SABER II 15W CORDED UNDERHOOD LIGHT
FEATURES:
•
30 Super Bright SMD LEDs
•
18/2 SJTOW 25ft cord remains flexible in cold weather and water resistant
•
ABS handle with double injection, impact protection and ergonomic design provides comfortable usage
•
Aluminum alloy hook with PVC cover for protection, soft coated padded hooks help prevent scratching
of the vehicles surface
•
The bar extends from 47" to 70" and easily attaches to most SUV's and trucks
•
360 degree ratcheting hooks provide safe and firm attachment.
•
CSA listed
California Prop 65 WARNING:
This product contains chemicals including lead, known to the State of California to cause cancer, birth defects, or other
reproductive harm. Wash hands after handling.
ATD‐80351
USER'S MANUAL
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ATD Tools ATD-80351
Summary of Contents for ATD Tools ATD-80351
- Page 1 ATD‐80351 SABER II 15W CORDED UNDERHOOD LIGHT USER’S MANUAL FEATURES: • 30 Super Bright SMD LEDs • 18/2 SJTOW 25ft cord remains flexible in cold weather and water resistant • ABS handle with double injection, impact protection and ergonomic design provides comfortable usage • Aluminum alloy hook with PVC cover for protection, soft coated padded hooks help prevent scratching of the vehicles surface • The bar extends from 47" to 70" and easily attaches to most SUV's and trucks • 360 degree ratcheting hooks provide safe and firm attachment. • CSA listed California Prop 65 WARNING: This product contains chemicals including lead, known to the State of California to cause cancer, birth defects, or other reproductive harm. Wash hands after handling.
-
Page 2: General Safety Warnings
General Safety Warnings: WARNING: The instructions and warnings contained in this manual should be read and understood before using or operating this tool. Do not allow anyone to use or operate this tool until they have read this manual and have developed a thorough understanding of how this tool works. Failure to observe any of the following instructions could result in severe personal injury to tool user and bystanders, or cause damage to the tool and property. Keep this manual for future reference. Note: The warnings and cautions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. WARNING: Use safety equipment. Users and bystanders should use safety goggles or safety glasses with side shields which comply with current national standards, or when needed, a face shield. Use an ANSI approved dust mask or respirator when working around metal, wood, and chemical dusts and mists. This applies to all persons in the work area. Also use non‐skid safety shoes, hardhat, gloves, dust collection systems, and hearing protection when appropriate. WARNING: Keep bystanders and children out of the work area while operating this tool. WARNING: Always keep your work area clean, uncluttered, and well lit. Cluttered or dark areas invite accidents and injuries. DO NOT work on floor surfaces that are slippery. WARNING: Do not operate this tool if you are tired or under the influence of alcohol, drugs, or medications that could affect your ability to use the tool properly. WARNING: Dress properly. Do not wear loose clothing or jewelery as they can be caught in moving parts. Wear restrictive hair covering to contain long hair. WARNING: Do not reach over or across running machines. Keep proper footing and balance at all times. Non‐ skid footwear is recommended when working. ... - Page 3 WARNING: Grounded tools must be plugged into an outlet properly installed and grounded in accordance with all codes and ordinances. This tool is equipped with a 3‐prong plug and a 3‐wire grounding system. Never remove the grounding prong or modify the plug in any way. Do not use any adapter plugs. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. NOTE : Double insulated tools are equipped with a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still doesn’t fit, contact a qualified electrician to install a polarized outlet. Do not change the plug in any way. WARNING: To reduce the risk of electric shock, DO NOT use in damp conditions, on wet surfaces, or expose to rain. Do not plug in this tool or operate it with wet hands or while standing in water. WARNING: Never use the cord for carrying, pulling or unplugging the power tool. Grasp plug and pull to disconnect from outlet. Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged cords immediately. WARNING: Do not carry the power tool with your finger on the switch. Ensure the switch is in the off position before plugging the tool into the power outlet. In the event of a power failure while a tool is being used, turn the switch off to prevent surprise starting when the power is restored. WARNING: Always remove the power cord from the electric outlet when making adjustments, changing parts, cleaning or working on the tool. WARNING: Care should be taken to arrange the cord so it will not be stepped on, tripped over, or otherwise subjected to damage or stress. WARNING: Never attempt to plug in or operate equipment with defective or damaged wires, power cord or power cord plug. Have any defective or damaged parts replaced immediately by qualified personnel. WARNING: Avoid body contact with electrically grounded surfaces. There is an increased risk of electric shock if your body is grounded. ...
- Page 4 NOTE : The table below shows the correct size to use according to cord length and the amperage draw of the tool (specified on the nameplate). When in doubt, use the next heavier gauge. The smaller the gauge number, the heavier the cord. (AWG = American Wire Gauge). Minimum Gauge for Extension Cords (AWG) (when using 120 volts only) Ampere Rating Total Length of Cord in Feet (meters) More Than Not More Than 25' (7.6m) 50' (15m) 100' (30.4m) 150' (45.7m) 0 6 18 16 16 14 6 10 18 16 14 12 10 12 16 16 14 12 12 16 14 12 Not Recommended ...
- Page 5 Operating Instructions: • To use, plug the unit into any 110-120 VAC power source, such as a wall receptacle. • Press the on/off switch (l) to turn unit on, press the other side of switch (0) to turn it off. •...
- Page 6 CLEAR TUBE LOWER PRT80351-18 DRIVER PRT80351-08 SCREW 2.9X16 PRT80351-19 ALUMINUM TUBE,UPPER PRT80351-09 BRIGHTNESS INDICATE COVER PRT80351-20 ELASTIC BAND PRT80351-10 RIGHT HANDLE SET PRT80351-21 BLOCK PRT80351-11 ON/OFF SWITCH Visit us at www.atdtools.com Copyright (C) 2013 ATD Tools, Inc. All rights reserved.
