Kogan KAPRNTPKLBA User Manual

Portable pocket bluetooth label printer
Hide thumbs

Advertisement

Quick Links

Download this manual
PORTABLE POCKET
BLUETOOTH LABEL PRINTER
KAPRNTPKLBA

Advertisement

loading

Summary of Contents for Kogan KAPRNTPKLBA

  • Page 1 PORTABLE POCKET BLUETOOTH LABEL PRINTER KAPRNTPKLBA...

  • Page 2: Table Of Contents

    Safety & Warnings Components Overview Operation Cleaning & Care Troubleshooting Specifications Notes...

  • Page 3: Safety & Warnings

    SAFETY & WARNINGS FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions. This device may not cause harmful interference and this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Components

    COMPONENTS Label Maker User Guide USB Charging Cable OVERVIEW Paper compartment cover Print head Paper exit Window Slider cutter Paper Indicator compartment Power Button Charging port...
  • Page 5 Label paper Various label paper is are available for purchase for this printer. Cut paper Continuous paper The label paper features an ‘easy tear’ line, to help peel off the adhesive backing. Gently bend the label paper along the ‘easy tear’ line to make it easier to peel the bottom paper from the adhesive.
  • Page 6 Power Button and Indicator Indicator Power button Button Operation method Functions Press and hold for 3s Turn On/Off Short press Print out the paper Power button Print the content of the Double press self-test paper Indicator status Solid Green Normal status Slowly flashing Green Charging with power on Rapidly flashing Green...

  • Page 7: Operation

    OPERATION 1. Open the paper compartment cover. 2. Place the label paper in the paper compartment with the printing side facing up. Printing side faces toward this direction 3. Pull out approximately 5mm of the 4. Align the tabs on the cover with the label paper.
  • Page 8 7. The printer will eject a small amount of 8. After printing a label, slide the cutter paper. Paper installation is completed. up to tear off the label. Notes: • When installing or replacing the label roll for the first time, the label position identification is required;...
  • Page 9 Alternatively, search for “Print Master” in Use your mobile phone to scan the QR the App Store (iOS) or Google Play Store code to download the APP. (Android) and download. Print master Pair the Label Printer to your Phone 1. Turn on GPS (Android mobile phone only) 2.
  • Page 10 Confirm the Label Size Method 1: Check the sticker on the label Method 2: Check the label paper paper. packaging Method 3: Use a ruler to measure Method 4: Check the label paper pads. 40mm...
  • Page 11 Creating Labels From the home menu, select from either Lite or Creation mode depending on your requirements. • Lite mode: Edit simply, print quickly • Creation mode: Requires more time to edit but has more options (multifunctional, graphic icons, QR codes etc.) Note: You can view operation tutorials and switch editing versions in the “home”...
  • Page 12 Lite Mode 1. Select “Label Setting” 2. Select the label size 3. Click “(T)” to input text Print master Print master Print master Click to enter content Click to enter content Label Label setting Blank label 12x40mm 4. Edit function description 5.
  • Page 13 Functions Operation method Example Click to insert text. User can edit the text size, typesetting and select various fonts, etc. Milk 2021/3/1 Add date Milk 18:44pm Edit specific time point Unit symbol Milk 500ml Creation Mode 1. Select “Label Setting” 2.
  • Page 14 5. After editing, click to 6. After printing, slide the 7. If using continuous "Print" cutter up to tear off the paper tear off the bottom label paper adhesive backing. Label Text direction Save Functions Description Click to insert text. User can edit the text size, typesetting and select various fonts, etc.

  • Page 15: Cleaning & Care

    CLEANING & CARE 1. Turn off the Label Maker. 2. Use a cotton swab dipped in a little alcohol. 4. Allow the alcohol to evaporate and 3. Wipe the print head gently. then turn it on and double click the power button to print labels.

  • Page 16: Troubleshooting

    TROUBLESHOOTING Problem Solution Ensure the tabs on the paper The printer cover won’t close. compartment cover are aligned with the holes in the printer. • Ensure the paper roll is correctly installed in the printer. • Ensure that the label is placed in the printer with printing side facing left.

  • Page 17: Specifications

    SPECIFICATIONS Printing technology Thermal printing Consumable width 6-15mm Effective printing width 12mm Pre-cut paper, black mark paper, continuous Supported paper paper Printing density Light, standard, dark Printing resolution 203dpi Print head service life 50km Communication interface Bluetooth Dimensions 135 x 79.6 x 29.2mm Power input 5V=2A Power supply method...

  • Page 18: Notes

    NOTES...
  • Page 20 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.kogan.com...
