Operating instructions and product features
Initial startup (m, ° C, 24h)
The functions of the Traveller can be checked
when the battery is inserted:
> Segment check
> Beep tone
> Background lighting Is the light switched on
After this automatic function test, the present
altitude is first displayed briefly after which the
display changes over to the time mode. The
European system of units (height = m, tempera-
ture = ° C, time mode = 24h) is already preset.
Initial startup (ft, ° F, 12h)
To set the American system of units (height = ft,
temperature = ° F, time mode = 12h). Insert new
battery, press the Victorinox emblem while
closing the battery compartment. The function
test then takes place as described above.
C = continuous pressure
Page 1 of 8
Do all segments light up?
Is a sound heard?
briefly?
Qd-00029.doc
Traveller
Traveller Lite
Expedition Lite
Choice of menu
Press the Victorinox emblem briefly to select the
desired menu.
If the button is not pressed for more than 30 min
in the "Altimeter", "Alarm" and "Temperature"
menus, the display automatically reverts to the
time mode.
Background lighting
Press the Victorinox emblem for 1.5 seconds to
switch the background lighting on. The light goes
out again 3 seconds after the last actuation. The
background lighting is automatically switched off
on changeover to the setting mode (except in the
alarm function).
Version 12.06.07
Advertisement
Related Manuals for Victorinox Expedition Lite
Summary of Contents for Victorinox Expedition Lite
- Page 1 Traveller Traveller Lite Expedition Lite Choice of menu Press the Victorinox emblem briefly to select the desired menu. If the button is not pressed for more than 30 min in the "Altimeter", "Alarm" and "Temperature" menus, the display automatically reverts to the time mode.
- Page 2 Setting watch Press the Victorinox emblem for 4 seconds until the display flashes. Now release the Victorinox emblem again. You have changed to the time setting mode. The arrow shows the current setting direction. The change takes place automatically. If the Victorinox emblem is pressed for longer than this (min.
- Page 3 The arrow shows the present adjustment direc- tion. The changeover is automatic. If the Victorinox emblem is pressed for a longer period (at least 6 seconds), the adjusting speed is increased (20 digits/s). Brief pressure on the Victorinox emblem changes the display by 1 digit (meter).
- Page 4 Altitude setting with weather correction The altitude calculation is made using the inter- national altitude formula. This is based on an average air temperature value and pressure distribution. The different air pressure must be set before leaving on a hike by entering the known present altitude.
- Page 5 Barometer display reset Press the Victorinox emblem for 4 seconds to reset the display. If the difference between two measured values is too great, the barometer is automatically reset.
- Page 6 The arrow indicates the present setting direction. The change takes place automatically. If the Victorinox emblem is pressed for longer (at least 6 seconds), the adjustment speed is in- creased (20 digits/s). Page 6 of 8...
- Page 7 Setting Countdown Press the Victorinox emblem for 2 seconds until a beep tone is heard and the display flashes. Release the Victorinox emblem again. You have now changed to the countdown setting mode. The arrow indicates the present setting direction.
- Page 8 Setting combinations (Temperature menu) Press the Victorinox emblem for 8 seconds until the display flashes. Release the Victorinox emblem again. You have now changed over to the unit setting mode. By pressing the Victorinox emblem briefly while the display is flashing, the temperature and altitude units can be changed (see illustration).
