Summary of Contents for GeoCue TRUEVIEW IF1200A
- Page 1 GeoCue 8/16/2023 Version 1.0 Payload Adapter Installation Guide for the IF1200A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Payload Adapter Installation Items ......................2 IF1200A Third Party Integration ......................4 IF1200A Third Party Integration: Payload Adapter ................4 IF1200A Third Party Integration: AV18 Antenna Mast Installation............6 Disposal ..............................9 Support ..............................9 Table of Tables ............................10 Table of Figures ............................ -
Page 3: Payload Adapter Installation Items
PAYLOAD ADAPTER INSTALLATION ITEMS Item Part Name Article Number Quantity number IF1200A Antenna mount AV18 antenna (not included) * ANT1000705A00T VAR6 Front-latch tube mount assembly ASY1001068A01N M3x8 mm flat head screws HDW1001301A00N 3ft Cable Right Angle SMB Jack to Right Angle SMA Jack (not pictured) CAB1000799A00T Loctite Threadlocker Blue 243 (not pictured) -
Page 4: Figure 1. Payload Adapter Installation Items
Figure 1. Payload adapter installation items. Payload Adapter Installation Guide for the IF1200A 8/16/2023... -
Page 5: If1200A Third Party Integration
IF1200A Third Party Integration IF1200A Third Party Integration: Payload Adapter 1. Position the Payload Adapter so the XYZ coordinate axis symbol of the Payload Adapter is facing the front of the IF1200A. Figure 2. Position payload adapter. 2. Unscrew the four (4) Gremzy 12mm tube mount clamps so they are in the open position. Payload Adapter Installation Guide for the IF1200A 8/16/2023... -
Page 6: Figure 3. Unscrew Tube Mount Clamps To Open Position
Figure 3. Unscrew tube mount clamps to open position. 3. Install the payload adapter onto the IF1200A and tighten the four (4) Gremzy 12mm tube mount clamps loosely so the payload adapter can slide to adjust into position. Figure 4. Slide payload adapter into position. 4. -
Page 7: If1200A Third Party Integration: Av18 Antenna Mast Installation
IF1200A Third Party Integration: AV18 Antenna Mast Installation 1. Position the antenna assembly so the antenna cable is exiting towards the port side of the IF1200A drone. 2. Using two (2) M3x 8mm flat head screws tighten the antenna assembly to the IF1200A drone body. -
Page 8: Figure 6. Antenna Cable Routing
Figure 6. Antenna cable routing. 4. Attach the cable using zip-ties along the route of the cable, as follows: Figure 7. Attach the cable using zip-ties. Payload Adapter Installation Guide for the IF1200A 8/16/2023... -
Page 9: Figure 8. Install And Tighten The Av18 Antenna To The Mount Assembly
5. Install and tighten the AV18 antenna to the antenna mount assembly. Figure 8. Install and tighten the AV18 antenna to the mount assembly. Payload Adapter Installation Guide for the IF1200A 8/16/2023... -
Page 10: Disposal
Normal support business hours are Monday - Friday, 8 AM — 5 PM USA Central Time. Our GeoCue Support website contains general workflow information, in addition to specific issue and error messages that you may encounter. Click on the link and search for information contained in the knowledge base. -
Page 11: Table Of Tables
TABLE OF TABLES Table 1. List of payload adapter installation items................... 2 TABLE OF FIGURES Figure 1. Payload adapter installation items....................3 Figure 2. Position payload adapter........................4 Figure 3. Unscrew tube mount clamps to open position................. 5 Figure 4.
