Ateis UAP G3 User Manual

Universal audio processor g3, basic ver./high power ver.
Hide thumbs
Table of Contents

Advertisement

Quick Links

/
Universal Audio Processor G3, Basic Ver./High Power Ver.
User Manual
Revision History
v1.01
www.ateis.com
© 2022, ATEÏS. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UAP G3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ateis UAP G3

  • Page 1 Universal Audio Processor G3, Basic Ver./High Power Ver. User Manual Revision History v1.01 www.ateis.com © 2022, ATEÏS. All rights reserved.

  • Page 2: Table Of Contents

    3.1.2 ................................12 Rear panel 3.1.3 Peripherals ................................13 3.1.3.1 ................................. 13 RAC 5/ RAC 8 controller Configuration - UAP G3 Designer software Quick Start ........................... 15 4.1.1 Software Installation ................................15 4.1.2 ................................17 Auto search & Connection 4.1.3 ................................

  • Page 3: Contents

    Contents 5.1.2.2 ................................. 43 Reboot (reset)/standby mode command 5.1.2.3 Element control value command ................................. 44 5.1.2.3 ............................44 Write Element value command 5.1.2.3 ............................44 Read Element value command 5.1.2.3 ............................45 Increase Element value command 5.1.2.3 Decrease Element value command ............................
  • Page 4 UAP G3 User Manual 6.1.9 ................................92 Logic Control 6.1.10 Logic Meter ................................92 6.1.11 ................................92 6.1.12 ................................93 6.1.13 ................................93 Priority/Volume Arbiter Delay ........................... 94 6.2.1 ................................94 Delay (Advanced) 6.2.2 Delay (Basic) ................................95 DigiLink ........................... 96 Dynamic ...........................

  • Page 5: Contents

    UDP Stream ........................... 130 6.21.1 ................................130 UDP Stream Receiver 6.21.2 ................................131 UDP Stream Transmitter 6.22 VoIP ........................... 132 Xpressor 6.23 ........................... 134 Maintenance Technical data UAP G3/UAP G3H ........................... 137 Contact information © 2022, ATEÏS. All rights reserved.

  • Page 6: About This Manual

    UAP G3 User Manual About this manual This user manual will explicitly describe the hardware installation and the software configuration, providing installers and users the necessary information to setup and configure the system. Firmware version: Version v1.01 Important safety instructions 1.

  • Page 7: Connection

    About this manual hazard. To prevent the unit from falling down and causing personal injury and/or property damage, avoid installing or mounting the unit in unstable locations. Operate the device in an environment with a free-air temperature of between -5 °C and +55 °C (-23 °F and 131 °F).

  • Page 8: Copyright

    UAP G3 User Manual The equipment or the property can be damaged, To alert the user to the presence of uninsulated or persons can be lightly injured if the alert is “dangerous voltage” within the product’s enclosure not observed. that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 9: System Requirement

    About this manual Do not use benzene, thinner or chemicals to clean the device. Use only a soft, dry cloth. If the device is moved from a cold place (e.g., overnight in a car) to a warmer environment, condensation may form inside the unit, which may affect performance. Allow the device to acclimatize for about one hour before use.

  • Page 10: Hardware Installation & Connection

    Hardware Installation & connection Mounting Mount the UAP G3/ G3H audio processor in any standard 19-inch 1U audio equipment rack using the supplied mounting brackets and screws. Consider leaving enough ventilation space above and below the unit. Do not mount the processor directly above the heat generating devices like power supplies or power amplifiers.

  • Page 11: Devices

    Front panel 1. Configuration audio I/O 4 audio slots (A, B, C and D) are equipped in UAP G3/G3H. Each of these audio slots receives either 4 audio input or output channels. When the UAP G3/G3H is powered, users can identify...

  • Page 12: Rear Panel

    UAP G3 User Manual 3.1.2 Rear panel 6. Mains power inlet: Connect the mains power to this socket, the UAP G3/G3H accepts AC voltages 100~240V, 1.2A, 47~63Hz (fuse: T1.6AL/250VAC). 7. 24VDC backup power input. 8. 1 set of RS485 interface for 3rd party control.

  • Page 13: Peripherals

    Devices 3.1.3 Peripherals 3.1.3.1 RAC 5/ RAC 8 controller The RAC includes two parts Top and Bottom and can be used to adjust the audio source and adjust the parameters (volume control, etc.) The two sets of 5/8 steps knobs on RAC can be programmed by using web browser.

  • Page 14: Configuration - Uap G3 Designer Software

    UAP G3 User Manual Configuration - UAP G3 Designer software The UAP G3 Designer software integrates with fully DSP components and offers a flexible user- defined I/O configurations for different kinds of applications, including several models of quick settings, making the UAP system easy to setup, program and control, it also controls the audio devices via PC/Laptop for multi-rooms.

  • Page 15: Quick Start

    Quick Start 4.1.1 Software Installation Install the UAP G3 Designer software to user Windows PC/Laptop (Win7 / Win 8/ Win 10/Win 11) Follow the instructions of the InstallShield Wizard to install UAP G3 Designer V1.01 EU software. Installation 1. Click on [NEXT] to install the software.
  • Page 16 UAP G3 User Manual 4. Click on [Finish] to complete the installing. 5. Go to the desktop and click on the [UAP G3 Designer v1.01] to start. © 2022, ATEÏS. All rights reserved.

