- Page 1 Instruction Manual ELECTRIC GRIDDLE WITH CABINET （Series of Instructions） MANUAL INSTRUCTIONS (Read the machine carefully before using it.)
- Page 2 2. Equipped with independent adjustable temperature controller, the control range is between 50 ℃ - 300 ℃, saving energy. 3. It is made of stainless steel with oil and slag boxes. 4. Fast temperature rise, convenient operation and easy maintenance. II. Basic parameters: Model HER-706A HER-906A Service voltage 3N-380V 50/60Hz 3N-380V 50/60Hz power 12kW 50-300℃...
- Page 3 Instruction Manual III. electrical schematic diagram ST1 、 ST2 KM1 、 KM2 EH1-EH6 ------ ------ ------ Heating tube Thermostat AC contactor ------ ------ HL1、HL3 Power indicator HL2、HL4 Heating indicator IV. operation procedures: 1. Check whether the power supply installation is normal, and ensure that the power supply voltage is consistent with the use voltage of the furnace.
- Page 4 Instruction Manual V. precautions for installation: 1. The use voltage of the equipment must be consistent with the supply voltage. 2. The user shall install appropriate leakage protection switch near the equipment. 3. Copper equipotential terminal is set under the back of the furnace body, which shall be connected with copper core conductor of no less than 1.5mm2 according to the regulations.
- Page 5 Instruction Manual Vi. general troubleshooting: Fault phenomenon Reason Elimination method 1. Turn on the switch, turn 1. No power supply for 1. Check the power supply on the power, and the power the line indicator does not light up or heat up 2.
- Page 6 Instruction Manual variant? Is the power cord aged, cracked or broken? Is the control panel damaged? In use: is there any burnt odor or odor? Is the switch not in good contact? Is the temperature out of control or leakage? Warning! Routine inspection must be carried out frequently to prevent accidents.
