Summary of Contents for Reddot M2
- Page 1 2021 User Manual ECG-Enhanced Smart Pillbox M2 Thank you for purchasing our company's products. For your safety, please read this user manual carefully before using the product.
-
Page 2: Table Of Contents
CATALOGUE 1.Production Information..........2.Instruction for use............3.Application scope & Contraindications......4.Precautions..............5.Product Features............6.Product performance indicators........7.Working and storage conditions........8.Cleaning and disinfection..........9.Electromagnetic Compatibility Information.... -
Page 3: Production Information
1. Production Information ECG-Enhanced Smart Pillbox Model No Weight 105g (Battery included, battery weight about 10g) Bluetooth Version Bluetooth 5.0BLE Input Voltage DC 3.7V Rated Power 0.75VA Battery Capacity 570mAh Lithium Battery 2. Instruction for use Product structure and appearance: Finger Induction Area. Charging Port The device lights up in orange and starts charging, the device does not working while charging. -
Page 4: Application Scope & Contraindications
3. Application scope and contraindications 1. Application: used for single-lead acquisition, display, and recording of human ECG data. Automatic analysis and diagnosis functions are not included. 2. Contraindications: 1) Those who are allergic to ECG electrodes are prohibited; 2) Those who have a pacemaker are prohibited; 3) People who have allergic reactions to this product are prohibited;... -
Page 5: Precautions
4. Precautions 1) Please read this manual carefully before use. 2) When the product is not going to be used for a long time, please charge and discharge the product once every 3 months. 3) The built-in battery should be discarded according to the regulations of relevant departments. - Page 6 10) For the disposal of the ECG-Enhanced Smart Pillbox and its accessories and packaging (plastic bags, foam and paper boxes, etc.), please comply with local laws and regulations to avoid environmental pollution. 11) In the environment of strong magnetic field such as nuclear magnetic resonance (MRI) and CT examination, it is strictly forbidden to wear and use the ECG-Enhanced Smart Pillbox at the same time.
-
Page 7: Product Features
5. Product features 1) Classification by type of protection against electric shock: internal power supply; 2) Classified according to the degree of protection against electric shock: CF type; 3) Classified according to the degree of protection against ingress of liquid: IPXO 4) Classified according to the degree of safety when used with flammable anesthetic gas mixed with air or flammable anesthetic gas mixed with oxygen or nitrous oxide: Equipment that cannot... -
Page 8: Product Performance Indicators
6. Product performance indicators 1) Dynamic input range: For a differential mode voltage with an amplitude of 10mV (peak-to-valley) (when the gain is set to 5mm/mV) that is superimposed with a 300mV DC bias voltage and changes at a rate of 125mV/s, the digital recorder should have the ability to respond and display. -
Page 9: Working And Storage Conditions
7. Working and storage conditions 1. Working conditions Temperature: 5C~40°C: Humidity: ≤80% (non-condensing); Altitude: 700hPa~1060hPa 2. Storage conditions: Storage and transportation temperature: -20C~55C. Storage and transportation humidity: <93% (no condensation); transportation stability requirements: transportation under normal temperature conditions; air pressure range: 700hPa~1060hPa; Note: No corrosive gas, strong mechanical vibration and strong electromagnetic field, clean and well-ventilated room. - Page 10 The name and content of harmful substances in the product Harmful Substance Part Hexavalent Polymeric Diphenyl Lead Mercury Pot Cd Name chromium Biphenyl ether Cr(VI) (PBB) (PBDE) Case Storage box Circuit board Fastener Battery This form is prepared according to the provisions of SJ/T11364. O: Indicates that the content of the hazardous substance in all homogeneous materials of the part is below the limit requirement specified in GBT26572...
-
Page 11: Electromagnetic Compatibility Information
4. Warning: In addition to the accessories provided by our company, the use of other manufacturers' accessories may lead to an increase in the emission of the M2 ECG-Enhanced Smart Pillbox or a decrease in the immunity to interference. 5. See Table 1. - Page 12 Guidance and Manufacturer's Declaration - Electromagnetic Emissions (Table1) The M2 ECG-Enhanced Smart Pillbox is intended for use in the electromagnetic environment specified below, and the purchaser or user should ensure that it is used in such an electromagnetic environment: Electromagnetic Environment...
- Page 13 Guidance and manufacturer's declaration — Electromag- netic immunity The M2 ECG-Enhanced Smart Pillbox is intended to be used in the electric shock environment specified below, and the purchaser or user should ensure that it is used in this electromagnetic environment.
- Page 14 Guidance and manufacturer's declaration — Electromag- netic immunity The M2 ECG-Enhanced Smart Pillbox is intended for use in the electromagnetic environment specified below, and the purchaser or user should warrant that it is used in such an electromagnetic environment. (Table 3)
- Page 15 Recommended Isolation Distance Between Portable and Mobile RF Communication Devices and M2 ECG-Enhanced Smart Pillboxes The M2 ECG-Enhanced Smart Pillbox is intended for use in electromagnetic environments where RF emissions are controlled. Depending on the maximum output power of the communication device, the purchaser or user can prevent...
