INDEX:
1 - General ..................................................................................................................................................................................................................... 23
1.1 - Introduction ......................................................................................................................................................................................................... 23
1.2 - General warning .................................................................................................................................................................................................. 23
1.3 - Symbols in the manual ........................................................................................................................................................................................ 24
1.4 - Important tips ...................................................................................................................................................................................................... 25
1.5 - Cautions.............................................................................................................................................................................................................. 25
1.6 - Noise................................................................................................................................................................................................................... 25
1.7 - Cautions levels.................................................................................................................................................................................................... 25
1.8 - Temporary Storage ............................................................................................................................................................................................. 25
1.9 - Transporting ........................................................................................................................................................................................................ 26
1.10 - Overall size ....................................................................................................................................................................................................... 26
1.11 - Disposal ............................................................................................................................................................................................................ 26
1.12 - Assistance center .............................................................................................................................................................................................. 26
1.13 - Repairs and spare parts .................................................................................................................................................................................... 26
1.15 - Ordering spare parts.......................................................................................................................................................................................... 26
2- AT206 panel description .......................................................................................................................................................................................... 27
2.1 - How is the package and what is included ........................................................................................................................................................... 27
2.2 - Product external and internal view with description.............................................................................................................................................. 28
2.3 - Panel wall mounting instructions.......................................................................................................................................................................... 29
3 - First starting of the product, use and description................................................................................................................................................. 30
3.1 - Operation to do during the first starting of the AT206 panel ................................................................................................................................. 30
3.2 - AT206 panel; LED indication decription ............................................................................................................................................................... 31
3.3 - AT206 panel; command buttons decription.......................................................................................................................................................... 31
3.4 - AT206 panel; function description........................................................................................................................................................................ 32
4 - AT206 connection and electrical drawings ............................................................................................................................................................ 33
4.1 - Power connection................................................................................................................................................................................................ 33
4.2 - Panel electrical drawing....................................................................................................................................................................................... 36
4.3 - Diesel engine auxiliary connection....................................................................................................................................................................... 37
4.4 - Gasoline engine auxiliary connection .................................................................................................................................................................. 38
5 - AT206 panel programmation instruction................................................................................................................................................................ 39
5.1 - Programmation menu access description ............................................................................................................................................................ 39
5.2 - Parameters modification instructions ................................................................................................................................................................... 39
5.3 - User menu parameters........................................................................................................................................................................................ 39
5.4 - Advanced menu parameters................................................................................................................................................................................ 39
6 - General sales conditions and warranty................................................................................................................ Errore. Il segnalibro non è definito.
Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc
Pagina 22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT206 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pramac AT206

  • Page 1: Table Of Contents

    2.3 - Panel wall mounting instructions..................................29 3 - First starting of the product, use and description..............................30 3.1 - Operation to do during the first starting of the AT206 panel ..........................30 3.2 - AT206 panel; LED indication decription ................................31 3.3 - AT206 panel;...
  • Page 2: General

    Verify if the registration number reproduced on the technical card of the acquired model agrees with that one cut with the label of the “Marking CE” The Firm “PRAMAC s.r.l.” will not think he is responsible for difficulties, breaks, accidents etc. due to the no knowledge or at any rate to the no application of the rules held in this manual.
  • Page 3: Symbols In The Manual

    - Never for any reason modify any part of the electric panel (connections, holes, electrical or mechanical devices, etc.) unless duly authorized to do so in writing by “PRAMAC”: the responsibility deriving from any such action shall fall on the person doing it since he then in fact becomes its manufacturer.
  • Page 4: Important Tips

    25° C and +55° C with short times not exceeding 24 h ours, up to +70° C. - Stack the electric panels without stacking too many one on top of another. Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 25...
  • Page 5: Transporting

    In the event of damage due to transportation or delivery of the wrong model, call the firm that carried out the service and “PRAMAC”. Before removing the packing from the electric panel, carefully read the user warnings given in this handbook.
  • Page 6: 2- At206 Panel Description

