Protector Circuit Board Ass'y
141810735
141810730
141810710
141810703
648211118
648211141
649201115
628111111
649201118
648211135
625001115
6261 10026
624200204
624200206
624201101
651300018
654911295
787121126
138011283
124011289
111911370
670101111
116310204
116310157
116310147
116210035
725224008
for Regular Type Units
Power Supply & Overload
Protection Circuit Board Ass'y
for European Type Units
DIN IN/OUT Circuit Board
Ass'y
Function Indicator Circuit
Board Ass'y
FM Stereo Ind Circuit Board
Ass'y and Overload Ind Circuit
Board Ass'y
Bracket, Power Transistor
AC Outlet
Antenna Termina! Strip
Socket, FM 75Q Antenna
Speaker Terminal
Bracket, Dial Lamp
DIN Socket, 5P
Headphones Receptacle
4P Pin Jack, Tape Monitor, etc.
6P Pin Jack, Phono
& AUX
1P Pin Jack, FM Det Out
Dial Drum with Spring
Tuning Shaft with Flywheel
Dial String
Top Cover
Bottom Cover
Front Panel
Handie, Front Panel
Knob, Tuning
Knob, Function,
Volume, etc.
Knob, Lever Switch
Button, Push Switch
Screw, 4 x 8mm, Top Cover
Mtg
* not used in European Type Units.
7
FINISH
START
Note:
Carry out stringing with the front end
set at VC minimum.
Zur Beachtung:
Antriebsseil mit dem Drehko
der Eingangsstufe in Minimumstellung
verlegen.
Note:
Effectuer le cablage avec le condensateur
réglable de i'étage d'entrée réglé au minimum.