  • Page 17: Auto Search & Connection

    Search and connect to the devices for programming and controlling. 1. Make sure the UAP G3/ G3H Designer software is not blocked by the Windows Firewall. 2. Go to "View > Options > "Network Settings > Network Adapter" window. Make sure the Network Adapter (network card) setting is correct and every device are connected appropriately, then power the devices to start the next steps.

  • Page 18: Create New File

    Create New File Create new file 1. First, go to [File] > [New] to open a new UAP G3 System file. 2. Check the box for [Auto Search] in the lower left corner of the window, display all the system which is connected to user's network.
  • Page 19 The UAP G3 Designer software has automatic deploy function that enables each UAP G3 device with a device ID shown under “Identifier”. 3. Go to “Device Management” >> “Drag n' Drop" the "UAP G3 Audio Network“ on the editing window, and the online devices diagram will be automatically created.
  • Page 20 UAP G3 User Manual A floating window will pop up which allows user to choose a various types of UAP G3 System display (Default/ Vertical/ Horizontal) shown on the editing window 4.There are more than 25 kinds of fixed DSP configuration on UAP G3 Designer software. These pre- programmed configurations are varying by different kinds of I/O hardware.
  • Page 21 Configuration - UAP G3 Designer software N Ducker/ Matrix/ Paging m odels o Manual: Users choose the DSP components freely. o Paging: For multiple devices to paging in the system. o Matrix: Basic models of the paging. o N Ducker: Suitable for dividing the system into several areas to paging.
  • Page 22 UAP G3 User Manual "Gate" for details. 5) AGC: Add AGC(Automatic Gain Control) component to the DSP configuration. "AGC Mono/AGC Stereo" for details. 6) Hi/Lo: Add Hi/Lo Pass component to the DSP configuration. See "Hi/Lo Pass" for details. 7) PEQ: Add PEQ (Parametric Equalizer) component to the DSP configuration, from 2-16 bands.
  • Page 23 "Pink Noise", "Tone Noise" for details. Audio Slot: Choose the audio cards in Slot A, B, C, D on the UAP G3/G3H device. Click the bar at the right side to expand the setting w indow as below picture History o Fixed: Click the checkbox to fix the history on the list.

  • Page 24: Quick Access Toolbar

    Make > Compile > Build. 8. Click on "Upload" button to upload user UAP G3 configuration on to the UAP G3/ G3H processor. 9. Click on ''Online'' button to go online.

  • Page 25: Main Toolbar

    Configuration - UAP G3 Designer software I'm lost : Click this button to restore the scale and scroll scope of the working area. More Buttons : Click to pull down the "Customize Quick Access Toolbar'' window. Including selective buttons to show on quick access toolbar and the modification of interface.
  • Page 26 UAP G3 User Manual Signal Trace: Show the audio signal path of the selected DSP component in the DSP configuration. Click this button once to start tracing, and click it again to stop. o Signal Path Forward Trace: Trace the input audio path through the selected DSP component.

  • Page 27: System

    Configuration - UAP G3 Designer software space among them in horizontal/vertical. Size: Select several graphical objects, and then choose one of them to be the reference to make them have same size/width/height. Z-Order: Select the graphical objects to be on the front or at the back of other graphical objects.

  • Page 28: View

    UAP G3 User Manual IDM <Admin>: Manage/display/edit the user authorized level. See IDM for details. Click button to login and logout. Online: Online the software with the processor. Once online, the parameters will be synchronized based on the adjustment of the parameters of processor. The system configuration is not able to edit during online.

  • Page 29: Template: Devices/Components

    Configuration - UAP G3 Designer software About: Display the information of Designer software. Manual: Link to the user Manual of system. System export: Export the configuration settings in xml. format. User can select the specific parameter of the devices or DSP components System Export Window 4.3.4.1...

  • Page 30: Object Tree

    UAP G3 User Manual Components Template Display the DSP components such as EQ, Dynamic and Filter etc. of UAP G3/ G3H. The components can be 'drag n drop' into the design window (working area) for system configuration. The Components Template can only be accessed if users have a Super Password ID.

  • Page 31: Property

    Configuration - UAP G3 Designer software 4.3.4.3 Property The Properties window will show the information of selected device/components/element and hardware connection (on Device Management window). It is able to edit the settings of the selected component/device on this window. Path: View > Property To quickly edit the displayed texts of component, select a component first, and press F2 on userr PC/laptop keyboard, then user can edit its displayed texts of component.

  • Page 32: Phone Book

    Allow to create/edit the phone book database for telephone call and VoIP call on PC/Laptop. Once completed, go to Device Management > Phone Book to upload the settings into UAP G3/ G3H processor. Path: View > Phone Book © 2022, ATEÏS. All rights reserved.
  • Page 33 Configuration - UAP G3 Designer software : Create a new contact person. : Remove the selected contact person. : Import the contact person information from the excel file (.xls). : Export the contact person information to a excel file (.xls).

  • Page 34: Search

    UAP G3 User Manual 1) Personal: Edit the contact details of this contact person. 2) Telephone Card: Edit the telephone setting of this contact person, allowing to dial his telephone/cell phone number. Add / Remove: Click to add a new telephone setting/remove the selected telephone setting.

  • Page 35: Options

    Configuration - UAP G3 Designer software Search Text: Type the text user wish to be searched. Case sensitive: A filter which must be typed exactly as required (shown as a capital letter or a common letter). Whole words only: A filter which the completed full letters or item can be searched only.

