Summary of Contents for APsystems APstorage APbattery
- Page 1 APbattery USER MANUAL Please read this manual carefully before installing the system and carry out the installation procedures as per the instructions Rev1.5 2023-11-29 © All Rights Reserved...
-
Page 2: Table Of Contents
Table of Contents CHAPTER 1 INTRODUCTION ........................2 CHAPTER 2 PRECAUTIONS ........................4 CHAPTER 3 INSTALLATION CYCLE ....................5 SECTION 3.1 Check kit components .................... 6 SECTION 3.2 Read the instruction manual ................7 SECTION 3.3 Check installation tools ..................7 SECTION 3.4 Risk assesment/compliance to standards ............8 SECTION 3.5 Requirements for wall or support ..............8 SECTION 3.6 Identify a suitable location for the APbattery ..........9 SECTION 3.7 Installation space planning ................. -
Page 3: Chapter 1 Introduction
Energy storage system installer training course. All specifications and descriptions contained in this document are verified to be accurate at the time of printing. Continuous improvement is a goal at APsystems and we reserve the right to make product modifications at any time. - Page 4 CHAPTER 1 INTRODUCTION Battery Terminals And Communication Ports Safety Switch(ON/OFF) Safety Valve Items Description On/off button Used as APbattery indicator and mode switching APbattery terminals and Used to connect with PCS and operate the system communication ports Used as the main circuit switch; Protect the circuit and avoid Safety switch unexpected issues occuring Aluminum case...
-
Page 5: Chapter 2 Precautions
CHAPTER 2 PRECAUTIONS WARNING Failure to observe the precaution described in this section can cause serious injury to persons or damage to property. Observe the following precautions: Risks of explosion Do not subject the APbattery to strong impacts. Do not crush or puncture the APbattery. ... -
Page 6: Chapter 3 Installation Cycle
PCS into the building’s electricity supply. A typical project cycle for a APsystems APbattery is shown below. It shows consideration of the APbattery from the start of the project through the stages of installation, commissioning, and finishing with operation and maintenance considerations. -
Page 7: Section 3.1 Check Kit Components
CHAPTER 3 INSTALLATION CYCLE SECTION 3.1 Check kit components Check kit contents against the included part list with component descriptions and quantities. Ensure all components and quantities are present before starting the installation project. KITS PICTURES APbattery ×1 Mounting Plate ×1 Expansion screw (M8*70) -
Page 8: Section 3.2 Read The Instruction Manual
CHAPTER 3 INSTALLATION CYCLE SECTION 3.2 Read the instruction manual All of the instructions should be thoroughly read and understood before attempting to install, wire, operate and maintain the APbattery. Contact with electrically active parts of the system such as terminals can result in burns, sparks, and lethal shock whether the module is connected or disconnected. -
Page 9: Section 3.4 Risk Assesment/Compliance To Standards
CHAPTER 3 INSTALLATION CYCLE SECTION 3.4 Risk assesment/compliance to standards The APbattery can power your home by combing with a PCS to store PV generated electricity to create a solution for residential and light commercial properties. Installation standards vary between countries and as such we recommend in all cases that you check with your local standards authority before you commit to installing our energy storage system. -
Page 10: Section 3.6 Identify A Suitable Location For The Apbattery
CHAPTER 3 INSTALLATION CYCLE Mounting Angle The APbattery should be installed vertically or tilted no more than 15° Do not install the APbattery on a forward-leaning or horizontal plane. Install the APbattery on a solid and ventilated surface. ... -
Page 11: Section 3.7 Installation Space Planning
CHAPTER 3 INSTALLATION CYCLE The 1000mm lower clearance is only recommended where children could access the APbattery and touch the heat sink/chassis. Unless walls are properly insulated, avoid mounting the APbattery on any wall that is directly exposed to the sun or a heat source such as a boiler room wall. Only work on the APbattery when it is fully disconnected and observe the heat sink ... -
Page 12: Chapter 4 Installation
CHAPTER 4 INSTALLATION SECTION 4.1 Installation for mounting plate STEP Description Draw lines positioning the holder plate with ruler Step1 on the wall Drill the screw holes into the wall for Step2 8×φ12×55mm Tap the expansion bolts into the holes in the wall. Step3 Tighten the hex nut with a wrench to fully expand the expansion bolt sleeve. -
Page 13: Section 4.2 Installation For Apbattery
CHAPTER 4 INSTALLATION SECTION 4.2 Installation for APbattery WARNING APbattery is heavy and challenging to lift, we recommend multiple persons to lift it. We recommend to follow the schematic instruction to complete the installation. Repeat the same installation process if you have multiple series or parallel installations of ... -
Page 14: Chapter 5 Wiring
(Ensure the APbattery is powered on). The initial voltage should register within 48-54V DC. if the reading is outside this range then please call your APsystems authorized reseller for advice. It is recommended that the DC cable connection between the PCS and APbattery is kept to a ... - Page 15 CHAPTER 5 WIRING STEP4 installation method positive cable is the same as that of negative cable. (threading before crimping the terminal) STEP5 Connect the negative cable to the terminal of the battery negative interface; STEP6 Connect the communication ...
