  • Page 1 All manuals and user guides at all-guides.com M a nu a l PLANAR 60B PDP...
  • Page 2 All manuals and user guides at all-guides.com ・Safety Precautions Power Supply - W a r n i n g AC plug should not be touched Do not use multiple devices in an Do not use damaged electrical with wet hands. It may cause outlet at the same time to avoid the cord/plug, or loose outlet.
  • Page 3 All manuals and user guides at all-guides.com Precautions are divided into two: "Warning" and "Caution". W a r n i n g : Serious injury or fatal injury may occur, if the indicated warning is not followed. C a u t i o n : Minor injury or product damage may occur, if the indicated caution is not followed.
  • Page 4 All manuals and user guides at all-guides.com ・Usage and Maintenance W a r n i n g During a thunder storm, Do not insert any metal Do not all ow ch il - Never attempt to disas- please unplug the elec - objects such as chop- dren to climb or play semble, repair or modify...
  • Page 5 All manuals and user guides at all-guides.com Notes Fixed (immovable) screen can cause permanent damage to PDP monitor 1. Video games, price tags, graphics and others can damage the screen. 2. When using simultaneous screen function, if the simultaneous screen stays on the corner of screen for a long time 3.

  • Page 6: Table Of Contents

    All manuals and user guides at all-guides.com ・Contents User Guidance Information …… ………………………………………………… … 2 3 • Safety Precaution …………………… ……………… ……………… 4 5 • Usage & Maintenance ……… ……………… ………………………………… ………… 6 7 • Contents • Part Names - Front View…………………………………………… ………………………8 - Rear View ……………………………………………………………………9 ……………...
  • Page 7 All manuals and user guides at all-guides.com ………………… …………………………………… 26 • Stopping the screen ……………………………………………… 26 • Checking the current state Application ……………………………… ……………………… 27 • Checking the menu ………………… ……………………… 28 29 • Adjusting the video screen ………………………………… … 30 •...

  • Page 8: Part Names

    All manuals and user guides at all-guides.com ・Part Names Front View Main Power Supply (A/C Input) Button - Please turn off the main power switch if the monitor is not in use for a long period. Remote Control Sensor Power/ Standby Indicator Waiting State: Red Operating State: Green Input Select ion B utton...

  • Page 9: Rear View

    All manuals and user guides at all-guides.com Rear View A/C Input Terminal AudioVideo Input Terminal RS-232 Terminal S-Video Terminal (External Connection Component (DVD/DTV) Input Terminal External Speaker Connection A d j u s t m e n t ) (480i/480p/720p/1080i) Terminal (8Ω) RGB PC Input Terminal Audio Input Terminal...

  • Page 10: Options

    All manuals and user guides at all-guides.com ・Options Options ※ Various options are subject to change for quality improvement of the products, without notice. ※ Please contact your dealer or the reference for purchase options. desktop stand Wall-mount c e i l i n g - m o u n t b r a c k e t b r a c k e t A udio cable...

  • Page 11: Accessories

    All manuals and user guides at all-guides.com Accessories ※ The configuration of the component s may look different f rom t he drawing contained here. Batter y (1.5V AAA type) 2 RG B Cable User 's Manual Power Cords Remote Control DVI Adapter...
  • Page 12 All manuals and user guides at all-guides.com ・Installing PDP Monitor Installing wall - mount bracket ▶ Installing Wall mount PDP monitor can be installed on the wall as the picture shown above. Notes Please secure enough space for safe use. (Please refer to A and B.) If you install the monitor in any ill-ventilated locations, it can cause a fire or damage to the product due to the internal temperature of the product.
  • Page 13 All manuals and user guides at all-guides.com Installing desktop stand This is not floor-standing unit. ※ ▶ PDP monitor can be installationed on the desk as the picture shown above. Notes Do not install in an unstable location or on a smaller support than the main body. ※...
  • Page 14 All manuals and user guides at all-guides.com ・Remote Control Unit ※ When using the remote control, point it towards the front of the PDP monitor.

  • Page 15: Remote Control

    All manuals and user guides at all-guides.com If remote control does not function 1. Check the polarity (+,-) of the batteries. 2. Check if the batteries have power. 3. Check if there is a power failure. 4. Check if the power cord is unplugged. 5.
  • Page 16 All manuals and user guides at all-guides.com ・Connecting VCR Connecting VCR Connecting to Composite Video terminal Connect Video/Audio connection line to Composite [(yellow is for Video, white is for Audio (left), red is for Audio (right))] of PDP and Video/Audio output terminal of the video.

  • Page 17: Connecting Cable Broadcasting Receiver

    All manuals and user guides at all-guides.com Connecting cable broadcasting receiver <Back panel ofthe Mon itor> In order to watch cable TV, subscribe to local cable TV broadcasting company and install separate converter for cable TV. Connecting to external input terminal Connect image/voice connection line to PDP external input terminal [(yellow is for image, white is for voice (left), red is for voice (right)) and image/voice Audio...

