RB-1 PIN Pad Token

QUICK Reference

http://www.cryptocard.com

051004

Table of Contents

Need help?

Do you have a question about the CRYPTO-Server RB-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for CryptoCard CRYPTO-Server RB-1

Page 2: Table Of Contents
CTIVATED BY First Use ......................8 Generating a Passcode..................8 User-changeable PIN ..................9 ...................10 ENERATING IGITAL IGNATURES ..................11 OKEN ESYNCHRONIZATION LCD C ..................12 ONTRAST DJUSTMENT ....................13 OKEN NITIALIZATION ....................14 ATTERY EPLACEMENT Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 3: Overview
The PIN may be required to access the Menu items. Used to confirm or complete any keypad inputs. Used to clear a keypad input error (e.g. PIN, challenge). Used to change the PIN used to activate the token. CHGPIN Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 4: Operating Modes & Options
Determines the length of time a passcode is displayed on the token, after which the token display is cleared and the token turned off. Options are 30, 60, and 90 seconds. Also used to prevent the token from being reactivated before expiration of the shut-off period. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 5 Token Activated by PIN requires the user to key the PIN into the token before a passcode is generated. In this mode, only the passcode displayed by the token is sent to the authentication server; the PIN is not transmitted across the network. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 6 Token Activated by PIN options, the token will be locked and will not generate passcodes until it is re-initialized. Allow Trivial PINs: • No: prevents the use of sequences or consecutive digits/characters longer than 2. For example, 124 is permitted; 123 is not permitted. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 7 Multiple mode. Note that the Automatic shut-off option will power the token off automatically after the specified time interval elapses. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 8 Usage Flags: • Authentication enabled: token can be used to authenticate, if checked. • Signature enabled: If this usage flag is checked, the token may be used to generate digital signatures. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 9: Using The Rb-1, Pin Stored On Server
Server Operator may also force a PIN change for individual users, as required. When a PIN change is required, the user will be prompted through the process. Once complete, the user must re-authenticate to gain access to protected resources. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 10: Using The Rb-1, Token Activated By Pin
The token displays the one-time passcode. b. In Challenge-response mode: Enter the 8 digits of the challenge using the numeric keypad. Press ENT to complete the input. The token displays the one-time passcode. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 11: User-Changeable Pin
2. At the NEWPIN? prompt, enter the digits of the new PIN and press ENT. 3. At the VERIFY prompt, re-enter the new PIN and press ENT to confirm. 4. The token displays a CARD OK message to indicate that the new PIN has been accepted. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 12: Generating Digital Signatures
Press ENT to complete input. The digital signature is displayed for entry into the application/document. Press ENT and repeat step 2 if multiple signatures are required. Press PASSWORD to end digital signature mode. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 13: Token Resynchronization
1. Press MENU and enter your PIN, if required. The Contrast prompt will be displayed. 2. Press MENU again to display the ReSync option. 3. Press ENT to selection this option. Enter the resynchronization challenge using the numeric keypad. Press ENT to complete the input. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 14: Lcd Contrast Adjustment
3. Press MENU repeatedly to lighten the display (-xx00xx- is the lightest value). Press DIGSIG repeatedly to darken the display (-xx15xx- is the darkest value). 4. Press PASSWORD to accept the contrast selection. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 15: Token Initialization
The LCD end of the token should be toward the bottom of the initializer. 2. Follow the CRYPTO-Console GUI directions for token initializations. Click Next to initialize. The token will display the CARD OK message on successful initialization. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
Page 16: Battery Replacement
Administrator for reprogramming. 3. Remove the battery compartment cover. 4. Remove one battery and replace it with a new battery (CR2016). 5. Remove the other battery and replace it. Copyright © 2005 CRYPTOCard Corporation All Rights Reserved...
