POWER LUX DSP SUBWOOFER
OWNER'S MANUAL: PL-10s, PL-12s, PL-10p and PL-12p
[INTRODUCTION]
Thank you for choosing Phase Technology
We know there are a wide variety of choices available
today, and we sincerely appreciate your purchase of
our product. Phase Technology speakers are built to
exacting standards and will provide many years of
listening enjoyment.
Our speakers are the result of over five decades of
designing and manufacturing. We hold many key
patents in loudspeaker technology including the
soft-dome tweeter. Our mission, our passion is to
constantly advance the art and science of accurate
audio reproduction. Our dedication ensures your new
speakers will accurately reproduce all the impact,
detail, and delicacy of today's digital technology.
Regardless of application, serious audiophile
listening or home theater, we recommend that you
take the time to read this manual thoroughly before
connecting speakers to your amplifier or receiver.
In the highly unlikely event that you should experience
a problem with set-up or operation, please contact
one of our authorized dealers for assistance, or
contact us directly.
Phase Technology Corporation
13720 W. 109th Street
Lenexa, KS 66215
913.663.5600
www.mseaudio.com
techsupport@mseaudio.com
[FEATURES]
speakers.
• 325-Watt RMS, 750-Watt Peak Power
®
Integrated Amplifier
• 10" or 12" Long Throw Mica-Graphite Poly Cone
with NBR Surround
• Sealed or 3" Ported Enclosure
• Signal Sensing Auto Turn On/Off
• Level and Phase Control
• 5 band Manual EQ
• Variable Crossovers
• Stereo LFE Inputs
• Stereo Line Outputs with Wide Range and
Subwoofer Mode Configurations
• Audio Control through MSE Sound Application
SAFETY INSTRUCTIONS .............................................. 2
GETTING STARTED & PRECAUTIONARY NOTES ....... 3
SUBWOOFER PLACEMENT .......................................... 3
HOOKING UP YOUR
POWER LUX DSP SUBWOOFER ..................................4
AMPLIFIER SETUP AND BASS MANAGEMENT .......... 5
SUBWOOFER AMPLIFIER PANEL ................................ 6
CARING FOR YOUR SPEAKERS .................................. 7
MAINTENANCE AND SERVICE .................................... 7
TROUBLESHOOTING ................................................... 7
WARRANTY .................................................................. 8
SPECIFICATIONS .......................................................... 9
Advertisement
Table of Contents
Summary of Contents for Phase-Tech POWER LUX PL-10s
- Page 1 POWER LUX DSP SUBWOOFER OWNER’S MANUAL: PL-10s, PL-12s, PL-10p and PL-12p [INTRODUCTION] [FEATURES] Thank you for choosing Phase Technology speakers. • 325-Watt RMS, 750-Watt Peak Power ® We know there are a wide variety of choices available Integrated Amplifier today, and we sincerely appreciate your purchase of •...
- Page 2 [SAFETY INSTRUCTIONS] 9. Heat - The appliance should be situated away from heat sources such as radiators, stoves, or other appliances that CAUTION produce heat. RISK OF ELECTRIC SHOCK 10. Power Source - The appliance should be connected to DO NOT OPEN a power supply only of the type described in the operating instructions or as marked on the appliance.
- Page 3 POWER LUX DSP SUBWOOFER [GETTING STARTED AND PRECAUTIONARY NOTES] For proper connection and therefore full enjoyment of your new Phase Technology speakers, we encourage you to read this Owner’s Manual thoroughly, even if you are very familiar with installing speakers and home entertainment equipment.
- Page 4 [HOOKING UP YOUR POWER LUX DSP SUBWOOFER] Special note: Turn off and unplug your amplifier before connecting speakers. Special Note: Observe Speaker Polarity Carefully! Every cable, speaker, and amplifier is clearly marked to show their positive (+) and negative (-) terminals.
- Page 5 WIRED DIRECT INPUT CONNECTION SETUP Two RCA and two XLR outputs are offered on the rear panel of the subwoofer. This subwoofer comes equipped with the ability to select your line output configuration. The two configuration modes allow for different signal conditioning based on your target speaker.
- Page 6 [SUBWOOFER AMPLIFIER PANEL] 1. Main Power Switch: “ON” and “OFF” switch. 2. Power Input: Connects to a standard AC power outlet with the supplied power cord. The Power Lux DSP subwoofer is designed to adjust automatically to handle power sources of 100-240V, 50-60Hz. 3.
- Page 7 [CARING FOR YOUR PHASE TECHNOLOGY SPEAKER] All Phase Technology speakers are finished with a high degree of craftsmanship in either hand polished paint, vinyl laminates or textured black finishes. We recommend using a lint-free rag with a small amount of glass cleaner to maintain the long-lasting beauty of the finish.
- Page 8 [WARRANTY] LIMITED WARRANTY: Phase Technology warrants its loudspeakers to be free from defects in material and workmanship for a period of ten (10) years for speaker product, limited lifetime for CI speakers, and three (3) years for the electronic components to the original purchaser. Purchase must be made from an authorized Phase Technology dealer.
