- Page 1 QA224 Stump Grinder Operation And Maintenance Manual Skid Pro Attachments PO Box 982 Alexandria, MN 56308 www.skidpro.com November 2021 www.skidpro.com...
-
Page 2: Table Of Contents
ontents 1. I ..............3 ntroduCtIon ArrAnty 1.1 Introduction ......................3 1.2 Warranty ......................3 2. C ................. 4 omponent dentIfICAtIon 3. s ..................... 5 Afety 3.1 Safety Alert Symbol And Signal Words ............5 3.2 Operational Hazards ..................5 3.2.1 p ....................6 repAre mergenCIes 3.2.2 r... -
Page 3: I A W
Call your Skid Pro dealer, distributor or the factory if Used equipment. you need assistance, information or additional copies Components covered by their own non-Skid Pro of the manuals. -
Page 4: C Omponent I Dentification
2. C omponent dentIfICAtIon 1 - Hydraulic Motor 2 - Quick-Attach 3 - Operators Manual Holding Tube 4 - Cutting Wheel 5 - Cutting Teeth 6 - Debris Guard www.skidpro.com... -
Page 5: Afety
3. s 3.2 o Afety perAtIonAl AzArds 3.1 s Afety lert ymbol IgnAl WARNING ords Prevent serious injury or death. You must read, understand and follow the instructions given by the operating unit manufacturers, as well as Read and understand this manual before the instructions in this manual. -
Page 6: Igns
To help prevent rollover: If you do not understand any part of this manual, Travel at a slow speed. • contact Skid Pro at 866-232-8224. Avoid sharp turns & sudden movement on slopes. • Carry stump grinder close to the ground. -
Page 7: A Void H Igh P Ressure F Luids
If you do not understand any fall, resulting in death or serious injury. part of the manual, contact Skid Pro at 866-232-8224. Never enter the area under a raised stump Always wear face and/or eye protection, safety shoes, and other protective equipment appropriate for the job. -
Page 8: Hazards From Modifying Equipment
WARNING Entanglement hazard. Keep clear of moving components. Wear proper protective equipment appropriate for the job. WARNING Burn hazard. Hot and high pressure hydraulic oil. Allow oil to cool before servicing. 3.4 h AzArds odIfyIng quIpment Do not make any alterations to your stump grinder. Altering may cause your equipment to be unsafe and may void the manufacturers’... - Page 9 Decal 2 Decal 4 Decal 3 Decal 5 www.skidpro.com...
-
Page 10: I Nitial S Etup
4. I 5. o nItIAl etup perAtIon Quick-Attach must always be fully engaged and 4.1 h ydrAulICs in the locked position. WARNING Keep bystanders away from equipment while in Pressurized fluids can penetrate the skin. use. Disconnect and lock out power source before disconnecting and/or connecting Always wear face or eye protection, safety shoes, hydraulic hoses. -
Page 11: Pre-Operation Check List
5.2 p 5.4 o perAtIon heCk perAtIon It is operators responsibility to perform the following Before starting, stand to side of stump grinder and checks prior to operation of equipment. look at center point on bottom of cutting wheel, this will appear different from the skid steer seat and can be Review and understand this manual and operating unit very deceiving. -
Page 12: R Outine M Aintenance
6. r outIne AIntenAnCe 6.1 I nspeCtIons Check hydraulic hoses and fittings daily for leaks. Replace hose if worn or damaged. Inspect the unit for any buildup of contamination (dirt, stones, etc.). Check cutting teeth every 2 hours of use. Keep cutting teeth in good condition. - Page 13 Remove and replace flex coupler (3). Note: Coupler hub on rotor shaft and motor shaft do not have setscrews. Setscrews are not needed in this application. Install hydraulic motor assembly. www.skidpro.com...
-
Page 14: T Roubleshooting
7. t roubleshootIng Problem Probable Cause Solution Cutting wheel does not spin. Cutting wheel jammed. Remove material from cutting wheel. Low oil. Check oil level in skid steer. Add if necessary. Not enough oil flow. Check flow control on skid steer. See your dealer. -
Page 15: Arts
8. p Arts 8.1 s tump rInder ITEM NO. PART NUMBER DESCRIPTION QTY. D001127 Skid steer attachment SSQT plate Standard skid steer plate D001028 1 x 5" Flange Pin D001674 1/2" Hose holder Sheet D001428 Rotor Frame D002336 S1028 Rotor with teeth S1028 Rotor Assembly with Keyed Shaft (S18 &... -
Page 16: S450 Motor
8.2 s450 m otor ITEM NO. PART NUMBER DESCRIPTION QTY. D001503 A-Motor Mount B2000 L110 Flex B2012 Flex Hub L110 1.25" B2013 L110 Flex D003999 A-Mount Chain Coupler Assembly D003749 A-Mount Chain Coupler – Chain D003748 Chain Link Coupler 1-1/4 x 5/16 Keyway D004149 Complete Hydraulic Motor with Relief Block –... -
Page 17: S550 Motor
8.3 s550 m otor ITEM NO. PART NUMBER DESCRIPTION QTY. D001374 Cat Motor Spacer 1.25" Shaft D001404 B Motor Mount D001007 Char-Lynn 24 GPM Motor D001009 Relief and Anti-Cav Assembly Valve Block D001982 #214 O-Ring D001981 #116 O-Ring D001984 Pressure Relief Valve D001983 Anti-Cavitation Check Valve D001009... -
Page 18: S650 Motor
8.4 s650 m otor ITEM NO. PART NUMBER DESCRIPTION QTY. D001175 Motor D001009 Anti-Cavitation Check Valve Assembly D001982 #214 O-Ring D001981 #116 O-Ring D001984 Pressure Relief Valve D001983 Anti-Cavitation Check Valve D001009 B-Mount Valve D001987 #114 O-Ring D002062 Seal for 1.5" Shaft - 6000 Series CL Motor D001020 L225 Flex Coupler Total Assembly with 6-Spline Insert D001018... - Page 19 www.skidpro.com...
