ANK AOH211 Instruction Manual

OPERATING INSTRUCTIONS

1. Unwind the cord to its full length and place the heater on a
firm, level, heat-resistant surface in a stable, upright position.
2. Visually inspect the ventilation holes to ensure that there are
no blockages.
3. Turn the thermostat knob to the minimum position and set
the power switch to OFF. Then insert the plug into a suitable
wall outlet (10Amp).
4. Turn the power switch from "0" to either "I" (Low Heat), "II"
(Medium Heat) or "III" (High Heat).
5. Turn the thermostat knob clockwise to maximum position,
once the room temperature rises to a comfortable level,
to maintain the room temperature, turn the knob anti-
clockwise until the indicator light turns OFF. The heater will
turn off but will automatically turn back on when it detects
that the ambient temperature has decreased. To lower
the temperature, turn the knob further anti-clockwise. To
increase the temperature, turn the knob further clockwise.
Note: There may be some non-harmful odour emitted from the
heater initially. This is normal during the break-in period or after
long-term storage. Place the heater is used in a well- ventilated
area and continue running it until the odour disappears.
Note: To avoid overloading a circuit do not plug the heater into a
circuit that already has other appliances working.
Note: Never leave this heater unattended when in use.
Caution: Make sure there is nothing flammable or heat sensitive
within 1 metre (40 inches). Operating the heater in any other
position could cause a hazard.
Caution: If there is an oil leak, do not use.
Warning: This product generates heat during operation, to avoid
overheating "DO NOT COVER" the product. Proper precautions must
be taken to prevent the risk of burns, scalds, fire or other damage
to individuals or property.
HEAT SETTING POWER
Low Heat 1000W
Medium Heat 1400W
High Heat 2400W

SAFETY CUT-OFF

THERMAL PROTECTIVE DEVICE
The heater has an overheat protection system that shuts off the
heater in the event of overheating.
If the heater stops working:
1. Turn OFF the heater and inspect the ventilation holes
for blockages.

12 Month Warranty

Thank you for your purchase.
Your new product is warrantied to be free from defects in materials and workmanship for
the period stated above, from the date of purchase, provided that the product is used in
accordance with accompanying recommendations or instructions where provided. This
warranty is in addition to your rights under the Australian Consumer Law.
For New Zealand customers, this warranty is in addition to statutory rights observed under
New Zealand legislation.
We will provide you with your choice of a refund, repair (where possible) or exchange
(availability dependent) for this product if it becomes defective within the warranty period.
The business will bear the reasonable expense of claiming the warranty.
This warranty will no longer apply where the defect is a result of alteration, accident,
misuse, abuse or neglect.
Please retain your receipt as proof of purchase and contact our Customer Service Centre
as listed below, for the entity you purchased this product from, for any difficulties with
your product. Warranty claims and claims for expense incurred in returning this product
can be addressed to the respective Customer Service Centre.
2. Unplug the heater and wait for it to cool (approximately
30 minutes).
If the unit does not restart, the permanent thermal fuse has
operated, and the unit will not function. Do not attempt to
operate the unit, since the overheat protection system cannot
be reset by the user. Do not open the unit and rest by yourself.
There are no user serviceable parts inside.

TIP OVER SWITCH

This heater incorporates a tip over switch. If the unit is
tilted or knocked over the power will be cut automatically.
When the heater is returned to the upright position, it will
function normally.

CARE AND CLEANING

1. Before cleaning, turn off the heater, unplug it from
the power outlet and allow the heater to cool (approximately
30 minutes).
2. Carefully wipe the exterior of the heater with a soft damp
cloth and dry thoroughly with a dry cloth.
Note: Do not immerse the power cord, plug or heater into
water or any liquid or pour water or any other liquid over
the heater.
1. Over time, dust may accumulate. This can be removed by
wiping with a damp cloth, or by using the brush attachment
on your vacuum cleaner.
2. Make sure that the heater is dry before plugging it back into
the power outlet.
Any other servicing should be performed by an authorized
service representative. Do not use the heater if it has
malfunctioned or become damaged in any way. When the heater
is not in use, store in a cool dry location and take care not to
damage the product. Do not store until the heater is cool.

DISPOSAL OF THE UNIT

At the end of its working life, do not dispose of the heater
with your household waste. Observe any local requirements
regarding appropriate disposal or recycling of electrical goods.
Contact your local authorities for advice regarding recycling
facilities in your area.

TECHNICAL SPECIFICATIONS

Model AOH211
Voltage 220-240V~
Frequency 50Hz
Rated Power 2000W-2400W
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
Contact for Kmart purchases Contact for Target purchases
Kmart Australia Ltd. Target Australia Pty Ltd
C/- Customer Service Centre C/- Customer Service Centre
690 Springvale Road, 2 Kendall Street, Williams Landing,
Mulgrave Vic 3170 Vic, 3027
Customer Service: 1800 124 125 Customer Service: 1300 753 567 or
(Australia) or 0800 945 995 via Customer Help at target.com.au/
(New Zealand) or via help/contact-us
Customer Help at kmart.com.au
OCH205
1000W
INSTRUCTION MANUAL
AOH211
WARNING!
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, READ,
UNDERSTAND AND FOLLOW INSTRUCTIONS BEFORE USING THIS HEATER
CPIN007614
