- Page 1 FortiTester 100F FTS-100F QuickStart Guide...
-
Page 2: Register For Support
Copyright© 2020 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All Toll free: 1 866 648 4638 other product or company names may be trademarks of their respective owners. -
Page 3: Box Includes
Box Includes QuickStart Guide FortiTester 100F 1x AC Power Cable 1x Console Cable 1x Ethernet Cable (USB to RJ45) 2x M3 Handle Screws 1x Set of Handles 1x Set of Sliding Rails 4x Rubber Feet... -
Page 4: Desktop Installation
Desktop Installation Rail Installation Please read “Cautions and Warnings” prior to installing your device. To install the FortiTester unit using the rail mount kit: The appliance can be placed on any flat surface, or mounted in a standard 19 inch rack. To install the appliance on a flat surface 1. -
Page 5: Sfp Ports
SFP Ports Release safety lock To install the SFP transceivers before mounting Slide the SFP into the cage socket until it clicks into place Lift latch to lock the SFP Cage Socket Push the safety lock forward to secure 1. To mount the chassis into the cabinet, first ensure that the ball retainer is in the fully open position. - Page 6 Device Guide Power Switch To turn the power ON/OFF. Grounding Screws Power Connection Provides extra grounding 100-240V AC, 50-60Hz, 6A-3A. MGMT Dedicated Gigabit Ethernet Management Port for system management. USB Ports Reserved for future use Console Ports 1-2 Optional connection to the RJ45 type 1 Gigabit Ethernet ports management computer.
- Page 7 Device Guide LED for Ports 5-6 Upper - LNK/ACT Green: Link established Flashing Green: Data activity Off: No link established LED for MGMT, Ports 1-2 Bottom - Speed Left - LNK/ACT Right - Speed Green: Link established at 10Gbps Green: Link established Green: Link established at 1Gps...
-
Page 8: Basic Connections
Basic Connections Web Browser with Ethernet cable Power Connection Plug the provided power cable into the rear of the appliance, and then into a grounded electrical outlet or a separate power source such as an uninterruptible power supply MGMT Port (UPS) or a power distribution unit (PDU). - Page 9 Terminal Emulation Speed (default): 9600 Data bits: Stop bits: Console Cable Parity: None Flow Control: None Console Port To connect to the CLI Requires: Terminal emulator such as PuTTY, Tera Term, or a terminal server. 1. Connect the appliance console port to the management computer using the provided console cable.
- Page 10 The presence conditions of the restricted substance (BSMI RoHS table) are available at the link below: 限用物質含有情況表 (RoHS Table) 請到以下 網址下載： https://www.fortinet.com/bsmi Battery – Risk of explosion if the battery is replaced by an incorrect type. Do not dispose of batteries in a fire. They may explode. Dispose of used batteries according to your local regulations.
- Page 11 Fortinet.com...
