ENER-J SHA5336-1G Quick Start Manual

Smart Wi-Fi Wall Touch Smart Wireless Video
Switch 1G/2G/3G Doorbell with Chime
(No Neutral Wire Needed)
Wireless Remote Control your switch from
anywhere, Works with Alexa & Google Home
www.ener-j.co.uk
SKU Code: SHA5336-1G / SHA5337-2G / SHA5338-3G

Features

1. No Neutral Wire Needed: Does not require a neutral wire
and can be easily installed without rewiring your existing
wiring. Simply replace your old switches to work with our
Smart Touch Switches. Our single live wire design without
a neutral wire is really an irreplaceable solution for many
traditional homes that couldn't use Smart Switches earlier
due to Neutral Wire which was mandatory but not any
more with our new design Smart Touch Switches
2. Touch Cotnrol & LED Backlight: Tempered glass touch
screen design, 40ms high-speed touch-sensitive response.
Strong/weak blue indicator shows the on/off clearly, easy
to find in darkness, but zero-impact on sleep. Low power
consumption and long service life.
3. Voice Control: Works with Alexa and Google Home for
easy voice control.
4. Automations: Control your switches, set timers create
scenes and routines to automate your lights according to
your schedule
5. Safety Protection: Fire-retardant material and Aluminum
shell for heat dissipation. 4mm thick tempered glass
panel is waterproof and safer than push button, prevent
electric shock even if touching by wet hands. No color
aging, easy to clean and no scratch.
Technical Specifications
Model No
Gang
Colour
Operating Voltage
Rated load
Self-consuming power
Operating environment
Wireless frequency
Wireless standard
Lifelong
Dimension
Weight
*No neutral wire needed.
: SK3-01/SK3-02/SK3-03
: 1/2/3 Gang
: Black
: AC180-240V/50Hz 2A
: Each gang less than 300W
: Less than 1mA
: -20°C~50°C, less than 95%RH
: Wi-Fi 2.4GHz (5G not supported)
: IEEE802.11b/g/n 2.4GHz
: More than 100,000 times
: 86*86*35mm
: 140g
