- Page 1 MODEL GGSCC6004K V1.1b 0923 User Manual 60cm Ceramic Cooktop...
- Page 2 GGSCC6004K Welcome Residentia Group Congratulations on purchasing your new 60cm Ceramic Cooktop. — Sôlt is proudly distributed within Australia by Residentia Group Pty Ltd. Head Office 165 Barkly Avenue Please refer to the warranty card at the rear of this manual for information Burnley Victoria regarding your product’s parts and labour warranty, or visit us online at:...
-
Page 3: Table Of Contents
User Manual Contents Safety Information Installation Instructions Your Cooktop Operating Instructions Cleaning & Maintenance Troubleshooting Technical Specifications Purchase Details Warranty Information Customer Care Sôlt recommends the use of original spare parts. When contacting our customer service team by calling 1300 11 4357, or by e-mailing support@residentiagroup.com.au, please ensure that you have the following information at hand. -
Page 4: Safety Information
GGSCC6004K Safety Information Conditions of Use Operation & Maintenance This appliance is intended to be used in household • Do not cook on a broken or cracked cooktop. If the and similar applications such as farm houses or by cooktop surface is break or crack, switch the appliance... - Page 5 User Manual • Do not store items of interest to children in cabinets • WARNING: Unattended cooking on a hob with fat or above the appliance. Children climbing on the cooktop oil can be dangerous and may result in fire. NEVER try to could be seriously injured.
-
Page 6: Installation Instructions
GGSCC6004K Installation Instructions Preparing the Cut-Out • Cut out the work surface according to the sizes shown SEAL in the diagram below. • For the purpose of installation and use, ensure you leave a minimum of 5cm space around the cut out. - Page 7 User Manual Preparing the Cut-Out Ensuring Adequate Ventilation • Under all circumstances, make sure the ceramic cooktop • Make sure the ceramic cooktop is well ventilated and is well ventilated and the air inlet and outlet are not that air inlet and outlet is not blocked. In order to avoid blocked.
- Page 8 GGSCC6004K Installation Instructions (continued) Applying the Fixing Brackets • The unit should be placed on a stable, smooth surface (such as the packaging). Do not apply force onto the controls protruding from the hob. Fix the hob on the work surface by screwing in the four brackets on the bottom of hob after installation (see diagram below).
- Page 9 User Manual Connecting the Hob to the Mains Power Supply • The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. The method of connection is shown below. L-N:220–240V~ • If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents.
-
Page 10: Your Cooktop
GGSCC6004K Your Cooktop Top View 1. Max. 1200W Zone 3. Max. 1800W Zone 5. Controls 2. Max. 1800W Zone 4. Max. 1200W Zone 6. On/Off... -
Page 11: Operating Instructions
User Manual Operating Instructions Using the Touch Controls • Read this guide carefully, taking special note of the ‘Safety Information’ chapter. • Ensure you remove any protective film that may still be on your ceramic hob. • The controls respond to touch, so you don’t need to apply any pressure. - Page 12 GGSCC6004K Operating Instructions (continued) Cooking With Your Ceramic Cooktop After powering on, the buzzer tone will beep once, the indicators will then light up for 1 second before, indicating that the ceramic hob has entered standby. • Touch the ON/OFF power control.
-
Page 13: Cleaning & Maintenance
User Manual Cleaning & Maintenance Care & Cleaning Guide Marks, Blemishes or Spots Solution Warning Everyday soiling on glass. Switch the power to the When the power to the cooktop is cooktop off. switched off, there will be no ‘hot (fingerprints, marks, stains left by surface’... -
Page 14: Troubleshooting
GGSCC6004K Troubleshooting Hints & Tips Problem Possible Cause Solution Cooktop cannot be powered on. No power. Make sure the cooktop is connected to the power supply and that it is switched on. Check whether there is a power outage in your home or area. If you’ve checked everything and the... -
Page 15: Technical Specifications
User Manual Technical Specifications Model GGSCC6004K Cooking Zones 4 × Zones Power Supply 220–240V~, 50Hz or 60Hz Rated Power 6000W Product Dimensions (W × D × H mm) 590 × 520 × 50 mm Cut-Out Dimensions (W × D mm) 560 ×... -
Page 16: Purchase Details
GGSCC6004K Purchase Details For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO. - Page 17 User Manual Notes...
-
Page 18: Warranty Information
GGSCC6004K Warranty Information WARRANTY TERMS AND CONDITIONS IN THIS WARRANTY CERAMIC COOKTOP ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in This document sets out the terms and conditions of the the ACL;... - Page 19 User Manual You will bear the cost of transportation, travel and For Appliances and services provided by Residentia delivery of the Appliance to and from Residentia Group Group in Australia, the Appliances come with a or its ASR. If you reside outside of the service area, you guarantee by Residentia Group that cannot be excluded will bear the cost of: under the Australian Consumer Law.
- Page 20 An initiative by Residentia Group T. 1300 11 4357 E. support@residentiagroup.com.au www.solt.house...
