Functions compatible with the 2010 Nissan Cube (Smart Key)
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Fuel level/EV battery level
Ignition Activation
Ignition Status
Immobilizer Bypass-Data No Key Req'd
Key2GO
Parking Lights Control
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Trunk / Hatch Release
933.NISS4HT
v2.36.198.12
2010 Nissan Cube (Smart Key)
THNIN3 Compatible
(Sold Separately)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Voxx Accessories DIRECTWIRE DIRECTECHS DS3
- Page 1 933.NISS4HT v2.36.198.12 2010 Nissan Cube (Smart Key) THNIN3 Compatible (Sold Separately) Functions compatible with the 2010 Nissan Cube (Smart Key) 3x LOCK START (Start control using OEM Remote) Entry Monitoring Trunk/Hatch Pin 3x LOCK STOP (Stop control using OEM Remote) Fuel level/EV battery level Accessory Activation Ignition Activation...
-
Page 2: Table Of Contents
Contents Introduction Pre-installation and application warnings Installation Wiring diagram with T-Harness (THNIN3) Wiring diagram Locating components in the vehicle Vehicle connections Module programming For Security-Only and Convenience-Only programming, see next sections. Module programming for convenience only (skip transponder) Module programming for security-only installations Pairing remotes Connecting the module 8556T Temperature Sensor... -
Page 3: Introduction
Introduction This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a digital configuration requires the module to be flashed with vehicle-specific firmware. Refer to our website (www.directechs.com) and click on the DIRECTLINK text in the header for additional information. -
Page 4: Pre-Installation And Application Warnings
Pre-installation and application warnings This section highlights important information for this specific firmware and will assist in pricing accordingly, as START HERE well as bringing awareness to any operational or vehicle limitations. Compatibilities and Requirements T-Harness Keys required for Keys required THNIN3 programming for operation... -
Page 5: Wiring Diagram With T-Harness (Thnin3)
Wiring diagram with T-Harness (THNIN3) Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( T-02 T-02 USED Clock & Data Wire at NATS Connector T-01 T-01 (behind Push-to-Start button) PTS Switch (brown 8-pin conn.) module can also be used for... -
Page 6: Wiring Diagram
Wiring diagram Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( NATS Antenna Conn. (behind Push-to-Start button) HS CAN High: Blue, pin 6 Diagnostic Connector OBDII (connector side view) Data: Lt. -
Page 7: Locating Components In The Vehicle
Locating components in the vehicle Optional starter disable connection When using an external relay, use a 1N4002 diode or larger. 1A diode [1N4002+ ] (+) Ignition (-) Ground When Armed (GWA) Output: Blue/White: 2 Refer to the Vehicle connections section for wire and Starter (conn. -
Page 8: Vehicle Connections
Vehicle connections The connection information listed below is specific to the 2010 Nissan Cube (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes. Data harness, 8-pin white connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color... - Page 9 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H2/13 Violet No Connection No Connection H2/14 Brown No Connection No Connection H2/15 White/Blue No Connection No Connection H2/16 Red/Blue No Connection No Connection H2/17 Black/White No Connection No Connection H2/18 Orange/Black...
- Page 10 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H4/5 No Connection No Connection H4/6 Green No Connection No Connection H4/7 Violet No Connection No Connection H4/8 Orange No Connection No Connection H4/9 Red/White No Connection No Connection H4/10 Pink No Connection...
-
Page 11: Module Programming
Module programming Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes. Security-Only Convenience-Only programming, see next sections. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift lever is in the neutral position. - Page 12 When the configuration is completed, reconnect the module. The LED turns ON solid green for 3 seconds, then turns OFF. Pair remotes (if applicable). For information on how to pair a specific remote, please refer to its corresponding owner documentation, which can be found inside the product packaging of the complete system or on www.directechs.com.* DATA/Hardwired Tach Learning: When using Data Tach, it is recommended to follow the Tach Learning procedure.
-
Page 13: Module Programming For Convenience Only (Skip Transponder)
Module programming for convenience features only (skip transponder) Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift is in the neutral position. Connect the 12-pin main power harness to the module. -
Page 14: Module Programming For Security-Only Installations
Module programming for security-only installations Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift is in the neutral position. Connect the 12-pin main power harness to the module. -
Page 15: Pairing Remotes
Pairing Remotes and Sensors To enter pairing: Key OUT Key IN Key IN Key IN Turn the vehicle ignition to the ON position. START START START START Within 10 seconds, on the Control Center (antenna) or the LED/Valet Pod (standalone switch), press and release once (1x), and then press and hold &... -
Page 16: When Used In Conjunction With Smartstart
before providing power to the Directed SmartStart unit: ® SmartStart with Loops – The brown loop must be cut. SmartStart with Pigtails – The gray wire must be connected to a ground source. Loops Pigtails DO NOT connect the Directed SmartStart 2-pin power harness when using the DS3+/DS4+. -
Page 17: Manual Transmission
Manual Transmission IMPORTANT! Directed does not approve nor support installations of manual transmission and remote starts on any electronic vehicles (EV), OEM Remote Start Activation firmware, vehicles with convertibles and/or removable tops, including but not limited to Jeep Wrangler, Honda S2000, Mazda Miata, and other such vehicles. This system supports manual transmission installations. -
Page 18: Led Diagnostics And Troubleshooting
LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power. - Page 19 External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence.
-
Page 20: Soft Reset
Soft reset A module reset will only erase the steps perfomed in “Module Programming”. The firmware and settings flashed to the module will not be affected. Connect all but the If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin main 12-pin harness power harness. -
Page 21: Tach Learning Procedure (Not Needed With Virtual Tach)
Tach learning procedure (not needed with Virtual Tach) Data Tach: The procedure is not required as the tach comes preprogrammed. However, it is strongly recommended to learn the exact value of the vehicle for the most consistent and reliable starting and functionality. Hardwired Tach: The procedure is required. -
Page 22: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or work- manship within the Lifetime from the date of original purchase in the original vehicle, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor. -
Page 23: Quick Reference Guide (Customer Copy)
Quick Reference Guide (customer copy) Sending commands to your vehicle Pit stop/idle mode Whether you want to remote start the engine, lock/unlock the doors or pop the trunk, there Stop the vehicle in a safe parking spot and put the gear gear in Park are 3 possible ways you can send commands to your vehicle, using the: in Park (P). - Page 24 SmartStart Bluetooth compatiblity (applicable to DS4/DS4+ ONLY) This system is equipped with a Bluetooth version of SmartStart offering up to 200' of range. The simple graphical interface gives you control over the following features of your installed remote start system or security with remote start system: Lock/Arm •...
