Function keys and I/O interfaces:
2
3
1
Ref Component
1) SD/MMC Slot
2) Volume key
3) Battery Charge
Indicator
4) Touch Screen
5) On/Off Button
6) Reset button
7) Headphone connector
8) Mini-USB- Connector
9) Main switch/
Battery switch
10) External antenna
connector
11) Loudspeaker
GPS NAVIGATION NAV740
4
9
Description
Accepts an optional SD (Secure Digital) or MMC (MultiMedia Card) card for removable storage.
Turns the volume up/down.
The loading display will shine red during the charging process. It will shine green when the battery
is completely charged.
Displays the output of your appliance. Tap on the screen with your finger to select menu commands
or enter data.
Turns the device on or off.
Restarts your appliance. (Reset).
Connects to stereo headphones.
Connection for connecting power charge.
For battery charge.
Connector for an optional external GPS antennal.
Plays back music, language statements and warnings.
Quick Start Guide
5
10
6
7
8
11
1
Advertisement
Table of Contents
Related Manuals for V7 NAV740
Summary of Contents for V7 NAV740
- Page 1 GPS NAVIGATION NAV740 Function keys and I/O interfaces: Ref Component Description 1) SD/MMC Slot Accepts an optional SD (Secure Digital) or MMC (MultiMedia Card) card for removable storage. 2) Volume key Turns the volume up/down. 3) Battery Charge The loading display will shine red during the charging process. It will shine green when the battery Indicator is completely charged.
-
Page 2: Initial Setup
Initial Set up: 1.Switching on the navigation system Remove the protective plastic from the screen and ensure the main power switch on the buttom side of the unit is in the ON position. ttention: Always leave the main switch in the ON position. The switch should only be set in the OFF position to preserve battery charge if the unit is to be stored for an extended period of time. -
Page 3: Find An Address
The Map On the tab, you can specify your destination as an Address, a POI (Point of Interest), or by its GPS Coordinates. You may also select a destination from Favorites, or one of your recently visited destinations from the History list. - Page 4 Use the buttons to see additional results. After the city and street are selected, you may now enter the house number. The range of available house numbers will be displayed. to select a cross street, or Use the keyboard to enter the house number, and tap You have now finished setting the destination.
-
Page 5: The Map Screen
Overview , 2D North-up All sounds can be muted by tapping The satellite dish icon opens the GPS Data screen. If you have moved the map, or modified the zoom level, the and return back to your current position and re-enable Smart Zoom. - Page 6 Settings to adjust keypad tones and voice guidance settings, to reach the TMC (Traffic Messaging Channel) Control Center to setup Real-Time traffic (where available), to manage which POIs will display on the map, to set the language of text and voice prompts, or units of measurement. to stop or suspend the V7 navigation.
