Gendome Home3000 User Manual

Portable power station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Home3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gendome Home3000

  • Page 5 Home 3000 Portable Power Station User Manual...
  • Page 6 Please read this user manual carefully and use the product correctly. About all safety tips, warning messages, terms of use, and disclaimers at: https://www.gendome.com/pages/faq...

  • Page 7: Table Of Contents

    CONTENTS 1. Specifications ............................1.1 Basic Info ............................1.2 Output ............................... 1.3 Input ........................... 1.4 Battery Module ..........................1.5 Temperature ............................1.6 Others 2. Safety Instructions ............................2.1 Caution ............................2.2 Warning ....................2.3 FCC Compliance Statement 3. Instructions for Beginners ..........................
  • Page 8 ....................18 3.5.2 Solar Power Charging ..................... 3.5.3 Wind Power Charging ......................... 3.5.4 External Battery ........................... 3.6 Use of APP ..........................3.7 UPS Function 4. Equipment Inspection and Storage ....................4.1 Inspection before Acceptance ........................4.2 Equipment Storage 5. Fault Indication and Troubleshooting ......................

  • Page 9: Specifications

    1. SPECIFICAITONS 1.1 Basic Info Weight 83.8lbs / 38kg Dimensions (L*W*H) 22.0*9.1*21.4 in / 560*230*543 mm Battery Capacity 3072Wh Support Wi-Fi Support Bluetooth 1.2 Output AC Output (×5) Max 3000W (Surge 6000W) USB-A (×4) Max 18W, 5V 3A/9V 2A/12V 1.5A PD3.1, Max 140W, 5V 3A/9V 3A/12V...

  • Page 10: Battery Module

    1.4 Battery Module Nominal Voltage 51.2V Battery cell EV-Grade LFP Cycle Life 2500 cycles to 80+% capacity, max 6500 cycles High temperature protection, low temperature protection, over discharge protection, over charge protection, Protection overload protection, short circuit protection, over current protection.

  • Page 11: Safety Instructions

    2. SAFETY INSTRUCTIONS 2.1 Caution Risk of Electric Shock. Do not remove the cover. No user serviceable parts inside. Refer servic- ing to qualified service personnel. For continued protection against risk of fire, replace only with the same type and rating of fuse.

  • Page 12: Instructions For Beginners

    3. INSTRUCTIONS FOR BEGINNERS 3.1 Application Portable power stations are widely used for power supply to almost all electrical products through interface conversion. In addition to charging through utility power input interface, equip- ment charging through solar power charging interface and wind power charging interface are also available.

  • Page 13: Dimensions

    3.2 Dimensions 560mm a. Length and Height 230mm 230mm AC ON OFF POWER ON OFF IOT RESET DC ON OFF USB-C 140W USB-C 140W 15A MAX USB-A 18W USB-A 18W DC 12V 120W USB FAST CHARGE 30A 125V~ GRDG 12V 360W MAX 15A MAX FAST SLOW...

  • Page 14: Display And Interfaces

    3.3 Display and Interfaces 3.3.1 Display INPUT OUTPUT OUTPUT Remaining Time: -- h -- m Use Status...

  • Page 15: Description Of Functions

    3.3.2 Description of Functions Name Icon Display Description Represents the specific power level, the Battery Percentage value ranges from 0% to 100%. It is dynamically displayed according to the actual value of the power. It displays green Power Ring when the power is higher than 50%. it displays yellow when the power is between 20% ~ 50%.
  • Page 16 3.3.2 Description of Functions Name Icon Display Description Represents the ON/OFF state of the DC DC Output switch, it is always on when DC switch is turned on, and it is gray when turned off. Represents the external battery pack of the device.

  • Page 17: Device Side Interfaces

    3.3.3 Device Side Interfaces AC ON OFF POWER ON OFF IOT RESET DC ON OFF USB-C 140W USB-C 140W 15A MAX USB-A 18W USB-A 18W DC 12V 120W USB FAST CHARGE 30A 125V~ GRDG 12V 360W MAX 15A MAX FAST SLOW OVERLOAD AC INPUT...

  • Page 18: Main Power Switch & Dc Output Interfaces

    3.3.4 Main Power Switch & DC Output Interfaces POWER ON OFF IOT RESET DC ON OFF USB-C 140W USB-C 140W USB-A 18W USB-A 18W DC 12V 120W USB FAST CHARGE 12V 360W MAX Hold the switch for 3 seconds to turn on/off Main Power Switch the equipment.

