Feasycom FSC-SYR16-7DB Instruction Manual

Long-distance range ultra-high frequency electronic label reader

Advertisement

Quick Links

FSC-SYR16-7DB
Long-distance range ultra-high frequency
electronic label reader
Instruction manual
Shenzhen Feasycom Co.,Ltd
www.feasycom.com
Page 1 / 11

Advertisement

Table of Contents
loading

Summary of Contents for Feasycom FSC-SYR16-7DB

  • Page 1 FSC-SYR16-7DB Long-distance range ultra-high frequency electronic label reader Instruction manual Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 1 / 11...
  • Page 2: Table Of Contents

    4、ID neighbor discrimination ..........................7 三、Read-write configuration ............................7 四、Read-write installation ............................8 1、Read-write installation .............................8 2、Read-write fixed and height adjustment ......................9 3、Read-write azimuth adjustment ........................9 4、Installation examples - vehicle parking lot management ................10 Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 2 / 11...
  • Page 3: 一、Introduction

    Less than 6ms per 64bits average read time for a single card, set by software 0-5 m (0~8 m for high power) (The reading distance is related to the tag and the field Reading distance environment) Operating -40℃~+65℃ temperature Storage -45℃~+95℃ temperature Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 3 / 11...
  • Page 4: 2、Read-Write Size Structure

    2) Motor vehicle management: monitoring and management of various motor vehicles by public security, traffic and other departments; 3) Road and bridge tolls: due to the product has a long-distance high-speed reading tag data, road Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 4 / 11...
  • Page 5 It is recommended that during the test, there should not be any objects blocking the reader within at least Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 5 / 11...
  • Page 6: 二、The Read-Write Mode Of Operation And Wiring Instructions

    1.8M, and the diameter of the vertical pole is 30-50CM. Installation Diagram Holding rod diameter 30-50mm Read-write working mode and wiring description 、 1、Wiring instructions for the reader Black Green White Grey Purple DC+(7-12V) WG-D1 WG-D0 2、Tag operation Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 6 / 11...
  • Page 7: 3、The Way Of Work

    Commonly used in Wiegant communications. III、Read/Write Configuration Our company provides DEMO software programme for configuring the working parameters of the reader/writer. The interface of the parameter configuration picture is shown below: Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 7 / 11...
  • Page 8: 四、Read-Write Installation

    For DEMO software use, please refer to the UHF Setup Software Manual. IV、Installation of the reader 1、Installation of the reader Back of the reader Mounting Clip Codes brackets Shenzhen Feasycom Co.,Ltd www.feasycom.com Page 8 / 11...
  • Page 9: 2、Read-Write Fixed And Height Adjustment

    2.2m, and it is preferable to use stainless steel with a wall thickness of more than 1.2mm. Use the fasteners provided in the FSC-SYR16-7DB reader box to fix the reader to the top of the pole. Adjust the height from the centre of the FSC-SYR16-7DB reader to the level of the lane according to the type of vehicle (mainly referring to large and small vehicles), which is usually about 2.0m (1.8 to...
  • Page 10: 4、Installation Examples - Vehicle Parking Lot Management

    4、Installation example - park of vehicle car management The principles for selecting the installation location of the FSC-SYR16-7DB reader system are: 1) FSC-SYR16-7DB read-write and the straight-line distance from the road gate should not exceed 1 metre 2) FSC-SYR16-7DB read-write location and the tag card without any items between the blockage...
  • Page 11 In this case: the requirements FSC-SYR16-7DB reader should be close to the road gate equipment, at the same time so that the effective range of its read tag (the farthest straight line away from 0.5 m to 8 m) can cover the entrance and exit of the inlet and outlet of the ground sensing coils or ground sensing coils, as shown in the picture below.
