Related Manuals for Aim Pectel T2 ECU
Summary of Contents for Aim Pectel T2 ECU
- Page 1 AiM Infotech Pectel T2/T6 ECUs Release 1.00 This tutorial explains how to connect AiM devices to Pectel T2 and T6 ECUs.
- Page 2 Software configuration For Pectel T2 and T6 ECUs to correctly communicate with AiM device it is necessary to set them up using the dedicated Pectel software. To set the ECU follow these steps: • connect Pectel T6 to your PC •...
- Page 3 Wiring connection For Pectel T2 and T6 ECUs, it is possible to connect to AiM devices through the front male connectors. Here below you find each ECU connector pinout and connection table. Pectel T2 ECU Front connector pin Pin function...
- Page 4 AiM device configuration Before connecting the ECU to AiM device set this up using AiM Race Studio software. The parameters to select in the device configuration are: • ECU manufacturer: Pectel • ECU Model: T_2 T_6 “Pectel – T_2 T_6” protocol Channels received by AiM loggers connected to “Pectel –...