  • Page 36: Status Bar

    UAP G3 User Manual RWD-AIO: Set the skin color (blue/orange as default) and the color of title displayed on RWD-AIO. o Replace All: Click [Replace All] to apply the new setting of skin color. o Font color: Set the custom color setting for the title displayed on RWD-AIO, and click [OK] to apply the setting.

  • Page 37: Functionality

    Functionality Functionality 3rd party command The 3rd Party Command function allows an external device to control the main controller including the events or elements through Ethernet (UDP) or communication interface. Path-1: System > 3rd Party Command Path-2: 1. Right click the element > Find > 3rd Party Command. 2.

  • Page 38: Command Format

    00, 01 FFFF FFFF STX : always be 0x5B HS: When the external device writes 1 on [HS] command field, it means the UAP G3/ G3H will respond the external device a Handshake Response command. See Handshake Response Command for more details.

  • Page 39: Cmd Field

    EOC: always be 0xB5 5.1.1.1 CMD field There are three types of command that are available for external device to control the UAP G3/ G3H. Reboot/Standby Mode command (its CMD field is 27) 2. Element Type, see the following table below.

  • Page 40: Data Field

    UAP G3 User Manual Element Type Event Type Decrease the Current Path Player event Element value Advnaced Increase/Decrease Singular Paging event Elements value Integrated Paging event Basic Recorder event Auto Recorder event Uninterrupted Recorder event 5.1.1.2 Data field 5.1.1.2.1 Value format This chapter will describe the Data Field of command.

  • Page 41: Element Target Format

    Functionality means the [Level] will be adjusted to -20 dB. o Example-2: Control the [Element Adjust] Event, and adjust all the applied parameters to 50%. 5.1.1.2.2 Element Target format The following table is used for describing the element targets. Element Target Element Target Target N...

  • Page 42: Event Target Format

    PL1ID/PL2ID: The Identifier (ID) of processor (L1, L2). o EID: The ID of event. 5.1.2 Supported commands The UAP G3/ G3H allows the external device to control it via 3rd party control, see the following command chapters. 5.1.2.1 Handshake response command The Handshake is a secured packet switching.

  • Page 43: Reboot (Reset)/Standby Mode Command

    0: ACK (UAP G3/ G3H responds the external device that it has received network packet). o 1: NAK (The process of sending the network packet to UAP G3/ G3H is not in order or has problem. Please resend the command. If it fails, contact user ATEÏS dealer).

  • Page 44: Element Control Value Command

    5.1.2.3.2 Read Element value command This [Read Value] command contains the two following steps: 1. The external device will send the [Request] command to UAP G3/ G3H for asking the current value. 2. The UAP G3/ G3H will respond the [Respond] command to inform the current value to external device.

  • Page 45: Increase Element Value Command

    Element Target Format for details. Value 1 ~ Value N: When external device requests to get the Target 1~Targer N from UAP G3/ G3H, the UAP G3/ G3H will reply Value 1~Value N to external device, see Value Format details.

  • Page 46: Decrease Element Value Command

    UAP G3 User Manual Value Value Target Target Target Target Target Target Target Target Type Data Count PL1ID PL2ID EL1ID EL2ID 3DCC Value 0014 0001 0001 0000 02CA CCCD 5.1.2.3.4 Decrease Element value command Use a value to decrease the specific parameters (Target Count + Target 1~N) via 3rd party control.

  • Page 47: Events Control Value Command

    Functionality Target 1 ~ Target N: The target information including the position of this parameter, see Element Target Format for details. Example: This command can increase the [Level (9, 1, 0)] value of a component (0) on Processor (1,1) by 0.1 dB (float, 3DCCCCCD), and the value is also within the max./min range [-60 dB (float, C2700000) ~ 20 dB (float, 41A00000)].

  • Page 48: Elements N-Trigger Event

    UAP G3 User Manual Value Value Target Target Target Target Target Type Data Count PL1ID PL2ID Bytes 3DCC Value 0011 0001 0001 0000 02CB CCCD Example-2 (percent value): This command can use a percent value (10.0%, 41200000) to adjust the [Elements Adjust Event] (0) on Processor (1,1).

  • Page 49: Message Play Event

    Functionality Value Value Target Target Target Target Target Type Data Count PL1ID PL2ID Bytes 00000 Value 0011 0001 '0001 0000 0058 Example-3 (percent value): Use the 0.0% value (00000000) to activate the [Load] action on the Elements N-Trigger Event (0) of Processor (1, 1).

  • Page 50: Path Play Event

    UAP G3 User Manual Example-3 (pause the message): Use the Integer value (00000002) to pause the Message Player Event (0) of Processor (1, 1). Value Value Target Target Target Target Target Type Data Count PL1ID PL2ID Bytes 00000 Value 0011...

  • Page 51: Singular Paging Event

    Functionality Example-1 (stop the event): Use the Integer value (00000000) to stop the Path Player Event (0) of Processor (1, 1). Value Value Target Target Target Target Target Type Data Count PL1ID PL2ID Bytes 00000 Value 0011 0001 0001 0000 0058 Example-2 (play the event): Use the Integer value (00000001) to play the Path Player Event (0) of Processor (1, 1).