  • Page 18: Connecting Dvd

    All manuals and user guides at all-guides.com ・Connecting camcorder/ Video game ・Connecting DVD Connecting camcorder/ game machine <B ack panel of t he Monitor> Use after connecting the Video game in the same way as a camcorder. Connecting composite video Connect Video/Audio connection line to Composite [(yellow is for Videowhite is for Audio (left, red is for Audio (right)] and Video/Audio output terminal of camcorder.
  • Page 19 All manuals and user guides at all-guides.com Connecting DVD <Back panel of the Monitor> Connecting to component terminal Connect Video connection line to PDP component terminal (Y, PB, PR) and component video output terminal of DVD. Connect audio connection line to PDP component Audio input terminal and Audio output terminal of DVD.

  • Page 20: Connecting Dtv Receiver

    All manuals and user guides at all-guides.com ・Connecting DTV receiver Connecting to component terminal/ Connecting to RGB terminal <B ack panel ofthe Monit or> V i d e o A u d i o COMPONENT COMPONENT RGB <digital broadcasting> You should connect and use separate SET TOP BOX to receive digital broadcasting. In 1080i mode among DTV modes, the screen size does not act, but fixed to 16:9 that the screen size does not change.
  • Page 21 All manuals and user guides at all-guides.com Watching DTV 1.Turn on the PDP monitor and press input select button of remote control. 2.Use button to select Component and then press button. (Audio should be connected to component voice terminal.) 3.When connecting RGB terminal, use button to select Analog RGB and then press button.

  • Page 22: Connecting To

    All manuals and user guides at all-guides.com ・Connecting to PC Connecting to DVI-I terminal Connecting to Analog RGB terminal Insert DVI adapter into PC signal line and then connect PDP DVI-I input terminal and RGB output terminal of PC. Connect Audio connection line to PDP DVI Audio input terminal and Audio output terminal of PC. (PC Audio connection line is not included and should be purchased separately.) ※...
  • Page 23 All manuals and user guides at all-guides.com Using PC 1. Turn on the PDP monitor and press input selection button of remote control. 2. Use button to select Analog RGB and then press button. (If PC output is set to Digital, select Digital RGB.) 3.

