ZLT X100 PRO User Manual

ZLT X100 PRO User Manual
Thank you for choosing our 5G wireless data terminal products.
In order to enable you to better use the data terminal, please read
this manual carefully, and keep it on standby for future use.
Our company reserves the right to modify the technical
parameters and specifications of this manual, and we will timely
improve the printing errors and discrepancies with the latest data of
this manual. All changes will not be notified in advance, and the
Company reserves the right of final interpretation.
ZLT X100 PRO is a high-performance 5G indoor data terminal,
which supports NR (SA&NSA) and LTE, converts cellular network
data into WiFi and wired network interface data, supports one
gigabit LAN interface, and one telephone interface, and 2.4G+5G
dual band WiFi hotspot (AP). It is applicable to domestic or
commercial scenarios where communication networks and WiFi
hotspots need to be rapidly deployed.
Main technical indicators of product
1.
● Wired network port：Support 1000Mbps RJ45 network port
● Power:input : AC 100V~240V, 50Hz~60Hz
output : DC 12V/1.5A
● Operating temperature: 0℃~ +45℃
● Relative humidity: 5%~95%
● Dimensions: L90 x W50 x H163 (mm)
● Weight: about 415g
2. Installation instructions
1） Take out the wireless data terminal and install the SIM card
into the card slot according to the direction marked on the
data terminal.
2） Use a standard RJ45 network cable to connect the LAN port of
the data terminal to the computer.
3） Use the power adapter to connect the external power socket
V1.0