  • Page 52: Integrated Paging Event

    UAP G3 User Manual See the following 2 types of value format that is support by [Events Value Control] command. 1. Boolean value o off: Stop paging o on: Start to page 2. Integer value o 0: Stop paging o 1: Start to page...

  • Page 53: Basic Recorder Event

    Functionality o If the code cannot be found, this command will be cancel. o If the paging zones (16x16) in the code has found, it will start to paging. o To stop the paging action, users need to define a [cancel paging] code, see the example of Code 7 as the picture below.

  • Page 54: Auto Recorder Event

    UAP G3 User Manual If the received value cannot be converted to the Function Code, then this command will be canceled. See the following 2 types of value format that is support by [Events Value Control] command. 1. Boolean value...

  • Page 55: Uninterrupted Recorder Event

    0000 0059 Events The UAP G3/ G3H Designer software offers various types of event to control the UAP G3/G3H devices. For example, to adjust the value of elements, paging event, trigger a message playing event. An event is allowed to set several elements, and an element can be controlled by several events.
  • Page 56 3. Click [Add] button to create a new event, then select a type for this event. Type o Message Player/Path Player: This Message Player allows to play the audio message files stored in UAP G3/ G3H or USB flash drive. It needs to create a Message Player component first, see Message Player.

  • Page 57: How-To: Configure Message Player/Path Player

    Active Procedure: Defines how UAP G3/G3H send program packets with third-party machines. o Passive Procedure: Define how UAP G3/G3H receive programs from third-party machines, and exchange packets 5.2.1...

  • Page 58: How-To: Elements Adjustment

    UAP G3 User Manual 5.2.2 How-to: Elements Adjustment 1. Right click the elements and assign them to an event. If the element's property and the type of event are not correspondence, the event will not be shown here for further assigned action.

  • Page 59: How-To: Sub-Preset

    Functionality 5.2.3 How-to: Sub-Preset 1. First, Select how many groups of this event on [Group Count]. Current Group: Choose a group and set (save or load) the parameters of event. Save: Save the current modified parameters as the latest applied value. Load: Click to load the adjusted value of event to the applied elements.
  • Page 60 UAP G3 User Manual 3. Click button on Mounting field to enter [Event Settings] window. Click [Add] button to establish a new integrated/singular paging event. Integrated: An integration paging event has multiple codes for zone selection. Singular: This event is similar to the integration paging event except that it ''only has one code''.

  • Page 61: Scheduler

    Functionality 1) The selected paging zones are not occupied by other sources with higher priority. 2) The priority of the other occupied sources are lower than the paging sources itself. 4. Select a paging event and click button as the picture below, and it will display all zones of this Paging component in [Paging Event] tab.
  • Page 62 For example, if users want to play a message at 8AM everyday from 2022/1/1~2022/12/31, except 2022/8/9. 1. Right click the figure of UAP G3/ G3H processor, then select Find > Schedulers to open the scheduler window, see the picture as below.
  • Page 63 Functionality Forever Trigger N Times Specific Time 4. Exception Time: Click button at [Exception] field, it will display a setting window. Here user can add the particular time between the Begin Time and the End Time to stop triggering the schedule.
  • Page 64 UAP G3 User Manual Type: Define the value type of the normal value and the active value. o Trigger: Trigger the applied elements when the time user set is up. o Percent: Trigger the applied elements by percent value when the time user set is up.

  • Page 65: Source Type

    Functionality Path-2: Go to [Object Tree] panel > right click the Event1 > Controls > Processor > Schedulers > Chime every 15min. 9. After assigned a schedule to control an element, click [Mounting] button, and it will show a tree view listed all its applied elements. See the picture as below. Source Type Source Type is a function to tag audio sources.
  • Page 66 UAP G3 User Manual o Device overview: Overview all the components in the device. Each string or component can be traced the audio source type and show as the same color.Right click to [Source Type Tracing] to open [Source type setting viewer]. See picture below.

  • Page 67: Protocol List

    So, in this situation the priority are: Source Type 2 > Source Type 4 > Source Type 1 > Source Type 3. Protocol List Controls There are four kinds of control in UAP G3/ G3H system, front panel knobs, control input, logic I/O and contact output. Path: System > Controls © 2022, ATEÏS. All rights reserved.

  • Page 68: Front Panel Knobs

    How to Use - assign an element control on a front panel knob of UAP G3/ G3H 1. Click [Controls] button on the toolbar to pull-down a small window, see the picture as below. 2. Select [Front Panel Knobs] option to control this element, then select a UAP G3/ G3H intended to make adjustment.
  • Page 69 Functionality components in the project exclude the wiring of routing. Pre-Sync: Click the check box to calculate the parameter in sync with the device. button: Click this button to link to its applied element setting page. 4. In order to add the element in each of the controls, double click the component which user wish to control its element.

  • Page 70: Control Input

    Remove : Click on Remove grid to remove the selected element, or user can remove the element from its component window (Component > [Controls] option > UAP G3/ G3H > Front panel knobs > one of knob). 5.6.2 Control input How to Use - connect a RAC remote for source selection (RAC5/8) and volume control (Knob).
  • Page 71 Switch: Select this type to program and send a Hi to Lo signal to an external device such as ON/OFF switch button. o RAC5/8 (Top/Bottom): Select this type to let the RAC5/8 remote be used by UAP G3/ G3H.
  • Page 72 UAP G3 User Manual 7. Try to switch the channel steps on the simulation window and see whether the input channels on Selector component window are coordinated. See as below. 8. Double click the Output component to open a Output component window.