  • Page 19: Ac Output Interfaces

    3.3.5 AC Output Interfaces AC ON OFF 15A MAX 30A 125V~ GRDG 15A MAX Short press the button to turn on/off AC output, AC Output Switch including four 15A outlet and one 30A outlet. It provides an output of up to 30A for electrical 30A AC Port appliances.

  • Page 20: Input Interfaces

    12~75V and a charging power of up to 1500W. It can be connected to a battery pack manufac- Battery Pack Parallel tured by Gendome to increase the equipment Operation Port capacity. It can be connected to wind power charging, pro-...

  • Page 21: Product Operation

    3.4 Product Operation 3.4.1 Turn on, Shutdown, and LED Lighting Press and hold the power button for 3 seconds, after a "beep" sound, the power is on. The LED screen lights up and the main power indicator enters the breathing light mode. When the product does not operate for 2 minutes, it will enter the sleep mode.

  • Page 22: Dc Output

    3.4.2 DC Output The DC output is off by default after the device turning on. The light indicator on the button is off, and there is no power output. After short pressing the DC on/off button, the power output is turned on.

  • Page 23: Ac Output

    3.4.3 AC Output The AC output is off by default after the device turning on. The light indicator on the button is off, and there is no power output. After short pressing the AC on/off button, the power output is turned on. The light indicator on the button is on, and power output is ready to use. Short press the button again to turn off AC output.

  • Page 24: Charging

    There are two modes for AC charging: fast charging and slow charging. The maximum input power of fast charging mode is 1800W, and can be adjusted from 500 to 1800W in Gendome App. The maximum input power of slow charging mode is 500W, and cannot be adjusted.
  • Page 25 AC CHARGE SPEED PROTECTION SOLAR 1500W WIND 200W INPUT 12-75V BATTERY-1 BATTERY-2 Please use the original Gendome charging cable in the box for AC charging. Gendome responses no liability for the damage caused by ATTENTION using other non-genuine charging cables.

  • Page 26: Solar Power Charging

    3.5.2 Solar Power Charging Users shall connect solar panels in series to charge the product as shown in the figure. The product supports DC input voltage from 12V to 75V and charging power up to 1500W. AC ON OFF 15A MAX 30A 125V~ GRDG 15A MAX...

  • Page 27: Wind Power Charging

    3.5.3 Wind Power Charging The device supports up to 200W wind power input. As the below instruction, the device can be charged by the wind turbine by a wind power cable. Please make sure input power of the wind turbine is between 12~75V before charging.cable. WIND 200W AC ON OFF 15A MAX...

  • Page 28: External Battery

    3.5.4 External Battery This product can be connected to up to two external battery packs at the same time to provide a larger capacity. Please pay attention to the following matters during operation: Before connecting the equipment to an external battery pack, please make sure that the product and the external battery pack are both turned off.

  • Page 29: Use Of App

    3.6 Use of APP Users may control and view information and data about this product through the Gendome App. For more information about the download and use of the App, please check Gendome official website: www.gendome.com Download APP 3.7 UPS Function This product supports UPS (Uninterruptible power supply).

  • Page 30: Equipment Inspection And Storage

    4. EQUIPEMENT INSPECTION AND STORAGE 4.1 Inspection before Acceptance Before signing for the product, please check the following in detail: Check the outer package for damage, such as deformation, holes, cracks or other signs that may cause damage to the equipment in the packing box. If any, do not unpack and contact your dealer.

  • Page 31: Fault Indication And Troubleshooting

    5. FAULT INDICATION AND TROUBLESHOOTING 5.1 End-of-Life Equipment If the product cannot serve anymore and scrap is required, please dispose of it according to the laws and regulations concerning the electrical waste disposal of the country/region where the product is used. It shall never be disposed of as domestic waste or discarded at will. 5.2 Troubleshooting List of Fault Codes Indicated on Display: Codes...
  • Page 32 Codes Definition Solution Over-Current Protection, Please reduce the connected equipment and turn on the AC Over-Current Protection or DC switch again. Overload Protection, Please reduce the input source and restart again. Overload Protection If the issue is still not fixed, please contact customer service.

  • Page 33: Maintenance And Preservation

    6. MAINTENANCE AND PRESERVATION 6.1 Maintenance Items Methods Cycle Once every half year to Check the cooling fin and air inlet/out- Product once a year let for foreign matters and dust. Cleaning Check whether the fan operates nor- Once a year m a l l y , w h e t h e r t h e r e i s n o i s e a n d whether the appearance is normal.

  • Page 34: In-The-Box

    7. IN-THE-BOX Gendome Home 3000 AC Cable Solar Cable Wind Turbine Cable XT60 Cable User Manual Download APP...