  • Page 24: Selecting An Input Signal

    All manuals and user guides at all-guides.com ・Turning on PDP monitor ・Selecting input signal Before turning on the PDP monitor Insert the power plug. Connect external equipment properly. Please use only after carefully reading this manual. Turning on the PDP monitor First check the power connection and check the connection of external equipment.
  • Page 25 All manuals and user guides at all-guides.com Selecting External Input. Select the required input using button in the next menu by pressing input selection button and then select with (Enter) button. If you know the input connected on the back of the monitor, you can instantly make the input selec- tion by pressing VIDEO button, S-VIDEO button, COMPONENT button, RGB/A button, and RGB/D button on the remote control.
  • Page 26 All manuals and user guides at all-guides.com ・Volume - Controlling Volume・Mute - Pausing sound ・Still - Pausing the screen・Info - Checking current state ・Menu - checking the menu Volume - Controlling Volume Press button to increase volume, Press button to decrease volume. Mute - Pausing sound Press button.
  • Page 27 All manuals and user guides at all-guides.com Menu - Checking the menu If input selections are "Composite", "S-Video", and "Component", the video menu is activated. If input selections are "Analog RGB" and, "Digital RGB", the computer menu activates. You should use the remote control for detailed menu item setting and change of PDP monitor. Press button.
  • Page 28 All manuals and user guides at all-guides.com ・PSM ・User setting Adjusting video screen How to change the screen mood. Press "PSM" button. Press PSM" button repeatedly to select the desired screen. Standard Dynamic Mild Game Movie User Press button. ① Press button to move to the item ②...
  • Page 29 All manuals and user guides at all-guides.com User setting - manually setting the screen mode You may change the user setting from any mode. Press the button ① Press button move to the item ② Press button to enter the sub-menu. ③...
  • Page 30 All manuals and user guides at all-guides.com ・ARC ・PIP ARC (Aspect Ratio Control) Press button. button, you can select 16:9 → Zoom1 → Zoom2 → Whenever you press panorama → 4:3. 16:9 Zoom 1 Zoom 2 4 : 3 Panorama 16:9 Zoom 1 Zoom 2...
  • Page 31 All manuals and user guides at all-guides.com PIP (Picture In Picture) Press the button. button, you can select PIP [Large] → PIP [Small] → PBP → Normal. When you press the Press PBP button, then you can see twin picture immediately. PIP [Large] Normal PIP [Small]...
  • Page 32 All manuals and user guides at all-guides.com ・PC Mode Adjusting PC It is screen adjustment when input signal is Analog RGB. Auto adjustment Use this when input signal is Analog RGB and if the screen's image location is incorrect, or if shaking occurs. ①...
  • Page 33 All manuals and user guides at all-guides.com User Adjustment Use this if minute adjustment is required after automatic adjustment. Press button. ① Press to move to the item . ② Press button to enter the sub menu. ③ Select "Brightness" with ④...
  • Page 34 All manuals and user guides at all-guides.com ・Color Tone Color Tone Press button. ① Press button to move to the item ② Press button to enter the sub menu. ③ Select "Color Temp" with ④ Select the required color among "Cool", "Normal ", "Warm ", and "User" Press button after adjustment to return to the previous menu.
  • Page 35 All manuals and user guides at all-guides.com Color Tone (User setting) Press button. ① Press button to move to the item ② Press button to enter the sub menu. ③ Select "Color Temp" with ④ Select "User" with ⑤ Press button.
  • Page 36 All manuals and user guides at all-guides.com ・SSM ・Equalizer SSM (Sound Stauts Memory) To listen to the selected sound Press button. Select according to the mood by repeatedly pressing the button. Standard Music Speech Movie User Press button. ① Press button to move to the item ②...
  • Page 37 All manuals and user guides at all-guides.com Equalizer Ajustment is available regardless of the state of the sound mode and will be stored as the user's mode. Press button. ① Press button to move to the item ② Press button on the left. ③...
  • Page 38 All manuals and user guides at all-guides.com ・AVL ・Stereo AVL (Auto Volume Leveler) It is the function to similarly adjust the different volume of each broadcasting company. Press button. ① Press button to move to the item ② Press button to enter to sub menu. ③...
  • Page 39 All manuals and user guides at all-guides.com Stereo (How to set stereo) For regions with poor radio reception(weak frequency), the sound state can be poor (staticy) when selecting a channel. Set the stereo setting to "Mono" in such case. Press button.
  • Page 40 All manuals and user guides at all-guides.com ・Reset ・Languages Reset Use the existing adjusted values for initiation as they were set in the factory. Press the button. ① Press button to move to the item ② Press button to enter to sub menu. ③...
  • Page 41 All manuals and user guides at all-guides.com Language Use this when the user selects the language from the menu indicated on the screen. Press button. ① Press button to move to the item ② Press button to enter to sub menu. ③...
  • Page 42 All manuals and user guides at all-guides.com ・Trasparency ・White Wiper Trasparency Use this to change the base of the menu to transparent and opaque. Press button. ① Press button to move to the item ② Press the button to menu to sub menu. ③...
  • Page 43 All manuals and user guides at all-guides.com White Wiper (How to set panel protection function) Caution: An afterimage may be left on the screen if you watch at 4:3 f screen rate or with a paused/ frozen screen for a long time. ※...
  • Page 44 All manuals and user guides at all-guides.com ・Current Time Setting ・Time Setting Current time setting ( How to set the current time) You can set the time to automatically turn on/off if you set the current time. Current time acts only when the main power button of the monitor is pressed. To maintain this function, use the sub- power button or power button of remote control.
  • Page 45 All manuals and user guides at all-guides.com Time setting Current Time should be set first for this setting. Current Time acts only when the main power button of monitor is pressed. To maintain this function, use the sub power button or power button of remote control. Press button.
  • Page 46 All manuals and user guides at all-guides.com ・On Time Volume Setting ・Sleep Time Setting On Time Volume Setting (How to set the volume when it is turned on) Current Time should be set first for this setting. Current Time acts only when the main power button of monitor is pressed. To maintain this function, use the sub- power button or power button of the remote control.
  • Page 47 All manuals and user guides at all-guides.com Sleep time setting (How to make automatically turn off when you sleep) Set the desired time to make it automatically turn off. Press button. Whenever you press the "Sleep" button, you can select "Sleep Timer off" → "Sleep timer: 15" →...
  • Page 48 All manuals and user guides at all-guides.com ・Trouble Shooting Take the following steps first and if you still have the same problem, turn off the power and contact an authorized service center. • Screen related Matters Problem Action Is the power plug pulled out? Insert the power plug. Turn The screen does not appear the main power button on and press the power button of the remote control.
  • Page 49 All manuals and user guides at all-guides.com • Sound related Matters Problem Action Screen appears, 1. Press the button gently. but there is no sound 2. Increase the sound by pressing volume adjustment button. 3. Check if voice terminal of external input is connected properly.
  • Page 50 All manuals and user guides at all-guides.com ・Trouble Shooting ・Supporting Display Mode • Others Problem Action Remote control does not work. 1. Check if main power button of PDP monitor is pressed. 2. Check if the batteries of the remote control were loaded properly.
  • Page 51 All manuals and user guides at all-guides.com Supporting Display Mode It is optimal screen when the resolution is 1024 x 768. Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) 3 1 . 4 6 9 7 0 . 0 9 6 4 0×3 5 0 3 7 .
  • Page 52 All manuals and user guides at all-guides.com ・Specifications ・User Information Component Mode (Y, C Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) 6 4 0×4 8 0 15.73 6 0 . 0 0 SDTV, DVD 480i 6 4 0×4 8 0 1 5 .
  • Page 53 All manuals and user guides at all-guides.com USER INFOMATION Note: This equipment has been tested and found to comply with the limit for a Class B digit al device, pursuant t o part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when t he equipment is operated in a commercial environmental.
