Electronic Humidity Sensor
C
ONTENTS
This package contains:
• 1 HA-4
• 2 Mounting screws and 2 anchors
• 1 Installation/Operating Instructions Guide
S
PECIFICATIONS
Power Requirement
Sensing Element
Sensing Range
Accuracy
Response Time
Operating Temperature
Weight
Dimensions
M
u o
t n
g n i
Case Material
a W
a r r
y t n
Environmental Conditions:
HA-4 is meant for Indoor Use Only
Operating Temperature
Overvoltage category
Pollution degree
Ingress Protection
Cleaning HA-4:
Clean the device with a soft dry cloth. Do not use liquid cleaners, solvents, or abrasive cleaners.
DO NOT OPEN THE CASE. This will void warranty
12 VDC or 24VDC, 0.21W Max
Capacitive / IC
5 to 95% RH at 77 °F (25 °C)
±3% 20 to 50% RH at 77 °F (25 °C)
TC < 12 minutes
-40 to +140 °F (-40 to +60 °C)
5.3oz (150.0g)
3.9" x 2.9" x 1.7" (9.9cm x 7.4cm x 4.3cm)
S
f r u
e c a
mount
ABS
1
Year Limited
-40 to +140 °F (-40 to +60 °C)
OVC I
2
IP21
Tech Support 8:00am - 5:00pm Central Time
(800) 635-4269
www.winland.com
© 2023 Winland Electronics, Inc.
D-075-0123 Rev A (10/2023)
