Summary of Contents for Mockingbird Let's Dig In!
- Page 1 Let’s Dig In! Mockingbird High Chair Instruction Manual and User Guide Scan the QR code for a step-by-step video tutorial on setting up and using your Mockingbird High Chair...
- Page 2 • NEVER use with accessories or replacement parts not • Do not use the Harness if it shows any signs of approved by Mockingbird for use with this product. deterioration or excessive wear and tear, such as • For indoor use only.
-
Page 3: Table Of Contents
Table of Contents Instruction Manual User Guide What’s Included Loading and unloading your child in the High Chair Assemble the Frame Loading: Utilizing the Strap Hooks and adjusting the Harness Unloading: Using the Quick Release Buckle Assemble the Child Chair Removing the Harness Attach the Baby Seat Adjusting the High Chair... -
Page 4: Instruction Manual
Watch our instructional video for a step-by-step tutorial here. Instruction Manual Let’s get started setting up your High Chair! @hello_mockingbird... - Page 5 Hardware & Tools: To keep things simple, you’ll find all the hardware and tools needed to assemble your High Chair in this package! Frame Bolts (6) Capsule Bolts (4) Hex Key @hello_mockingbird...
- Page 6 High Chair Components: Wooden Crossbar Child Step The Frame: Frame Leg (2) Metal Crossbar Adjustable Baby Footrest Bonus Gift! Child Chair: Capsule Capsule Cap Child Backrest Placemat Baby Seat & Tray: Baby Seat 5-Point Harness Adjustable Tray Tray Liner with Belly Bar (attached to the (attached to the Tray) Baby Seat)
-
Page 7: Assemble The Frame
Assemble the Frame Install the Wooden Crossbar Lay one Frame Leg flat on the floor with the inside face up and all indents visible. Insert the Wooden Crossbar into the matching indent on the bottom of the Frame Leg. Insert a Frame Bolt from the outside of the Frame Leg and fully tighten until completely snug. - Page 8 Install the Metal Crossbar Install the Adjustable Baby Footrest Lay one Frame Leg back on its side and insert the Metal Lay one Frame Leg back on its side and insert the Crossbar into the matching indent in the Frame Leg Adjustable Baby Footrest into the bottom of the white above the Wooden Crossbar.
- Page 9 Install the Child Step Attach the second Frame Leg Take the other Frame Leg and gently align the Align the Child Step with the matching indent on the Crossbars, Baby Footrest and Child Step into their bottom of the Frame Leg below the Baby Footrest. corresponding indents on the Frame Leg.
- Page 10 Tighten the Frame Bolts Using the Hex Key, retighten all six Frame Bolts until completely snug. There should be no gaps between each part and the Frame Legs. Important! Keep the Hex Key and retighten all Frame Bolts 2-3 weeks after assembly of your High Chair.
-
Page 11: Assemble The Child Chair
Assemble the Child Chair Slide the Child Backrest onto the Frame Install the Capsules Align the openings on the bottom of the Child Backrest Insert the Capsule into the hole on each side of the with the tops of the assembled Frame Legs. Slide the Child Backrest. - Page 12 Insert the Capsule Caps Insert each Capsule Cap into the Capsule on both sides of the Backrest. You will hear them click into place once securely clipped in. Pro Tip If you want to disassemble your High Chair in the future, the Capsule Caps can be easily removed by using a flat head screwdriver to pop them out.
-
Page 13: Attach The Baby Seat
Attach the Baby Seat Align the Baby Seat onto the Capsule Align the Baby Seat over the Capsules and slide into place onto the Backrest. Push down and on the base of the Baby Seat and listen for a click on both sides. Confirm the Baby Seat is fully clipped in and locked by pulling up on each side of the Baby Seat. -
Page 14: Attach The Adjustable Tray
Attach the Adjustable Tray Slide on the Adjustable Tray Removing the Tray Grasp the sides of the Adjustable Tray. Align the Grasp the sides of the Adjustable Tray, press the openings on the sides with the armrests and the track buttons located on the bottom side of the tray and pull on the bottom with the Belly Bar. -
Page 15: User Guide
User Guide Great job! Look at you, mastering this set up. Read on to learn how everything works! @hello_mockingbird... -
Page 16: Loading And Unloading Your Child In The High Chair
Loading and unloading your child in the High Chair Loading Securing Your Child Unbuckle the harness and align your child’s legs with Secure your child in the 5-point safety harness, the leg openings of the Baby Seat. Gently lower your adjusting the straps by pulling on the adjustment child into the High Chair, ensuring they are comfortably points at the waist. -
Page 17: Removing The Harness
Unloading Removing the Harness Press the button on the Quick Release Buckle To remove the Harness for cleaning, locate the silicone to quickly and easily release the straps. Undo the tab attached to the Harness on the back of the Baby Harness and gently lift your child out of the seat. -
Page 18: Adjusting The High Chair
Adjusting the High Chair Adjusting the Baby Footrest The Baby Footrest has 4 positions so you can adjust the seat height to fit your child just right. Unscrew the thumb screws on both sides of the Footrest, until you feel them pop out. Slide the Footrest up and down the track, using the markers in the track as a guide. -
Page 19: Adjusting The Tray
Adjusting the Tray The Tray has 3 positions to adjust the seat depth for your child. Press the buttons located on the bottom side of the Tray and slide onto the Baby Seat. Utilize the markers on the armrests to adjust the Tray to your desired position. -
Page 20: Using The Tray Liner
Using the Tray Liner Attaching and Removing the Tray Liner The Tray Liner comes attached to the Tray. For easy and quick one-hand removal, locate the tabs on either side of the Tray Liner and pull outward on the tab to unclip the Liner from the Tray. -
Page 21: A Seat At The Table
Child Chair Mode Pull your little one right up to the table in the Child Chair. Pro Tip Place your child’s meal or snacks within easy reach on the included Mockingbird Placemat for easy clean ups. Dig in and enjoy! @hello_mockingbird... -
Page 22: Converting To The Child Chair
Converting to the Child Chair Removing the Baby Seat Adjusting the Baby Footrest Locate the tabs under the Baby Seat on either side. Adjust the Baby Footrest to the highest position. This Press both inward and push up on the seat to remove will be the seat for the Child Chair. -
Page 23: When Things Get Messy
When things get messy Cleaning the High Chair surfaces and Tray You can wipe down all surfaces of the High Chair and Tray with a wet sponge and mild dish soap. Do not submerge the Tray underwater. Wipe with sponge Do not submerge and dish soap in water... - Page 24 2023-00057.2 hellomockingbird.com @hello_mockingbird...
