LED MADE SIMPLE.
Shipping Dimensions & Weight:
25ft. spool | 8.3" x 8.3" x 4.2", 4.6 lbs
50ft. spool | 8.3" x 8.3" x 6.5", 7.7 lbs.
164 ft. spool |13" x 13" x 9.1", 24.6 lbs.
PRODUCT FEATURES:
ETL Certified
Dimmable
Cuttable every 12 inches (1 ft.)
Controlled with DMX Decoder/Controller
50,000+ hours of rated life
UV protected and fire retardant
PERFORMANCE:
Color
Model
RGB
LUM-B34XTS-025 (25ft. reel)
LUM-B34XTS-050 (50ft. reel)
LUM-B34XTS-164 (164ft. reel)
USES:
• Cove, Soffit, Indirect Lighting
• Commercial Building Exteriors & Signage
• Aquariums & Stages, Concert Venues
• Casinos, Nightclubs, Bars, Resorts
• Accent & Decorative Lighting
©Lumilum LED Lighting
LUMILUM 120V LED LIGHT STRIP
120V B34XTS SERIES
SPECIFICATIONS:
SKU:
Available Colors:
IP Rating:
Voltage:
Power Output:
Reel Length:
Dimensions:
CRI:
LED Diodes:
Chip Type:
Lumens:
Operating Temp:
WARRANTY
3 YEAR
Color
CRI
Lumen/
Temp.
ft.
Color
-
-
Changing
Page 1 of 5
LUM-B34XTS
RGB (Color Changing)
IP65 (Indoor and Outdoor)
120V AC
3 Watts/ft.
164 ft. (50 meters)
0.70" X 0.33" Inches (W X H)
-
24/ft.
SMD 5050
-
-13°F ~ 113°F
Beam
Power
Angle
Consumption/ft.
120°
3W
• Architectural Design & Wall Washing
• Restaurants, Hotels, Spas, Theaters
• Bridges, Columns, Exterior Structures
• Patios, Paths, Decks, Fences
• Game & Play Rooms
IP65
Voltage
Current/ft.
120V
0.03A
(305)-233-2844
www.lumilum.com
Advertisement
Related Manuals for Lumilum B34XTS Series
Summary of Contents for Lumilum B34XTS Series
- Page 1 LUMILUM 120V LED LIGHT STRIP 120V B34XTS SERIES LED MADE SIMPLE. Shipping Dimensions & Weight: SPECIFICATIONS: 25ft. spool | 8.3” x 8.3” x 4.2”, 4.6 lbs 50ft. spool | 8.3” x 8.3” x 6.5”, 7.7 lbs. SKU: LUM-B34XTS 164 ft. spool |13” x 13” x 9.1”, 24.6 lbs.
- Page 2 LUM-B34SJW3X-500 LUM-B34SJW4X-500 (Sold in 12” Increments) Splice Connector LUM-B34XTS-IC Strip to DMX Connector Cable LUM-B34XTS-CX-4FT Waterproof Inline Connector LUM-B34XTS-IJC (3 Wire/RGB) 8ft Y-Connector Cable LUM-B34XTS-YCO Waterproof Inline Connector LUM-B34XTS-IJ4 (4 Wire/RGB) (305)-233-2844 ©Lumilum LED Lighting Page 2 of 5 www.lumilum.com...
- Page 3 LUM-B34XTS-XX (1ft or 4ft) DMX2 Decoder/Controller (IP65 Rated/Outdoor) LUM-B34XTS-DMX2 0.5” Aluminum U-Channel (Set of 6) LUM-B34XTS-U0 PVC U-CHANNEL 4ft. PVC U-Channel LUM-B34XTS-PVCU4 DMX Color Wheel Wall Panel (Not Recommended for Outdoor) LUM-RGBUX8 (305)-233-2844 ©Lumilum LED Lighting Page 3 of 5 www.lumilum.com...
- Page 4 U-Channel Aluminum LUM-P3535C-XX Surface Mount (4ft or 8ft) Mega Channel INSTALLATION DIAGRAM : DMX DECODER/CONTROLLER Please reference our DMX cutsheets for further instructions. Using Lumilum®Mounting Bracket (LUM-B34XTS-CL) Mounting Bracket DMX-Decoder Controller • LUM-B34XTS-DMX2 Fuse 12A Power In Vent Valve 110-125V...
- Page 5 Output: 3 Pin DMX Output: 5 Pin DMX Input: 5 Pin DMX B34XTS RBG Interconnector Cable (4 Pin Female Hub to 4 Pin Male Hub) • LUM-B34XTS-CC-XX (Available in 6in., 12in., 20in., and 40in.) (305)-233-2844 ©Lumilum LED Lighting Page 5 of 5 www.lumilum.com...
