Summary of Contents for WPI P40
- Page 1 WORLD PRECISION INSTRUMENTS INSTRUCTION MANUAL WPI P40 Microdrill Serial No._____________________ www.wpiinc.com 101923...
-
Page 3: Table Of Contents
WPI P40 Drill CONTENTS ABOUT THIS MANUAL ........................1 INTRODUCTION ..........................1 Notes and Warnings ......................... 2 Work Area ..........................2 Operation ..........................2 Bur and Chuck ........................2 Power ............................. 3 Parts List ............................4 Unpacking ........................... 4 INSTRUMENT DESCRIPTION ......................5 Setup ............................ - Page 4 World Precision Instruments...
-
Page 5: About This Manual
Fig. 1—WPI P40 Microdrill INTRODUCTION The line powered WPI P40 Drill makes easy work of grinding, finishing, cutting, and drilling bone, teeth and other material. The high-torque 40,000 RPM (maximum) motor is quiet and has minimal vibration, reducing wear on the motor and providing greater comfort for users. -
Page 6: Notes And Warnings
Notes and Warnings Please read the following cautions carefully before operating your new WPI P40 Drill. Work Area NOTE: Do NOT work in a dangerous place. Keep the workplace clean. Debris may cause an accident. NOTE: Do NOT use the control box in a humid place. -
Page 7: Power
WPI P40 Drill Fig. 2—Fig. Recommended maximum RPM/bur diameter. Power CAUTION: Do not turn on the power while the collet chuck of the handpiece is open. The motor could short circuit. CAUTION: To avoid an injury caused by a sudden start, verify that the switch is off before putting the power plug in the wall socket (mains). -
Page 8: Parts List
Concealed damage should be reported at once to the carrier and an inspection requested. Please read the section entitled “Claims and Returns” on page 15 of this manual. Please contact WPI Customer Service if any parts are missing at 941.371.1003 or customerservice@wpiinc.com. -
Page 9: Instrument Description
Power Switch – Switch to turn the power on (1). If using the foot pedal, set the power switch to off (0). Voltage Selection Switch – Selects 110 or 220V for the operation of the WPI P40 Drill Forward Reverse Switch – Set the direction the motor (bur) spins. -
Page 10: Setup
Bur – The WPI P40 Drill comes with a blank shaft and a tool set, but any standard 3/32” (or 2.35 mm) bit or bur will fit in the WPI P40 Drill collet chuck. -
Page 11: Operating Instructions
Normal Operations Install the desired bur in the handpiece collet chuck, and verify that the chuck lock is in the secure position. See Changing the Bur, above. Do not turn the WPI P40 Drill on until the bur is secured. -
Page 12: Maintenance
Avoid getting moisture on the inside of the WPI P40 Drill. • Do not apply oil to the WPI P40 Drill or clean it with water. Oil could break down the grease inside the bearings. •... - Page 13 Put the screws in the holes of the new carbon brushes (supplied with your WPI P40 Drill) and insert the new brushes the same way the old ones came out. Line up the screws with the screw holes and gently compress the spring as you position the new carbon brushes.
-
Page 14: Accessories
ACCESSORIES Part Number Description 504458-5 Replacement Fuse 120V-T3.15A/250V (pkg. of 5) 503560-5 Replacement Fuse 230V-T2A/250V (pkg. of 5) 501842 Ball Mill, Carbide, #7, 0.083” diameter (pkg. of 5) 501850 Abrading Tip, Rubber (pkg. of 20) 501851 Abrading Tip, Stone (pkg. of 5) 501852 Accessory stand 501853... -
Page 15: Troubleshooting
Please contact Technical Support for specific instructions on this procedure. NOTE: If you have a problem/issue with that falls outside the definitions of this troubleshooting section, contact the WPI Technical Support team at 941.371.1003 or technicalsupport@wpiinc.com. World Precision Instruments... -
Page 16: Specifications
SPECIFICATIONS This unit conforms to the following specifications: General Maximum Speed 40,000 rpm Maximum Torque 3.0 N·cm Overload Protection Function Environment Setup Temperature 10°C~30°C Humidity 10~80% Air pressure 700~1060 hPa Dimensions of the bur 2.35 mm (ISO7785-2 TYPE2) Minimum fitting length of bur 10 mm Power Power Input... - Page 17 WPI P40 Drill World Precision Instruments...
-
Page 18: Declaration Of Conformity
Sarasota, FL 34240-9258, USA as the manufacturer/distributor of the apparatus listed, declare under sole responsibility that the product(s): 505635 (WPI P40 DRILL) To which this declaration relates is/are in conformity with the following standards or other normative documents: Low Voltage Directive (Safety) 2014/35/EU: •... -
Page 19: Warranty
WPI shall not be liable for any damage to data or property that may be caused directly or indirectly by use of this product. - Page 20 175 Sarasota Center Blvd., Sarasota FL 34240-9258 Tel: 941-371-1003 • Fax: 941-377-5428 • E-mail: sales@wpiinc.com 1 Hunting Gate, Hitchin, Hertfordshire SG4 0TJ Tel: 44 (0)1462 424700 • Fax: 44 (0)1462 424701 • E-mail: wpiuk@wpi-europe.com Germany Pfingstweide 16, D-61169 Friedberg (Hessen), Germany Tel: +49 (0)6031 67708-0 •...
