- Page 1 ELECTRO-OPTICS BUCKMASTERS ™ BUCKMASTERS™ 10X42MM BINOCULARS OPERATOR’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Contents: Key Features: Product Identification: Operation Cleaning SIG SAUER Electro-Optics Infinite Guarantee /Limited Lifetime Warranty ® Please visit sigsauer com for Operator’s Manuals downloads WARNING: CANCER AND REPRODUCTIVE HARM—www.P65warnings.ca.gov... -
Page 3: Introduction
It has totally amazed me how the technology of our sport has grown Now we have partnered with one of the best brands in the industry, SIG SAUER SIG Electro-Optics are top quality, with built-in technology that is in a class of its own Check out the new SIG Buckmasters line of riflescopes, rangefinders, and binoculars this fall at your favorite retailer. -
Page 4: Contents
CONTENTS: • BUCKMASTERS™ Binoculars • Eyepiece and Objective Lens Cover • Binocular Harness Strap • Neck/Shoulder Strap • Lens Cloth • Padded Ballistic Nylon Case... -
Page 5: Key Features
KEY FEATURES: • Fully multi-coated lenses • Closed bridge design • BAK-4 Prism • IPX-7 rated (Protected against water immersion for 30 minutes at a depth of up to 1 meter) • Tripod mount capable • Multi-Position eye cups... -
Page 6: Product Identification
PRODUCT IDENTIFICATION: A Adjustable Eye Cups B Diopter Ring C Strap Attachment D Focus Wheel E Objective Lens F Tripod Adapter Cover BUCKMASTERS™ BINOCULARS SHOWN... -
Page 7: Operation
OPERATION SETTING THE DIOPTER ADJUSTMENT Setting the diopter adjustment of your binocular is very important, as properly adjusted binoculars will prevent eye strain and provide you with a crisp, sharp image To set the diopter adjustment on right eyepiece diopter adjustment models: 1 View an object about 100 yards in the distance CENTER FOCUS WHEEL 2 Close your right eye... - Page 8 4 Close your left eye 5 Adjust the diopter ring located around the right barrel, near the eyepiece, until the image presented to your right eye is clear and sharp DIOPTER RING Your binocular is now focused for your eyesight. To make any adjustments in the field, simply turn the center focus wheel while viewing through both barrels ADJUSTABLE EYECUPS...
- Page 9 INTERPUPILLARY DISTANCE OF BINOCULARS Interpupillary distance is the distance between your right and left eye 1 Set the distance between the centers of the right and left ocular lens of the binoculars to your interpupillary distance 2 Look at a distant object to make an adjustment while folding back the main body of the binoculars 3 Your interpupillary distance is correctly set when the field of view can be seen by both eyes as a single circle (see below illustration)
-
Page 10: Cleaning
CLEANING CAUTION IMPROPER CLEANING CAN RESULT IN SCRATCHES TO YOUR BINOCULAR LENSES. • Clean the fully armored body by simply wiping off any accumulated dirt or dust. • Clean the lenses only when necessary • Use a standard lens brush/blower brush first, to remove dust and debris from the lenses. •... - Page 11 BUCKMASTER™ BINOCULAR SPECIFICATIONS Model/Magnification 10x42mm Eye Relief 15mm Exit Pupil 4 2mm Linear FOV FT @ 1000 yards 315 ft Linear FOV FT @ 1000 meters 105 m Objective Clear Aperture 42mm Angular FOV 6 degrees Close Focus Distance 8 2 ft Interpupillary Distance 58mm - 73mm Diopter Range...
-
Page 12: Sig Sauer Electro-Optics Infinite Guarantee ® /Limited Lifetime Warranty
We understand the importance of quality in the line of fire, at the shooting range or on your next hunt SIG SAUER Electro-Optics had to earn the right to wear that badge and the Infinite Guarantee has your back, forever. Period. - Page 13 Please note that our Infinite Guarantee excludes coverage for intentional damage, misuse, cosmetic damage that does not affect the performance of the optic, loss, theft, or unauthorized repair or modification. Excludes electronic and Tritium components. Customers seeking warranty coverage must first obtain a Return Merchandise Authorization (RMA) by contacting SIG SAUER Customer Service, and return the product unloaded and freight prepaid ANY WARRANTIES IMPLIED BY LAW, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED.
- Page 14 SIG SAUER ELECTRONIC COMPONENT LIMITED 5-YEAR WARRANTY ® SIG SAUER warrants that the electronic and tritium components of the enclosed product were originally manufactured free of defects in workmanship, material, and mechanical function. For a period of five (5) years from the date of manufacture, SIG SAUER agrees to correct any defect in these components by repair, adjustment, or replacement, at SIG SAUER’s option, with the same or comparable quality components (or by replacing the product at SIG SAUER’s option);...
- Page 15 Some states do not allow the exclusion or limitation of implied warranties, or the exclusion or limitation of incidental or consequential damages, so some or all of the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from State to State THIS WARRANTY APPLIES TO COMMERCIAL CUSTOMERS ONLY, AND DOES NOT APPLY TO GOVERNMENT, MILITARY, LAW ENFORCEMENT, OR NON-US CUSTOMERS.
- Page 16 sigsauer.com sigsauer.com FOR PRODUCT SERVICE ON THIS MODEL, PLEASE CALL 603-610-3000 FOR PRODUCT SERVICE ON THIS MODEL, PLEASE CALL 603-610-3000 27100 SW Parkway Avenue, Wilsonville, OR 97070 USA 27100 SW Parkway Avenue, Wilsonville, OR 97070 USA 72 Pease Boulevard,Newington, NH 03801 USA 72 Pease Boulevard,Newington, NH 03801 USA All trademarks, service marks, trade names, trade dress, product names and logos appearing in this manual are the property of their respective owners.
