Summary of Contents for Sonero X-AVT110
- Page 1 HDMI TESTING METER INSTRUCTION MANUAL X-AVT110 Version: 2018-08-22...
-
Page 2: Table Of Contents
TABLE OF CONTENT Introduction Intended Use Safety Instruction Delivery Contents Features Specifications Connection Plan Interface Operation Maintenance Cleaning Warranty and Liability CE Conformity Disposel of the Device FCC compliance statement Disclaimer - 2 -... -
Page 3: Introduction
INTRODUCTION The HDMI Testing Meter from Sonero enables the reading of resolution, HDCP version as well as colour space and depth The results can be read off using the LCD display. Test the specifications of monitors/displays quickly and easily During operation, power is supplied via the micro USB... -
Page 4: Delivery Contents
Do not leave packaging material lying around carelessly These may become dangerous playing material for children Suffocation Risk! Keep packaging materials away from children! Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity, moisture, flammable gases, vapors and solvents. Do not place the product under any mechanical stress If it is no longer possible to operate the product safely, take it out of operation and protect it from any accidental use Safe operation can no... -
Page 5: Features
FEATURES Compliant with HDMI1.4/2.0 Specifications Compliant with HDCP1.4/2.2 Specifications Detect resolutions up to 4K2K@60Hz Detect HDCP version for 1 x or 2 x Detect Colour Space 4:4:4, 4:2:2 or 4:2:0 Micro USB port for power SPECIFICATIONS Product Size in mm: 69x22x 11mm Product Weight in g: Power... -
Page 6: Connection Plan
CONNECTION PLAN HDMI MICRO USB FOR POWER 720P 1080P 4K / 30Hz 4K / 60Hz 4K/60Hz HDCP2 X YUV 4:4:4 24Bit 4:2:0 24 Bit 4:2:2 30 Bit 4:4:4 36 Bit 48 Bit - 6 -... -
Page 7: Interface
INTERFACE MODEL NO.: X-AVT110 CHARGE NO.: XXXX PureLink GmbH Von-Liebig-Str. 10 | D-48432 Rheine | www.purelink.de - 7 -... -
Page 8: Operation
OPERATION A. Detect resolution range: 720p, 1080p, 4K/30Hz & 4K/60Hz B. Detect HDCP range: 1.x & 2.x C. Detect colour space range: 4:2:0, 4:2:2 & 4:4:4 a. 24 Bit/Pixel=8 bits/colour b. 30 Bit/Pixel=10 bits/colour c. 36 Bit/Pixel=12 bits/colour d. 48 Bit/Pixel=16 bits/colour MAINTENANCE There are no components located inside the product that require maintenance Never open or attempt to dismantle the product... -
Page 9: Warranty And Liability
To clean the product, use a soft, dry cloth Do not apply too much pressure to the housing as this may cause scratch marks You can easily remove dust using a soft bristled brush WARRANTY AND LIABILITY The manufacturer guarantees full statutory warranty terms on all new devices As the manufacturer has no influence on installation, warranty only applies to the product itself... -
Page 10: Ce Conformity
CE CONFORMITY PureLink GmbH hereby declares that this product X-AVT110 complies with Directive 2014/30/EU. The full text of the EU Declaration of Conformity is available at the following Internet address: www.purelink.de/ce/4251364709795_CE.pdf DISPOSEL OF THE DEVICE WEEE-Reg No : DE 93 847 290... - Page 11 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications However, there is no...
-
Page 12: Disclaimer
All rights reserved We reserve our right for misprints and changes to the device, packaging or user manual HDMI is a registered trademark of HDMI Licensing Administrator, Inc ® Sonero ® PureLink GmbH Von-Liebig-Straße 10 D-48432 Rheine info@purelink de www purelink de...
