- Page 2 Introduction This camera is designed for use as a front view or rear-facing backup camera, and mounted neatly behind your license plate. When installed with any of our camera-capable head units, the camera view can be automatically triggered when shifting into reverse or manually triggered by selecting the camera button from the head unit home screen.
- Page 3 Wiring • Follow two steps described below to install this product as a front camera or a rear camera. • The rear camera view automatically turns on when reversing. Ensure you connect the “ ” wire on your head unit to the vehicle’s Reverse Input reverse light for reverse trigger.
- Page 4 Mounting The camera is designed for mounting behind the license plate of your car through the screw holes on the license plate. No drilling hole is required. Remove the license plate lamp. Through the opening of the license plate lamp, run the camera’s cable from the outside into the inside of the car.
- Page 5 Image Setting • To remove the on-screen parking guidelines, cut open the white wire loop which splits from the camera’s cable. Otherwise, keep the white wire loop uncut. • If the camera image appears reverse, cut open the blue wire loop which splits from the camera’s cable.
