Instructions For Use
Motus GI Medical Technologies LTD.
Keren Hayesod 22,
Tirat Carmel, 3902638
Israel
Tel +972 73 2627757
Fax +972 4 6214442
Pure-Vu® and Motus GI® are trademarks or registered trademarks of
Motus GI Holdings, Inc. © 2021
LOW
Motus GI Holdings, Inc.
1301 E. Broward Blvd., Suite 310
Fort Lauderdale, FL, 33301
United States
Tel 1 844 PUREVU1 (787-3881)
Fax 1 954 541 8265
MED
HIGH
ERROR
Advertisement
Table of Contents
Related Manuals for Motus GI PURE-VU EVS
Summary of Contents for Motus GI PURE-VU EVS
- Page 1 Fort Lauderdale, FL, 33301 Israel United States Tel +972 73 2627757 Tel 1 844 PUREVU1 (787-3881) Fax 1 954 541 8265 Fax +972 4 6214442 Pure-Vu® and Motus GI® are trademarks or registered trademarks of Motus GI Holdings, Inc. © 2021...
-
Page 2: Table Of Contents
STORAGE AND TRANSPORTATION ................... TROUBLESHOOTING ........................TECHNICAL SPECIFICATIONS ...................... 9.1. Environmental Standards ......................9.2. Shipping and Storage ........................9.3. Performance Specifications ....................... 9.4. Endoscope Compatilibity ......................9.5. Workstation Mechanical Properties and Sizes ..............MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 3: Warnings And Precautions
Care shall be taken to avoid pinching the tubing during advancement through the GI tract and/or when applying torque to the endoscope. • Only Motus GI personnel or a trained Motus GI designee are allowed to service the Pure-Vu System. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 4: Symbols Used
GI tract by irrigating or cleaning and evacuating irrigation fluid (water), feces, and other bodily fluids and matter, e.g. blood. It is for use only by trained medical personnel located in hospitals, clinics, and doctors’ offices. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 5: Product Description
HIGH ERROR FIGURE 1: Pure-Vu Workstation – General Design & Components Workstation Endoscope Umbilical Section Main Connector Irrigation Bag/Water Bottle EVS Flex Channel Waste Containers/Waste Bag Irrigation Line Clamp In-Line Connector Foot Pedal MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 6: Pure-Vu Workstation
Irrigation Pump (Blue Markers) On/Off Power Button Cleansing Mode Indicators (Low / Med / High) Main Connector Error Light Foot Pedal Connector Fluid Button Power Cord Status Light Main Power Switch Drain Button MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 7: Pure-Vu Workstation Components
• Error Light (Triangle) - turns red when there is a non-recoverable system error where the Workstation stops its operation automatically. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 8: Foot Pedal
(default mode) and high where the pedal LEDs indicates the modes in parallel to the Workstation LED panel. Cleansing Mode Manual Purge Selector Suction Cleanse FIGURE 3: Pure-Vu Foot Pedal MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 9: Pure-Vu Disposable Kits
Proximal to the scope grip is the in-line connector that enables attachment to the Umbilical Section. The Umbilical Section connects the Pure-Vu EVS Flex Channel to the Workstation via its Main Connector. 3.3. Accessories for Use with Pure-Vu® System The following water bottles, Motus waste bag, waste containers, and disposable liners are recommended for use with the Pure-Vu System. -
Page 10: Assembly Of The Evs Flex Channel To The Workstation
STEP 1: Secure endoscope handle onto a scope holder or solid surface. Attention: Make sure the endoscope is clean and dry before attaching the EVS Flex Channel. STEP 2: Open the Tyvek lid (A) and remove the tray retainer (B). MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... - Page 11 STEP 4: Attach the EVS Flex Channel’s Tube Holder on the side of the endoscope with the control wheels as shown in image below. STEP 5: Lubricate the distal end of the endoscope with a lubricating gel. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE...
- Page 12 Flexible Head (C) Ensure the endoscope’s working/biopsy channel is aligned above the suction lumen of the Pure-Vu EVS Flex Channel as shown (B). If needed, fine adjustments can be made.
- Page 13 Channel, then peel off “#3” filament (D). Rub the strip on the scope and the EVS Flex Channel to make sure that all surfaces are well adhered (E). Repeat this action for additional strips. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE...
- Page 14 Remove “Peel A” (B), attach it to the EVS Flex Channel (C) and rub the strip on the EVS Flex Channel to make sure it’s well attached, remove “Peel B” (D) and repeat STEP 7. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE...
-
Page 15: Attaching The Umbilical Section To Evs Flex Channel
(E) marked with a single black and double blue lines aligning the black line of tubing with black line on pump head and blue lines on pump head to blue lines on tubing. Then close the suction pump head. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 16: Attaching The Evs Flex Channel To The Umbilical Section
Umbilical Section (C to D). Attention: Make sure the in-line connector is attached correctly between the Flex Channel and the umbilical section as shown in the below image. Verify the clips are well seated. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 17: System Operation
(#6 in Figure 2). The light at the button will turn blue to show this mode is activated. To deactivate the Fluid Only mode press the button again. 12. Upon completion of the endoscopy procedure, disassemble the Disposable as per Section 5.3. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 18: Disassembling The Umbilical Section And Evs Flex Channel
(F). If waste bag (G) is used it can remain connected to suction tubing. Discard irrigation bag or bottle, waste container or bag and tubing per facility protocol. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 19: Removing The Evs Flex Channel From The Endoscope
FIGURE 9: While securing the end of the endoscope and pointing downward, gently pull back the EVS Flex Channel from the end of the distal tip of the endoscope. Discard per facility protocol. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 20: Discarding The Disposables
5.5. Discarding the Disposables Following disassembly, discard the Pure-Vu EVS Flex Channel, Umbilical section, irrigation bags/bottles, waste containers/bags, unloading components and all other disposables according to facility protocol. CLEANING WORKSTATION AND FOOT PEDAL The Workstation and foot pedal should be cleaned after the procedure by thoroughly wiping down their surfaces with a viricidal cloth (Opti-cide, Cavicide or similar surface disinfectant of choice) that has an active ingredient of isopropyl alcohol (17% - 21%). -
Page 21: Troubleshooting
• Verify that the EVS Flex Channel suction port tip is not positioned against the GI tract wall. If so, direct the scope tip away from the wall. *If the above does not remedy the warning indication, contact a Motus GI representative. MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... -
Page 22: Technical Specifications
Following are the mechanical properties and size for the Pure-Vu Workstation: Workstation 250mm x 400mm x 280mm Dimensions [W x D x H] [10in x 15.7in x 11in] Weight 12kg (26.5lbs) Power Supply 100 - 240 VAC / 50 - 60 Hz MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE... - Page 23 MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE...
- Page 24 Motus GI Holdings, Inc. 1301 E. Broward Blvd. Pure-Vu® and Motus GI® are trademarks or registered trademarks of Suite 310 Motus GI Holdings, Inc. ©2023 Fort Lauderdale, FL 33301 Tel: 1.800.PUREVU1 (787-3881) IU00013 Rev. A Fax: 1.954.541.8265 MOTUS GI PURE-VU SYSTEM INSTRUCTIONS FOR USE...
