensity And Modes
In this mode the max light output is reduced to 25% in order to protect the lamp head from overheating o Running in silent or quiet mode reduces the max light output in order to protect the lamp head from overheating. 7.0 Intensity and Modes Epos 300 Epos 300 User Manual www.kelvinlight.com... - Page 16 7.1 Intensity The light intensity can be controlled via Bluetooth using the Kelvin Narrator App for iOS/Android, wired DMX, Lumen Radio/Wireless DMX (built-in) or from the separate control unit. The left knob on the controller is dedicated to light intensity throughout, while the intensity touch slider is available on operating screens such as CCT, HSI, Gel, XY and Effects.
- Page 17 Pressing/dragging the HSI color map adjusts the hue (horizontally) and saturation (vertically). Color space dropdown selects color space (Device, S RGB, Adobe 1988, Adobe Wide or Pro Photo). The white point slider adjusts the white point if device color space is selected. 7.4 Mode RGB Epos 300 User Manual www.kelvinlight.com...
- Page 18 Touch control: Color sliders adjust the respective colors. Color space dropdown selects the color space. White point slider adjusts the white point (if device color space is selected). 7.5 Mode XY Epos 300 User Manual www.kelvinlight.com...
- Page 19 Knob control: Middle knob turn adjusts the X parameter (horizontally). Right knob turn adjusts the Y parameter (vertically). Touch control: Pressing/dragging on the CIE-1931 diagram adjusts the X and Y parameters. 7.6 Mode Gel Epos 300 User Manual www.kelvinlight.com...
- Page 20 Brand dropdown selects brand. Category dropdown selects the category within the selected brand. Temperature slider sets the color temperature. 7.7 Mode Effect Epos 300 User Manual www.kelvinlight.com...
- Page 21 Pulses per minute, setting the number of pulses to be generated per minute (speed). Pulse type, selecting the form of the pulse. Sinusoid, logarithmic, exponential, or triangular. Epos 300 User Manual www.kelvinlight.com...
- Page 22 7.14 Touch control: Adjusting sliders. Opening dropdowns and selecting dropdown options. Back button press, returning to the effect menu. Play/pause button pressing, sets the respective effect as active and toggles the effect between play and Epos 300 User Manual www.kelvinlight.com...
- Page 23 9.0 Software and firmware Epos 300 9.1 Kelvin Narrator App Updates of the Kelvin Narrator App are available through the App Store and the Google Play Store. https://www.kelvinlight.com/app-narrator/ 9.2 Firmware Firmware updates are available through the Kelvin Narrator Bluetooth App.
- Page 24 Unknown power source. This condition is caused by invalid power source(s) and results in light output being turned off. The root cause of this condition might be unsupported or damaged batteries or power supply. Make sure to use batteries that meet the specified requirements, or a power supply provided by Kelvin. Epos 300 User Manual...
- Page 25 10.4 Specifications Please see detailed specifications available here including Photometrics: https://www.kelvinlight.com/product/epos_300_full_color_spectrum_rgbacl_led_studio_light/ Epos 300 User Manual www.kelvinlight.com...
-
Page 26: Years Keep Rolling Warranty
Latest updated version available at www.kelvinlight.com. By purchasing a Kelvin light, you will have peace of mind. Your projects are our highest priority, so if anything goes wrong – we make sure you have a light to keep rolling. - Page 27 Us. Furthermore, You are responsible for any shipping costs incurred in returning the Solution and We highly recommended that You use a traceable and insurable form of mail for shipment. Epos 300 User Manual www.kelvinlight.com...
- Page 28 If Your return includes a lithium-ion battery, You agree to have the battery shipped by a certified shipper of dangerous goods. You further agree not to attempt to ship any lithium-ion battery that has been physically damaged. Epos 300 User Manual www.kelvinlight.com...
-
Page 29: Trademarks
Epos 300. There might also be many more that works fine as well. We have also designed several different diffusers for the Epos 300, so that it is possible to fine tune the quality of light when using it in combination with other modifiers. -
Page 30: Wireless Communication
14.0 Wireless Communication Epos 300 Bluetooth communication with Kelvin Narrator app Module: Raytac MDBT50 p/n: MDBT50Q-U1MV2 (containing Nordic nRF52840 SoC) Frequency: 2.4 GHz RF output: -20dBm (100mW) LumenRadio Wireless DMX and RDM Chip: LumenRadio TimoTwo p/n: 800-8107 Frequency: 2.402 ~ 2.480 GHz...