  • Page 73: Contact Output

    Functionality 5.6.3 Contact output How to Use - connect a LED indicator for status monitor (logic output) on OL-AMP. CH1~CH2: The two channels of contact output on the rear panel of OL-AMP. Operator: o OR: Do an OR operation for all the applied elements which is assigned to control contact output.
  • Page 74 Path: System > Device Management 1. Device Information Devices: List the entire UAP G3/ G3H systems. Click [+][-] button and unfold/fold the devices which are connected under the system. Type: The type of the device such as UAP G3, UAP G3H, etc.

  • Page 75: Download

    File system Allow to manage all the files stored in the UAP G3/ G3H processor. The File System allows to save files into the UAP G3/ G3H or load files from UAP G3/ G3H. The supported file format are WAV, MP3, BMP, G722, XML, TIF, LOG, INI, PNG, JPG and XDUI.
  • Page 76 10."Ext." Button: Click to open a window listed all the extension devices connected to the UAP G3/ G3H. 3. Click [Add] button to add files, and select all the files user wish to save into UAP G3/ G3H. 4. Click button on the "Local"...

  • Page 77: Phone Book

    Refresh: Refresh the files from the processor. Backup: Backup all the files including audio, config files in UAP G3/ G3H to PC/Laptop (\\My Documents\UAP G3 Designer\Resource\[machines]\processors\[machines SN]). Download: Download the selected files from UAP G3/ G3H to PC/Laptop, the files will be...
  • Page 78 Retrieve SIP Server Information: Click to restore/download the SIP server settings from the UAP G3/ G3H to UAP G3/ G3H Designer software. Store SIP Server Information: Click to upload the SIP server settings into the UAP G3/ G3H. 3) Phone Book: Display the phone book setting (ID/Name/Sex/Age/E-mail) which intends to upload into the UAP G3/ G3H.
  • Page 79 5. If the contacts settings are conflicted when uploading the contacts settings into the UAP G3/ G3H, user need to choose either to follow (upload) the setting edited in PC (UAP G3/ G3H Designer software) or Machine (UAP G3/ G3H hardware).

  • Page 80: Reboot

    To reboot the devices by UAP G3/ G3H Designer software. How to Use 1. Open the Device Management panel, and select a system or a UAP G3/ G3H processor in ready status. The [Reboot] function will be shown on the right section of panel.

  • Page 81: Analog Input Calibration

    How to Use 1. Open the Device Management panel, and select a UAP G3/ G3H processor in ready status. The [Analog Input Calibration] function will be shown on the right. 2. Click [Analog Input Calibration] on the panel, and it will display a pop-up control window.

  • Page 82: Log

    UAP G3 User Manual 3. Rotate all the front panel knobs on UAP G3/ G3H or the knobs of the connected remote (RAC5/8) via the control inputs of UAP G3/ G3H to the minimum level first. 4. Click [...] button for [All] channel on [Min] field to calibrate the correct voltage for all the corresponded knobs.

  • Page 83: Settings

    5.7.8 Settings To set the time/date and the daylight saving time for UAP G3/ G3H system. The time/date can be either as user-defined or from NTP server. Changes in the Date/Time setting will affect the Scheduler and the Current Time display on UAP G3/ G3H Designer software.

  • Page 84: Fault List

    If the UAP G3/ G3H Designer software detects any Issue, it will show the fault at [Device Management] panel. How to Use 1. Click [...] at Fault grid to open a Issue List window, it will list the faults of this UAP G3/ G3H system. © 2022, ATEÏS. All rights reserved.

  • Page 85: Redundant Setting

    Functionality 2. Click button to know the troubleshooting to this Issue. Redundant setting UAP System provides several ways for setup redundant, including . User can setup redundant processors or redundant loops, so that the machines can replace the processors/ loops when the failure is detected.
  • Page 86 How to set redundant loop through OCTO Link 1. Drag the UAP G3 processor on the template and drop on the working area. 2. Click [Upload] the device.
  • Page 87 Functionality Name: Device's name. Type: The machine type of the device. Identifier: The first represent the Loop and the second number represent the device number in the loop. Redundant: Display the redundant device. OL-Backup: Available if the device is equipped with OL card. Serial Number: the number of the device.

  • Page 88: Dsp Components

    UAP G3 User Manual DSP components Control 6.1.1 Analog Control Send analog signal to the output channel or control the value such as level control or trigger the events. Control Window Analog Control-8CH Output: The channel of analog output channel (available in 1CH, 4CH, 8CH, 16CH).

  • Page 89: Capture

    DSP components Output: The channel which outputs the signal. Signal: Light up when the signal is detected. Threshold: Set the threshold value for transmitting the analog signal to logic signal. 6.1.5 Capture The Capture component is similar to Binarized component, the difference is it can transmit the analog signal (-N, +N) to logic signal (0 or 1) in multiple output channels, and also set the threshold value in a range (max.

  • Page 90: Event Trigger

    UAP G3 User Manual Input: The input channel to trigger the event. Click to rename the input channel. Event: Select an event from the drop-down list. See Events chapter for details. Percent: Trigger the event by the value range (max. and min.) and transmits to the percentage value.

