Summary of Contents for CNC Design QUAD COIL WINDER MK2
- Page 1 CNC GUITAR PICKUP QUAD COIL WINDER MK2 INSTRUCTIONS IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS MACHINE. Version 1 – 17/05/2023...
-
Page 2: Table Of Contents
Installing Software ..................8 - 9 GENERAL INFORMATION This manual has been compiled by CNC Design Ltd and is an integrated part of the product with which it is enclosed and should be kept with for future references. This manual describes the purpose for which the product has been designed and contains all the necessary information to ensure its correct and safe use. -
Page 3: Declaration Of Conformity
DECLARATION OF CONFORMITY... -
Page 4: Specification
SPECIFICATION The CNC Design Ltd policy of continuous improvement determines the right to change specification without notice. Dimensions of base plate (L x W) 870mm x 400mm Weight 38Kg Maximum feeder travel Approx. 100mm(35mm Between Bobbin plate & Tailstock) Maximum Stepper motor RPM... -
Page 5: Safety Warning
SAFETY WARNING Keep hands clear of moving parts during operation. Ensure all handles are fully tightened before operating. Make sure the power is switched off before connecting the power supply. MAINTENANCE The machine has been designed to be low maintenance. Your machine has been delivered lightly greased as such to keep the machine as clean as we can when assembling. -
Page 6: Getting To Know Your Coil Winder
GETTING TO KNOW YOUR COIL WINDER Control Unit Bobbin Plate ARM MKII Controller Tailstock Power Supply Belt tensioner Safety Cover 10 Safety Cover Limit Switch Feeder Assembly Positioning 11 Adjustable Feet Micrometer Feeder Assembly... -
Page 7: Operation And Use
OPERATION AND USE Remove Machine from the crate, remove wrapping. There are 4 push control buttons located at the front of the machine. These are from left to right: Start, Stop, Pause and Home. Also on top is the emergency stop button. - Page 8 OPERATION AND USE For Micro-adjustments use the Micrometer attached to each feeder assembly. Take care when maneuvering these along the rail as too much force from collisions could break the micrometer. DO NOT overtighten the red knob as this could cause a jam. Connect the power supply to your Mains supply.
-
Page 9: Installing Software
INSTALLING SOFTWARE Insert the enclosed USB stick into your computer, browse to the device and run setup.exe. Proceed through the wizard. Here you can select the installation folder and choose to install this for multiple users or a single user. - Page 10 INSTALLING SOFTWARE After installing the software click close. Browse to your desktop for a new shortcut as shown. All finished and ready to be used with your Coil Winder.
- Page 11 ©PUBLISHED BY CNC DESIGN LTD. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from CNC Design Ltd.
- Page 12 [11] NOTES...
- Page 13 [12] NOTES...