- Page 16 CHAPTER 5 WIRING STEP7 Connect positive cable to the terminal of the positive interface of the battery; STEP8 Adjust the tightness of the waterproof connector, and push positive negative mounting plates up to the proper position; STEP9 Press the positive and ...
-
Page 17: Section 5.1 Wiring In Parallel
CHAPTER 5 WIRING SECTION 5.1 Wiring in parallel WARNING The solid line in the figure represents the DC cable, and the dashed line represents the communication cable. Design specifications applicable for a maximum of 100 Amp charge/discharge PCS only. ... -
Page 18: Section 5.2 Wiring In Parallel Continued
CHAPTER 5 WIRING SECTION 5.2 Wiring in parallel continued BMS RJ45 definition RJ45-PIN BMS Port WAKEUP-12V WAK_GND CAN-H CAN-L 485-A 485-B The CAN interface is used for communication between batteries in parallel, 485 interface to communicate with inverter. Note that no WAKEUP function PIN1 / PIN2 must be disconnected. Connection of Communication Cable ... - Page 19 CHAPTER 5 WIRING Multiple batteries in parallel use RJ45 cables Set the BMS control board address for parallel battery packs If multiple batteries are used in parallel, you need to ask your dealer for a battery address setting tool. ...
-
Page 20: Chapter 6 Commissioning, Operating,And Maintenance
CHAPTER 6 Commissioning, operating,and maintenance SECTION 6.1 Commissioning STEP Description STEP 1 Turn on the safety switch Hold the on/off button of the APbattery for over 3 seconds until the button light is in STEP 2 a steady on state Ensure all the APbattery are powered on. STEP 3 Ensure the PCS and APbattery are connect successfully. -
Page 21: Section 6.2 Operating
CHAPTER 6 Commissioning, operating,and maintenance SECTION 6.2 Operating In the Process of using the APbattery please follow this manual for proper care and use of the product. There are three common modes: 1) Normal mode 2) Standby mode 3) Storage/transport mode NOTE Make sure to select the same mode for every APbattery in multiple connection. -
Page 22: Section 6.3 Apbattery Care
Caution : Do not use cleaning solvents to clean APbattery. SECTION 6.4 Maintenance APbattery is not user serviceable and must be repaired by a APsystems Certified Installer who has been trained by APsystems. If any problems arise refer to troubleshooting on page 24 before contacting the APsystems Authorized Reseller who sold the APsystems unit. -
Page 23: Chapter 7 Appendices
CHAPTER 7 APPENDICES SECTION 7.1 Troubleshooting If APbattery is not working correctly perform the following steps. If the issue persists contact APsystems customer support. Problem Solution check the temperature in the room and APbattery refuses to operate increase ventilation if needed... -
Page 24: Section 7.3 Specifications
CHAPTER 7 APPENDICES SECTION 7.3 Specifications Model APbattery-48V/5.76kWh Rated Energy 5.76kWh Depth of discharge 90% DOD Nominal Voltage 48VDC Voltage range 39~54VDC Maximum charging voltage 54VDC Maximum pulse current at 25℃,10s <120A DC Battery Input Voltage 40.0-60.0VDC Battery Capacity 120Ah Charging Strategy for Li-Ion Battery Self-adaption to BMS Max Continuous Charge Current... -
Page 25: Section 7.4 Warranty Claims And Performance
(ii) evidence showing the Product has been under-performing; and (iii) other documents, evidence, or information as may be required by APsystems or the agent appointed by APsystems to deal with such warranty claim. APsystems or approved agent of APsystems will examine the evidences and... - Page 26 APsystems might request the Customer to provide, to assess the actual performance of the Products; a valid warranty claim is not submitted to APsystems within 10 days after relevant applicable warranty period.