  • Page 91: Interface

    Input: The 16 channel Input channel used to control the elements or trigger events. Simulate: Tick the Simulate button to define the value which controls the element or triggers the events. If this button is disable, the system will use the value set from the physical UAP G3/ G3H hardware wiring for reference.

  • Page 92: Logic Control

    Output: The 6 CH output channel on the front panel of UAP G3/ G3H. Simulate: Tick the Simulate button to define the value which controls the element or triggers the events. If this button is disable, the system will use the value set from the physical UAP G3/ G3H hardware wiring for reference.

  • Page 93: Priority/Volume Arbiter

    LIFO, Priority + Volume, etc. The Priority/Volume Arbiter component will send logic output signal to RS485 Procedure Trigger component, which allows the RS485 Procedure Trigger component to send the 3rd party commands to external devices such as USB camera via RS485 protocol on UAP G3/ G3H.

  • Page 94: Delay

    UAP G3 User Manual the NS pin to RS485 Procedure Trigger component to send a 3rd party command automatically. Mode Follow: 1. Connector: The behavior of Priority/Volume will be based on the physical pin connection between the Gain Sharing Mixer component and Priority Volume Arbiter component.

  • Page 95: Delay (Basic)

    DSP components 4CH Delay (Advanced) 500ms Type: An alternative button. Choose between adjusting with Time or with Distance and temperature. Mute/Mute all: Mute (all) the output channel (s). Bypass/Bypass all: Bypass the audio signal of (all) the channel (s). Note: This will disable the Delay function.

  • Page 96: Digilink

    UAP G3 User Manual DigiLink Control Window 4CH Digilink Output 4 CH 4CH Digilink Input 4 CH Output/Input: Indicate the input/ output channel. DigiLink Channel: Set the Channel. Overload: Light up if the signal of an input channel is bigger than Overload Thd.

  • Page 97: Compressor Mono/Compressor Stereo

    DSP components Max Gain (dB): Define the maximum of automatic gain. Limit the max. gain to keep a natural audio dynamic. Attack Time (dB): Adjust the fade-in time to reach the target level. Release Time (dB): Adjust the fade-out time of the signal when AGC is no longer working. This value is ignored if the “Release button”...

  • Page 98: Comp-Limiter

    UAP G3 User Manual Compress: Light up in green when Compress is activating. Bypass: Disable the Compressor function. Soft Knee: Enable/disable the “Soft Knee” mode. This element controls whether the bend in the response curve is a sharp angle or has a rounded edge. A soft knee slowly increases the compression ratio as the level increases and eventually reaches the compression ratio set by user.

  • Page 99: Ducker Mono/Ducker Stereo

    DSP components o Thd. (dB): Activate the Limiter function when input level above this value. o Release Time (ms): The time it takes to release gain reduction. Compress: o Compress: Light up when the compression is activated which it will compress the input level by Ratio to be the output level.

  • Page 100: How-To

    UAP G3 User Manual To avoid the unexpected attenuation, don't set a threshold level too low. Response Time (ms): The time between the level detection of input S and the beginning of the Ducker’s operation on input A channel. Don't set the "response time" too long, otherwise user won't hear the beginning of input S channel (as the first word of a speech).

  • Page 101: Gate

    DSP components Default: Click to restore all settings to factory setting. Ratio x:1: Set the expansion ratio. Thd. (dB):Activate the Expansion function when input level below this value. Thd. Range (dB): Set the range of level, in which the ratio gradually alters from 1:1 to the value set by the ratio parameter (soft knee function).

  • Page 102: Gate - Voice

    UAP G3 User Manual Gate - Mono Gate - Stereo Mute: Mute the output of Gate component. Bypass: Bypass the input signal to the output of Gate component. Thd. (dB): Set the threshold lower than input signal, then the Gate will be opened and the input signal will pass.

  • Page 103: Gate With Sidechain

    DSP components Thd. (dB): Set the threshold to open the Gate-Voice (human voice only). Hold Time (ms): The time to close the output when no more human speech is detected continually. Release Time (ms): The fade-out time of the signal to decrease the signal after the hold time. Default: Click to restore all settings to factory setting.

  • Page 104: Equalizer

    UAP G3 User Manual Bypass: Bypass the input signal to the output of Limiter component. Hard Clipping: Enable/disable the “Hard clipping” mode. The difference between "Hard" and "Soft" clipping is that hard clipping cuts off the peaks flat, and a soft clipping is like a limiter which gives user a clipped signal with slightly rounded edges at the cut-off points, rather then the right-angle edges of a hard clipping.

  • Page 105: Peq Mono/Peq Stereo

    DSP components o Axis-X: Frequency of output signal (Hz). o Axis-Y: Gain of output signal (dB). o Purple Control Point: Gain (dB). 6.5.2 PEQ Mono/PEQ Stereo PEQ (Parametric Equalizer) is a multi-band variable equalizers which controls the three primary parameters: amplitude, center frequency and bandwidth, making more precise adjustments to sound than other equalizers.

  • Page 106: Hi&Lo Pass Peq

    UAP G3 User Manual o Axis-X: Frequency of output signal (Hz). o Axis-Y: Gain of output signal (dB). o Purple Control Point: Gain (vertical direction) and Frequency (horizontal direction). o Yellow Control Point: Bandwidth. 6.5.3 Hi&Lo Pass PEQ Hi&Lo Pass PEQ is a multi-band variable equalizer component that Hi&Lo pass filter combines with PEQ.