    Indicate the serial number required to identify the product. This number must always be quoted in requests for spare parts. HP = Horsepower Model = Indicates the code of the control panel that enables the type to be identified. Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 27...
  • Page 7: Product External And Internal View With Description

    The panel in the picures is only an example and it’s one of the model in production; for this reason, the current transformers, the power circuit and the contactors in the panel must be different from the components in the image. Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 28...
  • Page 8: Panel Wall Mounting Instructions

    The panel must be fixed on the wall by two fixing hook in equipment For air flow reasons, it is necessary that around the panel there is a free space of about 10cm for all the perimeter Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 29...
  • Page 9: First Starting Of The Product, Use And Description

    3 - FIRST STARTING OF THE PRODUCT, USE AND DESCRIPTION 3.1 - Operation to do during the first starting of the AT206 panel When you supply for the first time the panel, the board is setted in RESET mode. The non observance of the indications given about the first starting of the product, can cause faulty situations on the same product Before the first starting of the panel, check that the indications on the “Identification data plate”...
  • Page 10: At206 Panel; Led Indication Decription

    3.2 - AT206 panel; LED indication decription Type of If flashing, it indicate that the 4 digit multifunction measurement engine is running and the If on, it display to show showed by the alarms are not enable. If on, indicates that...
  • Page 11: At206 Panel; Function Description

    Test start time 00:00 – 23:59 10:00 U.04 Test with load 0=load 1=a vuoto U.05 Clock 0=no 1=yes U.06 weekly / days 0=week 1=days U.07 day of the week 1=Mon 2=Tuesd 3=Wed. etc. Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 32...
  • Page 12: At206 Connection And Electrical Drawings

    If you enable the automatic test (TEST button for 5 seconds) on Monday afternoon at 15.00, first test will start 3 days after (on Thursday) from 10.00 to 10.15. Second test will start on next Sunday (3 more days later) always from 10.00 to 10.15 4 - AT206 CONNECTION AND ELECTRICAL DRAWINGS 4.1 - Power connection 4.1.1 - Triphase connection...
  • Page 13 WARNING !! If the installation of the product is not in accordance to the specifics descripted above, can cause problems in terms of functionality and can also compromises warranty conditions. Then PRAMAC srl won’t be responsible for any direct or not direct damage due to wrong installation.
  • Page 14 WARNING !! If the installation of the product is not in accordance to the specifics descripted above, can cause problems in terms of functionality and can also compromises warranty conditions. Then PRAMAC srl won’t be responsible for any direct or not direct damage due to wrong installation.
  • Page 15: Panel Electrical Drawing

    4.2 - Panel electrical drawing Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 36...
  • Page 16: Diesel Engine Auxiliary Connection

    4.3 - Diesel engine auxiliary connection Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 37...
  • Page 17: Gasoline Engine Auxiliary Connection

    4.4 - Gasoline engine auxiliary connection Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 38...
  • Page 18: At206 Panel Programmation Instruction

    0=220M 1=220T 2=380T Group 2 Engine start-up P2.01 500 rpm signal from alternator or gen. (started engine) 1=altmm 0=gen 2=altes Started engine alternator voltage threshold 3-30V Started engine generator voltage threshold 20-500V Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 39...
  • Page 19 Programmable outputs P6.01 Progr. Relay (terminal 63) glow plugs 1 alarm P6.02 Progr. relay (terminal 53 - 54) alarm alarm decelerator electromagnet 2 P6.03 Progr. relay (terminal 62) siren siren alarm Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 40...
  • Page 20 Alarm relay (if enabled) yes/no A5.05 Not active yes/no yes/no Minimum frequency A6.01 Stop without cooling yes/no A6.02 Stop with cooling yes/no A6.03 Siren relay yes/no A6.04 Alarm relay (if enabled) yes/no Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 41...
  • Page 21 E1.05 Not active yes/no Emergency stop yes/no E2.01 Stop without cooling yes/no E2.02 Siren relay yes/no E2.03 Alarm relay (if enabled) yes/no E2.04 Not active yes/no E2.05 Not active yes/no Cod.Doc.AT206 PRAMAC - installator guide - IT,EN.doc Pagina 42...
