Wall mount bracket for DWC-XPZA cameras
1x Machine Screw, HM3 x 8 (Adapter Screw)
1x Silicon Cap (30 x 11mm)
1x O-Type Waterproof Ring (1.5 x 2mm)
1x Waterproof Mounting Pad (167 x 122 x 41.5mm)
4x Tapping Mounting Screws
1x Quick Setup Guide
NOTE:
Download all your support materials and tools in one place.
1.
Go to: http://www.digital-watchdog.com/resources
Search your product by entering the part number in the 'Search by Product' search bar. Results
2.
for applicable part numbers will populate automatically based on the part number you enter.
3.
Click 'Search'. All supported materials, including manuals and quick start guide (QSGs) will
appear in the results.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
DWC-XPZAWM
WHAT'S IN THE BOX
Quick Start Guide
digital-watchdog.com
Advertisement
Table of Contents
Summary of Contents for DW DWC-XPZAWM
- Page 1 Quick Start Guide Wall mount bracket for DWC-XPZA cameras DWC-XPZAWM WHAT’S IN THE BOX 1x Machine Screw, HM3 x 8 (Adapter Screw) 1x Silicon Cap (30 x 11mm) 1x O-Type Waterproof Ring (1.5 x 2mm) 1x Waterproof Mounting Pad (167 x 122 x 41.5mm)
- Page 2 Quick Start Guide INSTALLATION Mark and drill the necessary holes on the mounting surface using the mounting bracket itself. Secure the mounting bracket to the mounting surface using the tapping screws included with the mount. Use the waterproof mounting pad between the bracket’s arm and the mounting surface as needed.