  • Page 107: Feedback

    (4, 8 12 or 16 bands). The more of the feedback bands have, the better of the feedback frequency will be detected, but it will increase and consume the loading of DSP power of UAP G3/ G3H processor at the same time. Control Window Feedback 1/5 Oct 8 band (All) Bypass: Disable (all) the Feedback operation.

  • Page 108: Filter

    UAP G3 User Manual If the portable/wireless microphones were used, this setting will be recommended to close for dynamically catching the filters. (All) Manual: Enable (all) the manual setting (s) with Frequency, Bandwidth and Gain. This will disable the automatic detection.

  • Page 109: Crossover Mono

    DSP components Bypass: Disables the selected filter. Bandwidth: The transition bandwidth. Frequency: The frequency at which the phase shift crosses 90°. Graphical Window Axis X: Frequency of output signal(Hz) Y: Gain of output signal(dB) Control Points Purple: Frequency. Yellow: Bandwidth. 6.7.2 Crossover Mono The Crossovers will split the audio signal into separate frequency bands that can be separately...

  • Page 110: Crossover Stereo

    UAP G3 User Manual o Axis-X: Frequency of output signal (Hz). o Axis-Y: Level of input signal (dB). o Purple Control Point: frequency. 6.7.3 Crossover Stereo Enter topic text here. 6.7.3.1 Hi/Lo Pass Filter Allow to pass the high/low frequency and attenuate the frequency lower/higher than its cutoff frequency.

  • Page 111: Hi&Lo Pass Filter

    DSP components 6.7.3.2 Hi&Lo Pass Filter Allow to pass the high/low frequency and attenuate the specific frequency lower/higher than its cutoff frequency. Control Window Mode: The type of filtering. Bypass: Bypass the input signal to the output of Hi/Lo Pass Both component. Mute: Mute the output of Hi/Lo Pass Both component.

  • Page 112: Shelving Fliter

    UAP G3 User Manual Name Initial Minimum Maximum Precision Unit Slope 12dB Bypass Mute Bandwidth 1.00 0.01 2.00 0.01 Level -90.0 20.0 Freq. 22000 Element Description Mode: The type of filtering. Slope: The slope of attenuation, the higher slope means the drop speed levels are faster.

  • Page 113: Input

    DSP components Graphical Window o Axis-X: Frequency of output signal (Hz). o Axis-Y: Level of input signal (dB). o Purple Control Point: frequency (horizontal) and level (vertical). Input 6.8.2 6.8.2 The MI component allows to control and monitor the parameters of 4CH Mic/Line audio inputs signal. Component Appearance Control Window Bypass: Bypass the input signal to the output of MI component.

  • Page 114: Inverter

    UAP G3 User Manual Overload Thd. (dB): A threshold value to determine the signal of channel is overloaded or not. 6.8.3 MI-2 The MI-2 component allows to control and monitor the setting of the 2CH analog mic/line audio inputs signal.

  • Page 115: Level Control

    Name: The name of playing event. Type: o Message Player: Select either a message file from UAP G3/ G3H hardware or from external USB driver as the play source. o Path Player: Select a message folder from external USB driver as the play source.

  • Page 116: How-To

    UAP G3 User Manual The Path Player type does not need to add/edit/remove the message files due to it will play the audio source from a message folder, see the picture as below, Priority: The priority of the message event. The smaller the value is, the higher the priority is. The priority range is 1~99.
  • Page 117 DSP components CR Pin: Cancel the event for triggering messages and clear all of the logic signals. IR Pin: Interrupt. It will interrupt the messages and not play the messages. Pause Pin (P): It is used for stopping messages or continue the messages, it will restart exactly where the message is paused.

  • Page 118: Mixer

    UAP G3 User Manual Priority queue: If multiple message events are waiting to be played at the same time, the event with higher priority will proceed the message playing action, and the rest of message event will be placed at priority queue. Set the max. number of recording events in waiting queue (max.

  • Page 119: Gain Sharing Mixer Mm

    DSP components Output Mute: Mute or umute the mixed output signal. Output Level: The volume level of the channel's output signal. Mute: Mute or unmute the selected channel. Level: Increase or decrease the input level of channel. Thd. (dB): Set the threshold level to activate the channel when the level of mic input is above this value.

  • Page 120: Standard Mixer (Stereo/Mono Mixer)

    UAP G3 User Manual Matrix Mixer 8x8 Input Mute/dB: Mute the channel input or sets the master input level of the channel. Output Mute/dB: Mute the channel output or sets the master output channel of the channel. How to Use 1.

  • Page 121: Noise Generator

    DSP components 6.13 Noise Generator 6.13.1 Encrypted Sound Masking Encrypted Sound Masking can help make userr workplace more acoustically comfortable. It is the process of adding a low/high level and unobtrusive background sound to an environment in order to reduce the intelligibility of human speech for protecting private speech privacy and reduce noise distractions in an open workplace/environment.

  • Page 122: Tone Generator

    UAP G3 User Manual 6.13.3 Tone Generator Generate either a tone (single frequency) or a sweep sequence (between the two fixed frequencies and in a defined interval of time). Control Window Mute: Mute the component. Sweep: Activate the Sweep mode (sweep of frequency).
  • Page 123 DSP components Overload: Indicate the channel level above the chosen Overload Threshold (dB). Volume (dB): The meter shows the channel level. Mute: Mute the output signal. Signal: Light up when the signal is above -30dB level. Level (dB): The signal output level of the channel. Overload Thd.

  • Page 124: Page Control

    Vox+Contact: Activate the routing when both Vox and Contact modes are enable. TTL In: Activate the routing with a logical input or from UAP G3/ G3H Designer software, this function is worked with Contact Activation. Priority: The smaller the number is, the higher the priority is.
  • Page 125 DSP components already be occupied by another source. Component Appearance Control Window Audio Tab o Mode: 3 kinds of modes to trigger the paging action. Permanent: The paging source is always requested for paging. It's used when continues routing the audio to zones such as background music. Volume: The channel which requests for paging will be activated if the level signal is continuously higher than the 'Threshold' and over the 'Response Time'.
  • Page 126 UAP G3 User Manual o Hold Time (ms): Set the time between the end level's detection and the end of the paging (only for Volume Mode). o Mounting Event: Select a paging event for the zone selection. : Assign a paging event. The paging source, zones, codes, priority, etc. of each event can be adjusted.

  • Page 127: Peak/Rms Meter

    DSP components o Processor: Select a UAP G3/ G3H processor. o Paging component: Select a Network Paging component. o CH: Select an output channel intended to mute. 6.16 Peak/RMS Meter This component displays and monitor the amplitude of the incoming audio signal. There are two approaches available for measuring the signal.

  • Page 128: Selector

    UAP G3 User Manual Volume: Measure the value of the signal. 6.17 Selector 6.17.1 Input Selector The Input Selector component is able to assign one of channel input routed to a single output. The Input Selector has 7 kinds of components in different number of channel (4x1, 5x1, 6x1, 7x1, 8x1, 16x1, and 32x1).

  • Page 129: Source Type Shunt

    DSP components Trigger On: Light up If the input signal is activated or not. If the input signal is continuously greater than the Threshold over the Response Time, the Trigger On value will be set to 1 and the corresponding logic output is set to High. Threshold (dB): The threshold to determine if the audio input is activated.

  • Page 130: Usb Input/Usb Output

    6.20 USB Input/USB Output The USB Input and USB Output component allow to adjust the level of USB audio input/output. The USB interface refers to the mini-USB port on rear panel of UAP G3/ G3H. Component Appearance Control Window Mute: Mute the component.

  • Page 131: Udp Stream Transmitter

    Volume (dB): Display the volume of output channel. How to Use - Receiver Side For example, we want to receive the UDP streaming from the specific port of UAP G3/ G3H and output to a speaker. 1. Connect the UDP Stream Receiver component to an output channel on the working area as picture below.

  • Page 132: Voip

    6.22 VoIP The VoIP (Voice over Internet Protocol) component enables the UAP G3/ G3H to transmit and receive the audio signal through internet. Different from the UDP component, it's used for one-to-one networking applications. In addition, the DTMF (Dual-Tone Multi-Frequency signaling) is also supported - after the phone call has been received, press the number as codes on telephone for event trigger, network paging, etc..
  • Page 133 DSP components o Ring: Light up if receiving calls. o SIP: Light up when the call is busy (on the call). o Ready: Light up if it's in standby mode. It will light off when receiving call or the call is busy at the moment.

  • Page 134: Xpressor

    6. Double click the figure icon of SIP server, it will display a pop-up a window for entering the settings of SIP server. And click button to set the SIP account and password for this UAP G3/ G3H. 6.23 Xpressor This component is designed for suppressing local Echo or feedback.
  • Page 135 DSP components o Attack Time (ms): The needed time for changing the volume from the original level to the expected level. o Release Time (ms): The needed time for changing the volume from the expected level to the original level. Post-Processing: o Thd.

  • Page 136: Maintenance

    UAP G3/ G3H unit. If any loose parts rattle around on the inside when the UAP G3/ G3H unit is turned over in all directions, please shut down the UAP G3/ G3H unit immediately, as a loose part could lodge in a dangerous place and cause further damage or shock hazard.

  • Page 137: Technical Data

    Max. distance between 10m/33 ft (STP CAT5/6/7 cable) UAP G3/UAP G3H units Max. remote units via UAP 4 remote units per UAP G3-Link card and G3-Link connect 1 DGL-MIC mic at the end of bus Max. communication 250m/820ft (STP CAT5/6/7 cable, metal...
  • Page 138 UAP G3 User Manual distance between remote shielded RJ45 connector) units Audio Characteristics (Line In & Line Out) Output level 0 dBu (headphone) Output level 0 dBu (audio line out) Output impedance 30 ohm Sampling rate 48k Hz Frequency response 20 Hz ~ 20k Hz <...

  • Page 139: Contact Information

    Contact information Contact information www.paxproavgroup.com/ © 2022, ATEÏS. All rights reserved.
  • Page 140 UAP G3 User Manual http://www.ateis.com ATEÏS Europe B.V. ATEÏS Far East Asia Crop. Europe & Africa Far-East Asia No.60, Xinghua 2nd Rd, Tanzi, Celsiusstraat 1 - 2652 XN Lansingerland Taichung 427, Taiwan (Rotterdam Region), Netherlands Tel: +886-4-25333820 Tel: +31 (0)10 2088690 Fax: +886-4-25333830 info@ateis-europe.com...

This manual is also suitable for:

Uap g3h

Table of Contents
